- Page 1 PT1975R / PT1911MX / PT1975S / Touch Screen LCD Monitors USER’S GUIDE www.planartouch.com...
- Page 2 Important Recycle Instructions: Lamp(s) inside this product contains mercury. This product may contain other electronic waste that can be hazardous if not disposed of properly. Recycle or dispose in accordance with local, state, or federal Laws. For more information, contact the Electronic Industries Alliance at WWW.EIAE.ORG For lamp specific disposal information check WWW.LAMPRECYCLE.ORG.
-
Page 3: Table Of Contents
Table of Contents Usage Notice ... 3 Precautions ...3 Introduction ... 4 About PT1975R / PT1911MX / PT1975S ...4 Touch Screen for PT1975R...5 Touch Screen for PT1911MX ...5 Touch Screen for PT1975S ...6 Package Overview ...7 Installation ... 8 Product Overview...8 Kensington Security Slot ...9... - Page 4 Touch Screen Driver Installation ...24 Product Registration and Technical Support ...27...
-
Page 5: Usage Notice
Usage Notice - To prevent the risk of fire or shock hazards, do not Warning expose this product to rain or moisture. - Please do not open or disassemble the product as Warning this may cause electric shock. Precautions Follow all warnings, precautions and maintenance as recommended in this user’s manual to maximize the life of your unit. -
Page 6: Introduction
Introduction About PT1975R / PT1911MX / PT1975S The PT1975R / PT1911MX / PT1975S is a 19” flat panel screen with an active matrix, thin-film transistor (TFT) liquid crystal display (LCD). Features include: Direct Analog signal input Direct Digital signal input... -
Page 7: Touch Screen For Pt1975R
7, VISTA, XP, 2000, ME, 98, NT4.0, CE, XP Embedded, ® Linux, Apple Mac OS Touch Screen for PT1911MX Capacitive touch screen for finger input Surface: Anti-glare treatment Interface: Dual RS-232 Serial/USB controller Durability: 225 million touches at a single point Hardness of surface: Mohs’... -
Page 8: Touch Screen For Pt1975S
Touch Screen for PT1975S Surface Acoustic Wave (SAW) touch screen for finger and stylus input Surface: Anti-glare treatment Interface: Dual RS-232 Serial/USB controller Durability: 50 million touches at a single point Hardness of surface: Mohs’ Hardness rating of 7 Operating force: Typically less than 85 g Transmittance: 92%±5% ®... -
Page 9: Package Overview
Package Overview LCD Display Power Cord VGA Signal Cable DVI Signal Cable Audio-in Cable RS-232 Cable USB Cable - Type A to B Touch Screen Driver User’s Guide Installation CD-ROM Landing Strip DC Power Supply Cable Cover (sold separately) Screw... -
Page 10: Installation
Installation Product Overview Front View PT1975R/PT1911MX/PT1975S Bottom View (Without Stand) -
Page 11: Kensington Security Slot
Kensington Security Slot The monitor can be secured to your desk or any other fixed object with Kensington lock security products. The Kensington lock is not included. -
Page 12: Vesa Mount Your Monitor
The VESA mounting interface is located on the back of your monitor. To mount the monitor on a UL certified swing arm or other mounting fixture, follow the instructions included with the mounting fixture to be used. -
Page 13: Start Your Installation
Start Your Installation 1. Lay the LCD flat on an even surface. 2. Remove the stand back cover by pulling in the direction of the arrow as seen in step 2 diagram. 3. Move the stand into position as seen in step 3 diagram. 4. - Page 14 5 diagram. 6. Using a Philips Head screwdriver, insert the screw (CBM M3x6) into the cable cover and monitor as seen in the step 6 diagram. 7. Re-attach the stand back cover to the LCD stand by pressing firmly until the tabs snap into place as seen in the step 7 diagram.
