MTD BOLENS BL150 Operator's Manual

Quick Instructions to
Assemble Straight
Shaft String
Trimmers
for complete instructions, refer to the
Assembly Instructions section of this
manual.
Quick Instructions
to Start Engine
for complete instructions refer to
Starting/ Stopping Instructions section
of this manual.
Quick Instructions to
®
Replace SplitLine
Trimmer Line
®
Replacement SplitLine
Part #610375
For single line installation,
refer to Line Installation
section of this manual.
For replacement spool
installation, refer to Installing a
Prewound Reel section of this manual.
Wind line tightly in direction of arrow.
Split other end of SplitLine
IMPORTANT: READ OPERATOR'S MANUAL THOROUGHLY AND FOLLOW THE SAFE OPERATION PRACTICES BEFORE OPERATING THE UNIT.
NEED HELP?
PART NO. 769-04515 P00
Operator's Manual
Read and understand all instruction, warning and danger labels on the unit.
Place the shield onto the mount bracket.
Screw the 2 shield screws through the 2
holes on the mount bracket and into the
shield. Tighten.
Press primer bulb 10 times.
Move blue choke
lever to Position 2.
Push 6"-7" ends into
®
back 6"-7". 0.095" holding slots.
CALL 1–800–800-7310 IN U.S. OR 1–800–668–1238 IN CANADA
DO NOT RETURN THIS PRODUCT
For Assistance please call 1-800-800-7310 (U.S.) or 1-800-668-1238 (Canada)
or visit www.mtdproducts.com or www.mtdproducts.ca
Min. 6"
Put D-handle on shaft. Move handle
a minimum 6 inches away from
shaft grip. Insert clamp bolt and
tighten the wing nut.
Put blue choke lever Crouch in starting
in Position 1. position.
Pull the rope 3 to 5 While continuing to
times to start. Run squeeze the throttle
engine for 30-60 control, move the blue
seconds to warm up. choke lever to Position 3.
Spool
Spring
Inner
Reel
Bump
Knob
Unscrew Bump Knob™ Insert 10' of 0.095"SplitLine
counterclockwise. Remove hole in top of reel. Pull most of line
through hole until 3"-4" remains.
inner reel and spring.
Insert lines through eyelets in spool.
Insert spring and reel into spool.
BL150
2-Cycle Trimmer
40:1
1 Gallon
Mix thoroughly in a separate fuel can:
– 3.2 fl. oz. of 2-cycle engine oil
– 1 gallon of unleaded gasoline
Place the unit on a level surface. Fill fuel tank.
NOTE: Do not mix directly in the engine fuel tank.
SQUEEZE and HOLD throttle
Pull the rope
control for ALL further steps.
5 times.
DIDN'T START?
Repeat these instructions.
If engine still fails to start, refer
to the Starting/ Stopping
instructions section of this
Continue warming for an
manual for additional starting
additional 60 seconds.
and troubleshooting information.
During this time the unit
may be used.
3"-4"
®
through Bend short end and push it
into the other hole. Pull tight.
Hold the inner reel in place. Pull lines firmly to release
Tighten Bump Knob clockwise. from holding slots.
3.2 oz
5 X
