- Page 1 V-150VF SUMP PUMP WITH VERTICAL FLOAT INSTALLATION MANUAL...
- Page 2 A smooth day is a good day. THANK YOU That’s why Vada is dedicated Thank you for purchasing the Sump Pump with Vertical Float V-150VF! to creating pump solutions Record the product details here and leave with the owner. that you can count on. With...
-
Page 3: Know Your Product
PIT SIZE 10m Power cable HELPFUL HINT The Vada Sump Pump with Vertical Float V150-VF is designed for small spaces. It requires a minimum Vertical float with automatic pit size 300mm (L) x 300mm (W) x 400mm (H). switch operation If your pit is tapered, ensure the float can be fully engaged without getting caught on the pit wall. -
Page 4: Preparing For Installation
Teflon tape Hose clamps Cable ties Discharge hose … … … … (hard or flexible) The Vada Sump Pump with Vertical Float V150-VF is not suitable for the following applications: Pumping of Pumping Pumping Pumping Pumping blackwater liquids aggressive or... -
Page 5: Part 1: Pump Location
1. Wrap a hex nipple in Teflon and fit it to the tank outlet (or similar). ii. Fit the barrel union to the check valve to facilitate easy removal if needed. VADA SUMP PUMP WITH VERTICAL FLOAT V-150VF INSTALLATION MANUAL... -
Page 6: Part 3: Electrical Set Up
– RCD (also known as an Electrical Leakage Circuit breaker – ELCB) with a maximum rated residual current of 30mA. 2. Ensure the powerpoint is in a dry and flood free location. VADA SUMP PUMP WITH VERTICAL FLOAT V-150VF INSTALLATION MANUAL... -
Page 7: Operation
Turn the power on at the power point. Under normal conditions, the Vada V-150VF Sump Pump with Vertical Float requires low maintenance and is simple to service. To avoid possible failures, we recommend... -
Page 8: Storing The Pump
(l/min). Pump curves can be interpreted by tracing your finger along the Head (Metres) across to Flow (litres per minute). In the pump curve below, you can see that if the Vada Sump Pump with Vertical Float (V150-VF) has a discharge head between 4.3–3.2m (43–32kpa), then the pump will produce between 64–96 l/min, and will operate in the optimum operating range. -
Page 9: Troubleshooting
There is not enough Wait until there is enough water in the pit. water to start the Ensure the float switch is operating freely. Sump Pump When water is present, the pump will function. VADA SUMP PUMP WITH VERTICAL FLOAT V-150VF INSTALLATION MANUAL... -
Page 10: Warranty Conditions
Replaced items become Reece’s property. • The Vada V-150VF is correctly sized for your application. All replacement products will be available for collection without charge to the customer •...
