Last Modified: 5-3-2010
Model Year: 2010
Title: HYBRID / BATTERY CONTROL: HYBRID CONTROL SYSTEM: P0AA6-526,P0AA6-611,P0AA6-612,P0AA6-
613,P0AA6-614: Hybrid Battery Voltage System Isolation Fault (2010 Prius)
P0AA6-
DTC
526
P0AA6-
DTC
611
P0AA6-
DTC
612
P0AA6-
DTC
613
P0AA6-
DTC
614
DESCRIPTION
The power management control ECU monitors the battery smart unit and detects insulation malfunctions in the high-
voltage system.
DTC
INF
NO.
CODE
Insulation resistance between the high-voltage circuit and
P0AA6
526(*1)
the body has decreased.
6.4 C
Model: Prius
Hybrid Battery Voltage System Isolation Fault
Hybrid Battery Voltage System Isolation Fault
Hybrid Battery Voltage System Isolation Fault
Hybrid Battery Voltage System Isolation Fault
Hybrid Battery Voltage System Isolation Fault
DTC DETECTION CONDITION
From: 200904
Doc ID: RM000000OMD01IX
TROUBLE AREA
Hybrid vehicle transaxle
assembly
Motor cable
Generator cable
Inverter with converter
assembly
Frame wire
No. 2 engine wire
Hybrid battery junction
block
Compressor with motor
assembly
HV battery
Battery smart unit
