FERREX BTS920 User Manual

Belt & disc sander 450w
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ALDI guarantees that our exclusive brand products are developed to our
stringent quality specifications. If you are not entirely satisfied with this
product, please return it to the nearest ALDI store within 60 days from the
date of purchase, for a full refund or replacement, or take advantage of our
after sales support by calling the supplier's Customer Service Hotline.
AU
Made in China
FERREX
is a registered trademark of ALDI Stores
®
DISTRIBUTED BY:
ALDI STORES
1 SARGENTS ROAD
MINCHINBURY NSW 2770
www.aldi.com.au
AFTER SALES SUPPORT
1300 855 831
AU
support@scheppach.com.au
MODEL:
BTS920
10699
05/2021
5
YEAR
WARRANTY

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BTS920 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for FERREX BTS920

Summary of Contents for FERREX BTS920

  • Page 1 Customer Service Hotline. Made in China FERREX is a registered trademark of ALDI Stores ® DISTRIBUTED BY: ALDI STORES 1 SARGENTS ROAD MINCHINBURY NSW 2770 www.aldi.com.au AFTER SALES SUPPORT 10699 1300 855 831 support@scheppach.com.au YEAR MODEL: WARRANTY BTS920 05/2021...
  • Page 2 User Manual BELT & DISC SANDER 450W BTS920...

  • Page 3: Table Of Contents

    Contents Overview ..................3 Package contents/part list ............6 Explanation of Symbols .............. 7 Introduction ................9 Layout ..................10 Scope of delivery ................10 Intended use ................10 Safety regulations ..............11 Assembly ..................16 Operation ..................17 After Use ..................20 Technical data ................21 Storage and transport ..............
  • Page 4 12.1 12.2...

  • Page 5: Overview

    6 13 6 13...

  • Page 7: Package Contents/Part List

    Package contents/part list Sanding Belt, 1x Belt adjustment knob, 1x Belt unlocking lever, 1x Tool rest, 1x ON- / OFF switch, 1x Clamping screw, 1x Table, 1x Mitre gauge, 1x Sanding disc, 1x Allen screw with disc, 2x Support screw,1 x 12.1 Dust outlet for sanding belt, 1x 12.2...

  • Page 9: Explanation Of Symbols

    Explanation of symbols Kapitelüberschrift Explanation of Symbols The use of symbols in this manual is intended to draw your attention to possible risks. The safety symbols and the explanations that accompany them must be perfectly un- derstood. The warnings in themselves do not remove the risks and cannot replace correct actions for preventing accidents.
  • Page 10 Kapitelüberschrift Explanation of symbols These operating instructions provide places concerning m Attention! your safety which are marked with this indication. Failure to follow these instructions may cause light to m Caution! medium risk of injury. Failure to follow these instructions may cause danger to m Warning! life or danger of serious injuries!

  • Page 11: Introduction

    Introduction Introduction Congratulations on choosing to buy a FERREX product. ® All products brought to you by FERREX are manufactured to the highest standards ® of performance and safety, and as part of our philosophy of customer service and satisfaction, are backed by our comprehensive 5 Year Warranty.

  • Page 12: Layout

    Layout/Scope of delivery/Intended use If possible, keep the packaging • Layout (Fig. 1) until the end of the guarantee period. Sanding belt Read the operating instructions • Belt adjustment knob fully to familiarise yourself with Belt unlocking lever the tool prior to using it. 4.

  • Page 13: Safety Regulations

    Intended use/Safety regulations trained persons who are familiar with the machine and have been informed about the dangers. Unauthorized modifications of the machine exclude a liability of the manufacturer for damages resulting from the modifications. • The machine is intended for use only with original spare parts and original tools from the producer.
  • Page 14 Safety regulations tric shock. • Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded. • Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock.
  • Page 15 Safety regulations • Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations. • Dress properly. Do not wear loose clothing or jewellery. Keep your hair and clothing away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
  • Page 16 Safety regulations • Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control. • Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into account the working conditions and the work to be performed.
  • Page 17 Safety regulations • If the machine tends to tilt or walk (especially when sanding long and heavy panels), it must be fastened to a solid surface of sufficient carry- ing force. • Make sure the sanding belt runs in the correct direction – see arrows at the back of the belt.

