Assembly Instructions
Caution: You must read this before you process
Please look in the dummy box for hardware packs
BARCART
CAUTION : This Barcart is NOT a TOY.
Keep your child / children at bay during the assembly process.
For moving the Barcart and to prevent damage to the Barcart, two adults are
needed to execute this action.
Page 1 OF 8
Noble House Home Furnishings LLC
Advertisement
Related Manuals for Noble House Home Furnishings BARCART
Summary of Contents for Noble House Home Furnishings BARCART
- Page 1 CAUTION : This Barcart is NOT a TOY. Keep your child / children at bay during the assembly process. For moving the Barcart and to prevent damage to the Barcart, two adults are needed to execute this action. Page 1 OF 8...
- Page 2 Description Label Picture Leg Frame Upper Tray Lower Tray Handle Blocked Wheel Wheel Description Label Label Picture ① Bolts (M6x35mm) ② Allen Screw (M6x60mm) ③ Allen Wrench ④ Spanner Wrench Page 2 OF 8 Noble House Home Furnishings LLC...
- Page 3 Barcart help you put the various parts into perspective. Please read through the instructions below to familiarise yourself with the parts and steps before assembly. Page 3 OF 8 Noble House Home Furnishings LLC...
- Page 4 Place the Upper Tray (B) on a clean, non-marring surface as shown in picture above. Position Leg Frame (A) into Upper Tray (B), secure by using Bolts( ①) with Allen Wrench(③). Do not fully tighten the Bolts. Page 4 OF 8 Noble House Home Furnishings LLC...
- Page 5 Attach the other Leg Frame (A) into Handles (D) and Upper Tray (B) as shown in the picture. ① ③ Secure Leg Frame (A) into Upper Tray (B) by using Bolts( ) with Allen Wrench( ). Do not fully tighten the Bolts Page 5 OF 8 Noble House Home Furnishings LLC...
- Page 6 Repeat the same process with other wheels. Note: On this step,it will have two Blocked Wheels and two Wheels. Two Blocked Wheels should be in one side that parallel with Handle (D). Page 6 OF 8 Noble House Home Furnishings LLC...
- Page 7 With assistance from your adult partners, turn the Barcart back to normal flat ground EXERT pressure, floorwards, onto the Barcart. This pressure will help the Legs and Barcart Top reach alignment at all joints. Check for wobbles. In a sequential manner, gradually tighten all Screws, Bolts until evenly secured.
-
Page 8: Care And Maintenance
Care & Maintenance ● Furniture may scratch floors. We recommend using furniture pads to protect your floors. Page 8 OF 8...