-
Page 15: Remove The Deskstand
Remove the Deskstand Remove stand back cover. Remove hinge cover Remove 4 screws and then remove hinge. -
Page 16: Connecting The Display (Figure 11.1)
To setup this display, please refer to the following figure and procedures. 1. Be sure all equipment is turned off. 2. Connect the AC power cord to the power connector on the monitor and the other end into an electrical outlet (11.1). - Page 17 Figure 11.1...
-
Page 18: User Controls
User Controls Side Panel Controls Menu off status Menu on status Menu appear Menu disappear / return to main item Brightness Main item select up / Adjust up Mute Main item select down / Adjust down Enter / Select sub-item function Power On / Off... -
Page 19: How To Use The Osd Menus
6. To Lock the OSD / Power menu buttons, please follow the instructions below. (Please note: the monitor has to be turned ON with a valid signal preset) (a.) Press “Menu” key , the OSD menu will pops upon display. - Page 20 When the OSD Lock function is selected, this indicates that all the buttons except “power” button are now disabled. b. When the Power Lock function is selected, this indicates that the power key is disabled; user can not to turn off the monitor by “Power” key.
-
Page 21: On-Screen Display Menus
Factory Reset Volume Mute CONTENT The monitor luminance level control. The monitor backlight level control. Fine-tune the image to full screen automatically. Moving screen image horizontal position to left or right. Moving screen image vertical position to up or down. -
Page 22: Appendix
Appendix Troubleshooting If you are experiencing trouble with the LCD display, refer to the following. If the problem persists, please contact your local dealer or our service center. Problem: No image appears on screen. Check that all the I/O and power connectors are correctly and well connected as described in the “Installation”... -
Page 23: Warning Signal
The LCD display is under the power saving mode. In addition, the LCD display will enter power saving mode when experiencing a sudden signal disconnecting problem. The monitor can be activated by pressing any keyboard, triggering the mouse or touching the screen. Out of Range This message means that the signal of the computer graphic card is not compatible with the LCD display. -
Page 24: Product Dimensions
Product Dimensions... -
Page 25: Compatibility Modes
Compatibility Modes Mode IBM VGA IBM VGA VESA VGA VESA VGA VESA SVGA VESA SVGA VESA SVGA VESA SVGA VESA XGA VESA XGA VESA XGA VESA SXGA VESA SXGA Apple Mac II Apple Mac H. Frequency Resolution (kHz) 720 x 400 31.47 640 x 480 31.47... -
Page 26: Touch Screen Driver Installation
Touch Screen Driver Installation The PT1975R/PT1911MX/PT1975S is available with both RS232 and USB connections. The touch driver is located on the enclosed CD-ROM for these operating systems: Windows CE, XP Embedded, Linux, Apple Please Note: The PT1975R/PT1911MX/PT1975S is Microsoft (Human Interface Device) compatible if you use the USB touch screen interface. - Page 27 Choose to be either in the HID Mouse Mode or HID Digitizer Mode (Windows Simply click the “Apply” button once the settings are finalized. PT19075R/PT1911MX/PT1975S Install Instructions: If you are using a PC running Windows NT4.0, follow the instructions below: 1.
- Page 28 4. Connect the computer to the Touch Interface (RS-232 or USB) that you would like to use. 5. Load the Touch Driver CD, then follow the step-by-step instructions as show on monitor. PLEASE NOTE! Don’t plug in both the RS-232 and USB cables! Doing so may cause a driver conflict, making your touch screen inoperable.
-
Page 29: Product Registration And Technical Support
Product Registration and Technical Support Register Your Planar Products Today Thank you for choosing Planar. To assure you receive all the benefits of your Planar product and services, register your Planar product today. Visit our website to register your product at http://www.planar.com/support/product_registration.html. - Page 30 Tel: 1-866-PLANAR1 (866-752-6271) or +1 503-748-5799 outside the United States. Hours: 24 hours a day, 7 days a week © 2010 Planar Systems, Inc. 5/10 Planar is a registered trademark of Planar Systems, Inc. Other brands and names are the property of their respective owners.
