General Monitors 2180A Instruction Manual

Single channel control module hydrogen sulfide gas applications
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Model 2180A
Single Channel Control Module
Hydrogen Sulfide Gas Applications
The information and technical data disclosed in
this document may be used and disseminated
only for the purposes and to the extent
specifically authorized in writing by General
Monitors.
Instruction Manual
General Monitors reserves the right to change
published specifications and designs without
prior notice.
Part No.
Revision
07-05
MAN2180A
MAN2180A
C/07-05

Advertisement

Table of Contents

Troubleshooting

loading
Need help?

Need help?

Do you have a question about the 2180A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for General Monitors 2180A

Summary of Contents for General Monitors 2180A

  • Page 1 General Monitors. Instruction Manual 07-05 General Monitors reserves the right to change published specifications and designs without prior notice. MAN2180A Part No. MAN2180A...
  • Page 2 This page intentionally left blank.

  • Page 3: Table Of Contents

    LIST OF TABLES ........................VI INTRODUCTION...........................1 Protection for Life ............................1 Special Warning ............................1 Customer Support ........................2 1.0 BEFORE INSTALLATION ......................3 Differences Between Models 2180A and 2180................3 General Product Description......................3 Controller............................4 Sensor Assembly ........................5 2.0 INSTALLATION ........................6 Location of the Controller......................6 Power Connections ........................6...
  • Page 4 General Maintenance.......................26 Periodic System Verification ....................26 5.0 TROUBLESHOOTING......................27 General ............................27 Troubleshooting Table ......................27 Fault Codes..........................28 6.0 CUSTOMER SUPPORT .......................30 General Monitors’ Offices ......................30 Other Sources of Help ......................30 7.0 APPENDIX..........................31 Warranty...........................31 Sensor Operating Principle ......................31 General Specifications - Controller ..................33 7.3.1 Mechanical Specifications...................33...

  • Page 5: Illustrations

    Model 2180A Illustrations Figure 1: Model 2180A ............................4 Figure 2: Battery Backup Diagram ......................... 7 Figure 3: Protection Circuit for Relay Contacts ....................12 Figure 4: Junction Box Assembly Sensor......................13 Figure 5: Outline Drawing & Rear Terminal Connections ..................14 Figure 6: Front Panel Display ..........................
  • Page 6 Model 2180A List of Tables Table 1: Model 2180A Mounting Parts ........................6 Table 2: Sensor Wire Colors ..........................10 Table 3: Sensor Cable Colors ..........................10 Table 4: Cable Length ............................10 Table 5: De-Energized Alarm Relay Contacts...................... 11 Table 6: Energized Alarm Relay Terminations.....................

  • Page 7: Introduction

    This manual provides instruction for installing and operating the General Monitors Model 2180A Single Channel Control Module for Hydrogen Sulfide Gas Applications. While the 2180A system is easy to install and operate, this manual should be read in full, and the information contained herein understood, before attempting to place the system in service.

  • Page 8: Customer Support

    Model 2180A General Monitors’ gas detection systems are primarily safety devices for the protection of personnel and facilities and must be “always ready”. With proper installation, calibration, and maintenance, the system provides continuous monitoring of hazardous areas. The user must assume all liability for misuse of General Monitors’...

  • Page 9: Before Installation

    Please check the individual manuals for details about wiring, set up and operation of these two units. CAUTION: The Model 2180A Controller is easy to install and operate. However, one should fully read and understand this manual before attempting to place the system in service.

  • Page 10: Controller

    • High, Low & Fault relays NOTE: A service-loop is necessary between the Model 2180A Controller’s rear panel terminals and field/power wiring. This service loop permits the controller to be removed or slid forward for servicing. This service loop is...

  • Page 11: Sensor Assembly

    Model 2180A 1.4 Sensor Assembly One sensor assembly is supplied with the system. This assembly is comprised of the sensor, the sensor housing, and an optional splashguard. NOTE: This sensor assembly is CSA approved for Class I, Division 1 and...

  • Page 12: Installation

    The controller operating temperature range is 0°C to 60°C (32°F to 140°F). 2.2 Power Connections The Model 2180A operates on a nominal line voltage of 117 VAC, 50-60 Hz., 220 VAC operation is an available option. NOTE: To eliminate accidental shutdown, GMI does not provide a power ON-OFF switch.

  • Page 13: Battery Backup

    (ampere-hour capacity) is dictated by the length of time power outages may last. A Model 2180A Controller requires approximately 2 ampere (peak) at 24 VDC. General Monitors recommends that a lead-acid type battery be used. This type of battery can be expected to last for several years with minimum maintenance.

