EN
1D60
WIFI camera with solar panel
Dear customer, thank you for purchasing our product. Please read the following
instructions carefully and follow them to serve you safely and to your full satisfaction. This
will prevent misuse or damage. Avoid unprofessional handling of this appliance and always
observe the electrical appliance usage guidelines. Keep the instruction manual carefully.
DESCRIPTION
Solar panel
Infrared and white LED
PIR sensor
Camera
Ambient sensor
Microphone
LED indicator
Reset/AP switch
SD card slot
Speaker
Power button
USB input (charging)
Attachment to the holder

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1D60 and is the answer not in the manual?

Questions and answers

Summary of Contents for Solight 1D60

  • Page 1 1D60 WIFI camera with solar panel Dear customer, thank you for purchasing our product. Please read the following instructions carefully and follow them to serve you safely and to your full satisfaction. This will prevent misuse or damage. Avoid unprofessional handling of this appliance and always observe the electrical appliance usage guidelines.
  • Page 2: Packaging Content

    FEATURES Power button: Switch the button to the left to turn the device on, switch it to the right to turn it off. Indicator light: Blue indicates that the camera is connected to the Internet, red indicates that the connection to the Internet has failed. PIR sensor: the camera will start working if motion is detected.
  • Page 3: Using The Mobile App

    PIR SENSOR LOCATION Install the camera so that the angle between the sensor and the detected object is greater than 10°. If a moving object approaches the PIR sensor perpendicularly, the sensor may not detect motion correctly Path of the tracked Remark: object - PIR sensor detects motion at approx.
  • Page 4 Open the mobile app and click "Add Device", select "Camera and Lock", then Camera (Wi- Fi) and follow the instructions. For a video tutorial with more information on how to connect the camera and the application itself, please visit www.youtube.com under the title "Solight 1D60 - Application Instructions"...
  • Page 5: Camera Interface

    CAMERA INTERFACE Configuratio Full screen view Back Microphone on/off Transfer rate Battery status; HD - SD picture quality change Camera image TECHNICAL PARAMETERS Powered by rechargeable battery and solar panel. 1080P Full HD 2Mpx image and video quality. Day and night mode that switches automatically. High-quality, real-time, bi-directional audio transmission with noise cancellation.
  • Page 6 Sensor 1/2.9" CMOS colour sensor, 2 MPx Sensor Angle of view 100° Two-way voice intercom capability (built-in Audio Input/output microphone and speaker) Compression methods H.265 (H.264, H.265 support) Image frame rate 25 frames per second Maximum image resolution 1920*1080P Video IR double optical filter with automatic Light source for night vision switching, 4pcs 850nm LED and white light, IR...
  • Page 7 This product complies with all the essential requirements of the EU Directives that apply to it. The product has been issued with a CE declaration of conformity in accordance with the applicable regulations. On request from the manufacturer: info@solight.cz, or downloadable from www.solight.cz Solight Holding, s.r.o., Na Brně...
