CS55_HO_42606.qxd
4/26/06
1:31 PM
WARRANTY
Limited Warranty
• This warranty covers defects in materials and workmanship of products manufactured,
sold or certified by Plantronics which were purchased and used in the United States.
• This warranty lasts for one year from the date of purchase of the products.
• This warranty extends to you only if you are the end user with the original purchase
receipt.
• We will, at our option, repair or replace the products that do not conform to the
warranty. We may use functionally equivalent reconditioned/refurbished/remanufactured/
pre-owned or new products or parts.
• To obtain service in the U.S., contact Plantronics at (800) 544-4660 ext. 5538.
• THIS IS PLANTRONICS' COMPLETE WARRANTY FOR THE PRODUCTS.
• This warranty gives you specific legal rights, and you may also have other rights that
vary from state to state. Please contact your dealer or our service center for the full
details of our limited warranty, including items not covered by this limited warranty.
S O U N D I N N O VAT I O N
Plantronics Inc.
345 Encinal Street
Santa Cruz, CA 95060 USA
Tel: (800) 544-4660
www.plantronics.com
©2006 Plantronics, Inc. All rights reserved. Plantronics, the logo design, IntelliStand, and Sound
Innovation are trademarks or registered trademarks of Plantronics, Inc. All other trademarks are
the property of their respective owners.
Patents U.S. 5,210,791; 6,735,453; 6,903,693; D492,667; Australia 303306; EM 293964 and 69109;
Taiwan D109301; and Patents Pending.
Printed in USA.
Page ii
73700-01 (04.06)
U S E R G U I D E
CS55H HOME EDITION
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
WIRELESS HEADSET SYSTEM
Advertisement
Table of Contents
Related Manuals for Plantronics CS55
Summary of Contents for Plantronics CS55
- Page 1 • This warranty covers defects in materials and workmanship of products manufactured, sold or certified by Plantronics which were purchased and used in the United States. • This warranty lasts for one year from the date of purchase of the products.
-
Page 2: Table Of Contents
Technical Assistance Regulatory Notices REGISTER YOUR PRODUCT ONLINE Visit www.plantronics.com/productregistration to register your CS55H Home Edition product online so we can provide you with the best possible service and technical support. Please refer to the separate Safety Instructions booklet for important product safety information prior to installation or use. -
Page 3: Features
Listening Volume Major Adjust FEATURES Base - Bottom View Base - Bottom View Front: Indicator Lights Talking (Green) Power (Red) Charging (Amber) Charging Cradle Headset Headset Telephone Configuration Dial Rear: Speaking Volume Minor Adjust IntelliStand ™ ™ Home Phone Adapter... - Page 4 SETUP FOR CORDLESS AND CORDED PHONES Plug the AC charger into an outlet and Plug Home Phone Adapter telephone cord into the base's AC charging jack. (RJ11) into wall telephone jack. Use splitter provided if needed. See step for detailed location. Plug Home Phone Adapter power cord Plug Home Phone adapter base cord into into the base power jack.
-
Page 5: Charging
CHARGING 1. Slide headset into charging cradle. 2. Gently press down on the headset to ensure that headset is in correct position. Amber charge indicator light on base will flash while charging and will change to solid amber when fully charged. -
Page 6: Making/Answering/Ending Calls
However, if you do not hear a dial tone, if either you or the recipient is having trouble hearing, or if you experience buzzing/hissing, please follow the directions below. If you cannot hear a dial tone through your headset, use a coin or small screwdriver to turn the telephone configuration dial until you can. -
Page 7: Volume
Headset Mute To mute headset, press the listening volume/mute button straight in. Press again to unmute. You will hear 3 rapid beeps every 15 seconds to indicate mute is on. -
Page 8: Headset Controls
HEADSET CONTROLS Feature Action Listening volume Rock back minor adjust and forth Mute Short key press straight in Making/answering/ Short key press ending calls Low battery Return headset — warning to charging cradle Out of range Move closer — warning—when... -
Page 9: Troubleshooting
The CS55 Home Edition does not require a handset lifter. Handset does not lift handset. lifter is for use with Plantronics model CS55 in an office environment. does not lift handset. lifter is for use with Plantronics model CS55 in an office environment. -
Page 10: Subscription
SUBSCRIPTION The headset and base unit are supplied subscribed to each other. However, if you wish to use a replacement headset with the base unit, then the units must be re-subscribed as follows: Return the headset to the charging cradle. -
Page 11: Maintenance
Telephone companies report that electrical surges, typically lighting transients, are very destructive to customer terminal equipment connected to AC power sources. NOTE: Changes or modifications not expressly approved by Plantronics, Inc. could void the user's authority to operate the equipment.
