Page 1
Model No. Indoor Unit Outdoor Unit CS-RE9PKR CU-RE9PKR CS-RE12PKR CU-RE12PKR Operating Instructions Air Conditioner Thank you for purchasing Panasonic Air Conditioner. Installation instructions attached. Before operating the unit, read these operating instructions thoroughly and keep them for future reference. F569730...
Page 2
Quick guide Inserting the batteries 1 Pull out the back cover of remote control 2 Insert AAA or R03 batteries (can be used ~ 1 year) 3 Close the cover Clock setting 1 Press CLOCK 2 Set the time 3 ConÞ rm Basic operation 1 Select the desired mode AUTO...
Safety precautions To prevent personal injury, injury to others or property damage, please comply with the following: WARNING Incorrect operation due to failure to follow instructions below may cause harm or damage, the seriousness of which is classiÞ ed as below: Indoor unit and outdoor unit This appliance is not intended for use by persons This sign warns of...
Page 5
To prevent overheating, Þ re or electric shock: Do not use for preservation of precise equipment, • Do not share the same power outlet with other food, animals, plants, artwork or other objects. equipment. This may cause quality deterioration, etc. •...
How to use To select operation mode MODE AUTO - For your convenience HEAT - To enjoy warm air COOL - To enjoy cool air Remote control receiver Remote control and indicator - To dehumidify the environment display (Green) - To circulate air in the room POWER (Orange) TIMER...
Page 7
To save electrical power To set the timer ECONOMY consumption 2 sets of ON and OFF timers are available to turn ON or OFF the unit at different preset times. QUIET/ECONOMY • Save power consumption at unoccupied room by adjust set temperature up to 3°C automatically.
To learn more... Operation mode AUTO : During operation mode selection the POWER indicator blinks. * Unit selects operation mode during startup according to setting temperature and room temperature. HEAT : Unit takes a while to warm up. The POWER indicator blinks during this operation. COOL : Use curtains to screen off sunlight and outdoor heat to reduce power consumption during COOL mode.
Cleaning instructions To ensure optimal performance of the unit, Indoor unit cleaning has to be carried out at regular Front panel Aluminium Þ n intervals. Dirty unit may cause malfunction and you may see error code “H99”. Please consult authorised dealer. •...
Troubleshooting The following symptoms do not indicate malfunction. Symptom Cause Mist emerges from indoor unit. • Condensation effect due to cooling process. Water ß owing sound during operation. • Refrigerant ß ow inside the unit. The room has a peculiar odour. •...
Information Information for Users on Collection and Disposal of Old Equipment and used Batteries [Information on Disposal in other Countries outside the European Union] These symbols are only valid in the European Union. If you wish to discard these items, please contact your local authorities or dealer and ask for the correct method of disposal.