  • Page 18: Assembly

    Safety regulations/Assembly • Switch the machine off and pull the power plug from the socket when fitting or removing accessories. • Never leave the working area of the sanding machine while the tool is running, or as long as it has not come to an absolute standstill. Residual risks The machine has been built using modern technology and in accordance with recognized safety rules.

  • Page 19: Operation

    Assembly/Operation 2. Attach the tool rest (4) to the housing of the sanding belt (1) and secure it with the allen screw with disc (10) and the allen key (14). (Fig. 5) 3. The maximum distance between sanding belt (1) and tool rest (4) must be 1.6mm. Option 2: 1.
  • Page 20 Operation Turn the ON-/ OFF switch (5) ON and then immediately turn it OFF. If the sanding • belt (1) tends to slide off the idler drum or drive drum, the sanding belt (1) is not tracking properly. To adjust sanding belt tracking: Turn the belt adjustment knob (2) clockwise to adjust the sanding belt (1) to the left direction.
  • Page 21 Operation Sanding with the sanding disc (Fig. 12) Hold the workpiece (C) firmly, keeping fingers away from the sanding disc. 2. Only work with the sanding disc (9) in combination with the table (7). Note: Use extra caution when sanding very thin pieces and when sanding extra long pieces.

  • Page 22: After Use

    After Use After Use m WARNING! Prior to any adjustment, maintenance or service work switch off the machine and disconnect the mains power plug! Cleaning Keep all safety devices, air vents and the motor housing free of dirt and dust as •...

  • Page 23: Technical Data

    Technical data Technical data Dimensions L x W x H 560 x 270 x 530 mm Sanding disc ø 150 mm Idle speed n / Disc speed n 2980 rpm Belt dimensions 100 x 914 mm Belt speed 550 m/min Belt tilt 0°...

  • Page 24: Storage And Transport

    Technical Data/Storage and transport/Electrical connection Have the appliance serviced whenever necessary. • Switch the appliance off when it is not in use. • Wear protective gloves. • Storage and transport Store the machine and accessories out of children’s reach in a dark and dry place at above freezing temperature.

  • Page 25: Disposal And Recycling

    Electrical connection/Disposal and recycling Kapitelüberschrift The device may only be operated from an outlet with the properly installed earth- ing contact. AC motor • The mains voltage must be 230 - 240 V~ • Extension cables up to 25 m long must have a cross-section of 1.5 mm Connections and repairs of electrical machines may only be carried out by an elec- trician.

  • Page 26: Troubleshooting

    Kapitelüberschrift Troubleshooting Troubleshooting The table below contains a list of fault symptoms and explains what you can do to remedy the problem if your equipment fails to work properly. If the problem still persists after working through the list, please contact your nearest service workshop.

  • Page 27: Warranty Details

    Belt & Disc Sander 450W Warranty Details TO KEEP UP-TO-DATE WITH IMPORTANT PRODUCT INFORMATION The product is guaranteed to be free from defects in workmanship and parts for a period of 60 months from the date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion.

  • Page 28: Repair And Refurbished Goods Or Parts Notice

    Belt & Disc Sander 450W Repair and Refurbished Goods or Parts Notice TO KEEP UP-TO-DATE WITH IMPORTANT PRODUCT INFORMATION Unfortunately, from time to time, faulty products are manufactured which need to be returned to the Supplier for repair. Please be aware that if your product is capable of retaining user-generated data (such as files stored on a computer hard drive, telephone numbers stored on a mobile telephone, songs stored on a portable media player, games saved on a games console or files stored on a USB memory stick) during the process of repair, some or all of your stored data may be lost. ...