  • Page 14: Analog Output Connection

    2.5 Remote Reset Connection Remote reset (of the alarm relays) are made to the rear panel of the Model 2180A and should be connected between the RESET and 24VDC(-) terminals. A remote RESET switch must be a normally open/momentary closed type.

  • Page 15: Sensor Installation

    The presence of such materials in an area does not preclude the use of a sensor. The feasibility of using a sensor in such areas must be determined by an analysis of the specific factors in each application. Consult General Monitors before attempting any such installation.

  • Page 16: Table 2: Sensor Wire Colors

    3. Connect the cable so that the terminal color at the sensor housing matches the terminal color at the controller. General Monitors’ sensor leads are color coded, and should be connected to the rear terminal connector as shown in the following...

  • Page 17: Alarm Wiring Connections

    2.8 Alarm Wiring Connections The Model 2180A alarm relays may be operated as normally de-energized or normally energized, and latching or non-latching. The Low and High alarm contacts for customer use are DPDT (double pole, double throw), and are rated 4 amps at 115 VAC, resistive.

  • Page 18: Figure 3: Protection Circuit For Relay Contacts

    Model 2180A CAUTION: Inductive loads, such as bells, buzzers, relays contactors solenoid valves, etc., connected to the High alarm, Low alarm, and Fault alarm relays must be clamped down as shown in the diagrams below. Unclamped inductive loads can generate voltage spikes in excess of 1000 volts. Spikes of this magnitude will cause false alarms and possible damage.

  • Page 19: Figure 4: Junction Box Assembly Sensor

    Model 2180A Figure 4: Junction Box Assembly Sensor...

  • Page 20: Figure 5: Outline Drawing & Rear Terminal Connections

    Model 2180A Figure 5: Outline Drawing & Rear Terminal Connections...

  • Page 21: Start Up And Operation

    3.1 Types of User Interfaces User interfaces are provided so that the operator may interpret and direct the Model 2180A in the performance of its various functions. User interfaces consist of a digital display, status indicators, a mode button, and a reset button.

  • Page 22: Initial Application Of Power

    Model 2180A • The status indicators provide the user with an indication of the current mode of operation: HIGH (high alarm), LOW (low alarm), FAULT, SETUP (setup and setup check modes), and CAL (calibration or calibration check modes). • Mode button provides the user access to the Calibration, Calibration Check, Setup and Setup Check modes.

  • Page 23: Analog Output

    General Monitors offers ampoules with breaker bottles as a method of reliably introducing calibration gas to the Model 2180A. The ampoule is placed inside the breaker bottle into the breaker slot, and the breaker bottle is placed over the sensor. The ampoule should contain 50% FS of H S of the sensor range.

  • Page 24: Figure 7: Portable Purge Calibrator

    S) in air mixture and is available in 7 concentrations. The temperature limitation for operation and storage is 0°F to +130°F (-18°C to +54°C). Make sure the Model 2180A has had power applied for at least 24 hours to ensure that the metal oxide film of the sensor has stabilized.

  • Page 25: Calibration Check Mode

    Model 2180A 3. Allow the sensor to see the gas for 1 to 2 minutes. NOTE: Do not store the cylinder with the regulator fully engaged in the cylinder valve. 3.6 Calibration Check Mode This procedure is used to periodically check the response of an installed system to a known concentration of H S gas that is at least 50% of the full-scale reading.

  • Page 26: Aborting Calibration

    Model 2180A To Calibrate the Model 2180A: 1. Make sure the sensor is seeing clean air. 2. Enter the Calibration mode by following the same procedure for entering Calibration Check mode. Continue to press and hold the Mode button until the CAL LED becomes steady, approximately fifteen seconds.

  • Page 27: Entering The Password

    Model 2180A During the Setup mode the operator is allowed to select options. The selection procedure is the same for most of the options. Pressing the Mode button toggles the available choices. When the display has indicated a choice for five consecutive seconds, without the operator pressing the Mode button, the setup routine accepts that selection and moves on to the next option available.

  • Page 28: Low Alarm Options

    Model 2180A selection, (En or dE). Press the Mode button to toggle the selection. De-Energized (dE) is the factory default for this selection. The High LED on the front panel flashes while the latching/non-latching option displays. The display indicates the current selection, (nL or LA). Press the Mode button to toggle the selection.
  • Page 29 Model 2180A If the Password Disabled is selected, the unit returns to normal operation. If this setting is changed from Password Disabled to Password Enabled, the user enters a new password. The unit displays the left digit of the existing password (flashing on the display).

