Caution: You must read this before you process
BARCART
CAUTION : This Barcart is NOT a TOY.
Keep your child / children at bay during the assembly process.
For moving the Barcart and to prevent damage to the Barcart, two adults are
needed to execute this action.
Noble House Home Furnishings LLC
Page 1 OF 7
Advertisement
Table of Contents
Related Manuals for Noble House Home Furnishings BARCART
Summary of Contents for Noble House Home Furnishings BARCART
- Page 1 CAUTION : This Barcart is NOT a TOY. Keep your child / children at bay during the assembly process. For moving the Barcart and to prevent damage to the Barcart, two adults are needed to execute this action. Noble House Home Furnishings LLC...
- Page 2 Description Label Picture Upper Tray Lower Tray Removable Tray Blocked Wheel Wheel Description Label Label Picture ① Bolts (M6x25mm) Wooden Dowel ② (M10x25 mm) ③ Allen Key ④ Spanner Wrench Noble House Home Furnishings LLC Page 2 OF 7...
- Page 3 This Barcart has multiple parts and may require up to some 30 minutes to assemble. To give you an overview of the Barcart, the above picture is to help you put the below various parts into perspective. Please read through the instructions here to familiarise the parts and steps before assembly.
- Page 4 Position housing of Lower Tray (C) into pre-fixed Wooden Dowel (②) of Leg (A). Secure the Leg (A) and the Lower Tray (C) by using Bolts(①) with Allen Key(③). Do not fully tighten the Bolts. Noble House Home Furnishings LLC Page 4 OF 7...
- Page 5 4.1 Place the other Leg (A) on a clean, non-marring surface as shown in picture above. Attach the Wooden Dowel (②) into the housings on the Leg (A) 4.2 With assistance from your adult partners, turn pre-assembled barcart in step 3 180degree and position housings of Upper Tray (B) and Lower Tray (C) into the wooden dowel (②) of Leg (A) as shown in picture above.
- Page 6 Step 5 With assistance from your adult partners, turn Barcart in step 4 with its legs facing skyward Insert Blocked Wheel (E) and Wheel (F) into Leg Frame (A) as shown in the picture. Secure the wheels into the Leg Frame (A) by using Spanner Wrench (④) Repeat the same process with other wheels Note: On this step,it will have two Blocked Wheels and two Wheels.
- Page 7 Do not put hot items directly on furniture surface Do not clean furniture with harsh cleansers or polish. Do not place furniture under direct sunlight. Do not place furniture near heating or cooling vents. Do not write on furniture without a padded barrier to protect the surface. Do not place furniture outside .
