EN
FP03
HD Photopast
DESCRIPTION OF EQUIPMENT
1. MENU button
2. Left arrow
3. PLAY button
4. OK button
5. Right arrow
6. SHOT button
7. ON switch position
8. SETUP switch position
9. OFF switch position
10. USB connector
11. Speaker
12. AV connector
13. DC connector
14. SD slot
15. AA batteries
14
1 EN
15
1
2
3
7 8 9
10 11 12 13
4
5
6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FP03 and is the answer not in the manual?

Questions and answers

Related Manuals for Solight FP03

Summary of Contents for Solight FP03

  • Page 1 FP03 HD Photopast DESCRIPTION OF EQUIPMENT 1. MENU button 2. Left arrow 3. PLAY button 4. OK button 5. Right arrow 6. SHOT button 7. ON switch position 8. SETUP switch position 9. OFF switch position 10. USB connector 11. Speaker 7 8 9 12.

  • Page 2: Insertion Of Batteries

    INSERTION OF BATTERIES Remove the battery compartment cover and insert four 1.5V AA batteries into the battery compartment. When inserting, make sure to observe the correct polarity, which is marked on the bottom of the battery compartment. Replace the cover. When replacing, first remove the dead batteries and then insert the new ones.
  • Page 3 The photo trap supports high-speed SD cards class 10 and higher. Format the SD card before use. Regular use, as well as improper use, will shorten the life of the SD card and may cause data corruption. If the SD card is damaged, replace it. USE OF PHOTO TRAPS A slide switch is used for basic control of the photo trap.
  • Page 4 Settings item Option Description Select the photo trap mode. Photo Mode Video (Mode) Photo + video 24 MP (6528x3672) The higher the resolution, Photo resolution the higher the quality of the 20 MP (6144 x 3456) (Photo resolution) photo, but the larger the file 16 MP (5376 x 3024) and the more space it takes 12 MP (4608 x 2592)
  • Page 5 Settings item Option Description From 3 seconds to 10 We recommend setting the Video length video length to 10 seconds. minutes (Video length) The longer the upload time, the more power is consumed and the file takes up more space in the SD card memory.
  • Page 6 Settings item Option Description Low (low) Medium PIR sensor sensitivity is Sensitivity motion sensors (medium) High dependent on the (Sensor sensitivity) (high) ambient temperature. The "HIGH" setting is more suitable at higher temperatures. The "ME- DIUM/LOW" setting is suitable for lower temperatures.
  • Page 7 Settings item Option Description ON - on OFF - Select "ON" and the photo Time Lapse trap will automatically take (Time-lapse) photos/videos according to the set interval. This setting is particularly suitable for recording cold-blooded animals (e.g. snakes) or for recording plant growth.
  • Page 8 Settings item Option Description 1. Set the clock and 1. Setting the clock: use the Time & Date date. left/right arrow keys to (Time and date) set the clock and date. 2. Set the clock format. 2. Clock format: select 24- 3.
  • Page 9 Settings item Option Description ON - password must be You can set a 4-digit input Password protection password of the digits 0-9 (Password protection) OFF - settings will be and the letters A-Z to prevent unwanted access to without password the photo trap settings.
  • Page 10 Settings item Option Description Yes - yes, the memory card Formatting will delete all files Format memory card will be formatted. No - it on the tab. won't. Note: Before using the SD card for the first time, format it. ON - on OFF - Set the 4-digit photocell Serial NO...

  • Page 11: Night Mode

    SELECTION OF THE INSTALLATION LOCATION OF THE PHOTO TRAP Verify that the photo trap is effectively recording the selected area. Set the switch to the "SETUP" position. In the selected area, try different distances and angles so that you can move around the area around the photo trap repeatedly.
  • Page 12 the photo trap, the photo or footage will be overexposed. VIDEO AND DATA TRANSMISSION Connecting to TV Play the video footage on a connected TV. Switch on the TV and connect the photo trap to the TV via the AV cable. Once connected, the display of the photo trap will switch to power saving mode and the files can be played on the TV display.

  • Page 13: Technical Parameters

    TECHNICAL PARAMETERS 2" Display size 2 MP Camera FOV=90 Lentils Photo resolution 20 MP, 16 MP, 12 MP, 8 MP, 5 MP, 3 MP, 1 MP 1080P, 720P, 480P, VGA Video resolution Video format JPEG Photo format Language menu English (English), German (German), French (French), Italian (Italian), Spanish (Spanish), Czech (Czech) SD card up to 32 GB...

  • Page 14: Problem Solving

    4x 1.5 V type AA Batteries Built-in microphone Microphone Built-in speaker Speaker -20 °C to +60 °C Operating temperature -30 °C to +65 °C Storage temperature About 192 g Weight 110 x 90 x 60 mm Dimensions CLEANING The photo trap is designed for use outdoors and in nature, but it is not indestructible and must be kept relatively clean.
  • Page 15 The photo trap is not Check the installation site installed in the right place. and relocate it if necessary. The photo trap didn't turn on. The batteries are incorrectly Check the polarity of the inserted or discharged. inserted batteries replace them if necessary. The SD card is defective.
  • Page 16 EU Directives that apply to it. The product has been issued with a CE declaration of conformity in accordance with the applicable regulations. On request from the manufacturer: info@solight.cz, or downloadable from www.solight.cz. Solight Holding, s.r.o., Na Brně 1972, Hradec...