  • Page 30: Setup Mode Selection Table

    Model 2180A. The table shown below indicates the order of options in the Setup mode. To the right of the option entry is a description of the choices that are available for that option.

  • Page 31: Check Points For Calibration And Operation

    Model 2180A 3.10 Check Points for Calibration and Operation 3.10.1 Frequency of Calibration GMI recommends that the calibration be checked on each sensor at least every ninety (90) days. If a sensor is installed where it may be subjected to splashing water, mud or dirt accumulation, or adverse gases, more frequent calibration is recommended.

  • Page 32: Maintenance

    4.0 Maintenance 4.1 General Maintenance Once installed, the Model 2180A Controller requires little or no routine maintenance, other than periodic calibration checks. General Monitors recommends that a calibration schedule be established and adhered to. GMI also recommends that a logbook be kept, showing calibration dates and dates of sensor replacement.

  • Page 33: Troubleshooting

    If equipment or qualified personnel required for various tests is not available, it is recommended that the defective unit be returned to General Monitors for repair. A complete written description of the problem should be included.

  • Page 34: Fault Codes

    Model 2180A 5.3 Fault Codes In addition to the Fault LED on the front panel, the Model 2180A provides a fault code on the digital display whenever a fault condition occurs. The Fault Codes that can appear on the digital display are:...
  • Page 35 General Monitors for repair. If the system is still under warranty, damage to the unit caused by the customer may void the warranty.

  • Page 36: Customer Support

    United Arab Emirates 6.2 Other Sources of Help General Monitors provides extensive documentation, white papers and product literature for its complete selection of safety products. A selection of these documents are available online at the General Monitors website at http://www.generalmonitors.com.

  • Page 37: Appendix

    7.0 Appendix 7.1 Warranty General Monitors warrants the Model 2180A to be free from defects in workmanship or material under normal use and service within two years from the date of shipment. General Monitors will repair or replace without charge any such equipment found to be defective during the warranty period.
  • Page 38 Model 2180A or 0-100 ppm H S. Therefore, the change produces a signal approximately proportional to the logarithm of the H S concentration. This signal is processed, linearized, and displayed as a digital number on the front of the controller. The controller’s analog current output signal tracks the digital reading as well.

  • Page 39: General Specifications - Controller

    Model 2180A General Specifications - Controller 7.3.1 Mechanical Specifications Dimensions: 2.1”W x 6.9”H x 11.5”D (53mm x 175mm x 292mm) Weight: 3.8 lbs. (1.8 kg) Mounting: Rack, panel, wall 7.3.2 Environmental Specifications Temperature Range: 32°F to 140°F (0°C to 60°C) Storage Temperature: -4°F to +149°F (-20°C to 65°C)

  • Page 40: Recommended Spare Parts List

    Model 2180A 7.4.3 Recommended Spare Parts List Description Part Number Fuse – 2.A 250V F2 951-015 Fuse – 0.8A 250V F1 951-012 Sensor Per Original Order Table 10: Spare Parts List...

  • Page 41: Sample Calibration Schedule And Checklist

    Model 2180A 7.5 Sample Calibration Schedule and Checklist Sensor Serial Number Location ___________________ _____________________ 1. Installation and Preliminary calibration. Date: __________________ Record date after preliminary calibration is done. Date: __________________ 2. 24-hour calibration. Record date after 24- hour calibration is done.

  • Page 42: Product Configuration Table

    Model 2180A 7.6 Product Configuration Table MODEL 2180A SINGLE CHANNEL H2S CONTROLLER A. CONTROLLER 2180A Model 2180A Controller 3.0 lbs. 1 (Std) -P1 110 VAC/24VDC - P2 220 VAC/24 VDC RELAY – STATE - NC (STD) RS 1NC LATCH ALARM, NON-LATCH WARN, DE-ENERGIZED...

  • Page 43: Panel Assembly, Panel Mount - 98, Ref: 10199C

    Model 2180A E. ACTIVE CHANNELS: Controller Only (STD) One Active Channel 4.7 Lbs. Cal Kit Refill 4 Ea #20/#50/#1 0.7 Lbs. Sensor Housing 3.0 Lbs. Calibration Bottle 1.0 Lbs. Table 12: Product Configuration Table 7.6.1 Panel Assembly, Panel Mount – 98, Ref: 10199C...
  • Page 44 ADDENDUM Product Disposal Considerations This product may contain hazardous and/or toxic substances. EU Member states shall dispose according to WEEE regulations. For further General Monitors’ product WEEE disposal information please visit: www.generalmonitors.com/customer_support/faq_general.html All other countries or states: please dispose of in accordance with existing federal, state and local...
