BRK electronic SC7010BA Quick Start Manual

SMOKE & CO
C OMBO
A L A R M
SC7010BA
CAT.
10-YEAR CO SENSOR
10-YEAR ALARM LIFE
SMOKE & CO COMBO
Electrochemical CO sensor;
Photoelectric smoke sensor.
LATCHING ALARM
INDICATOR
Remembers which unit initiated
an alarm.
SILENCE FEATURE
Silences nuisance alarms.
END OF LIFE SIGNAL
Provides audible notice when alarm
needs to be replaced after 10 years.
SPREAD SPECTRUM
HORN TONE
Easier for elderly with normal age
related hearing loss to hear the horn.
OPTIPATH 360
TECHNOLOGY
Provides 360 degrees of direct
access to the smoke sensing
chamber.
120V AC, 60Hz Wire-in
with 3V (two 1.5V AA) Battery Backup

Description:

BRK Model SC7010BA is a wire-in, 120V AC 60Hz single and/or multiple station
combination smoke and carbon monoxide alarm specifically designed for
residential and institutional applications including sleeping rooms of hospitals,
hotels, motels, dormitories and other multi-family dwellings as defined in standard
NFPA 101. Model SC7010BA complies with ULC S531, CSA 6.19-01, NFPA 72 and
NFPA 720, HUD, FHA and other agencies that model their codes after the above
agencies. It meets building codes where AC/DC photoelectric smoke and carbon
monoxide alarms are required.
BRK SC7010BA is a state-of-the-art hardwired with battery backup smoke/
CO combo alarm that features a photoelectric smoke sensing chamber, an
electrochemical CO sensor and an End of Life signal. The Spread Spectrum Horn
Tone has a lower and varying frequency that makes it easier for the elderly with
normal age related hearing loss to hear the horn. This alarm features two latching
features and two silence features. Alarm Latch: Easily identifies initiating alarm
even after alarm condition has subsided. Low Battery Latch: Identifies which unit
is in low battery condition by blinking the green power light. Low Battery Silence:
Temporarily silence the low battery chirp for up to eight hours. Alarm Silence:
Silence alarm for several minutes. Other features include an 85dB horn, single
button test/silence, an easy access battery drawer and dust cover. OptiPath 360
Technology: Exclusive patented technology provides 360 degrees of direct access
to the smoke sensor. Two locking features are provided to prevent battery theft
and/or theft of the unit. Connection to AC power is made with a Quick-Connect
wiring harness. Installation is quick, easy and cost effective.
TM
3055574
MODEL SC7010BA
