Watchguard Firebox T45-PoE Hardware Manual

Hide thumbs Also See for Firebox T45-PoE:
Table of Contents

Advertisement

Quick Links

Download this manual
®
Firebox
T45-PoE
Hardware Guide
T45-PoE, T45-W-PoE
®
Firebox
BS4AE5P, BS4AE5PW

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Firebox T45-PoE and is the answer not in the manual?

Questions and answers

Related Manuals for Watchguard Firebox T45-PoE

Summary of Contents for Watchguard Firebox T45-PoE

  • Page 1 ® Firebox T45-PoE Hardware Guide T45-PoE, T45-W-PoE ® Firebox BS4AE5P, BS4AE5PW...
  • Page 2 WatchGuard Technologies, Inc.
  • Page 3 Guide revised: 10/27/2022 Copyright, Trademark, and Patent Information Copyright © 1998 – 2022 WatchGuard Technologies, Inc. All rights reserved. All trademarks or trade names mentioned herein, if any, are the property of their respective owners. Complete copyright, trademark, patent, and licensing information can be found in the Copyright and Licensing Guide, available online at https://www.watchguard.com/wgrd-help/documentation/overview.

  • Page 4: Table Of Contents

    Contents Firebox T45-PoE Hardware Guide Fireware OS Package Contents About Your Hardware Hardware Specifications Interface Specifications Environmental Requirements Hardware Description Front Rear AC Power Adapter Rack Mount Installation for Firebox T25 and T45 Precautions Wall Mount Installation Restore Factory-Default Settings...
  • Page 5 Avertissement: For Mobile Device Usage (Wireless) Radiation Exposure Statement Déclaration d’exposition aux radiations: France (Wireless) Japan VCCI Notice (Class A ITE) Taiwan RoHS Taiwan Class A Notice Taiwan NCC Mexico Notice Limited Hardware Warranty Declaration of Conformity WatchGuard Technologies, Inc.

  • Page 6: Firebox T45-Poe Hardware Guide

    The Firebox T45-PoE supports up to 20 users and delivers improved performance plus relentless security to provide both the speed and protection needed for any small business, retail location and more, to stay connected and run their business.

  • Page 7: About Your Hardware

    Firebox T45-PoE Hardware Guide About Your Hardware Hardware Specifications NXP LS1043ASE7QQB, 1.6GHz, 4-Core Processor Memory DDR4 4GB Storage M.2 SSD 16GB Input Ratings: 100-240V AC, MAX 1.2A, 50-60Hz Power Supply Output: 54V DC D = 205.5 mm (8") Dimensions W = 217 mm (8.5") H = 42 mm (1.65")

  • Page 8: Environmental Requirements

    Firebox T45-PoE Hardware Guide Environmental Requirements To safely install your Firebox, we recommend that you: Install it indoors. Put it in a secure area, such as a locked room, to block the device from people who do not have permission to use it.

  • Page 9: Hardware Description

    Firebox T45-PoE Hardware Guide Hardware Description Front Front view of the Firebox: Failover The Failover indicator is lit when there is a WAN failover from the primary external interface to the backup interface. After the external interface connection fails back to the primary external interface, the indicator is not lit.
  • Page 10 The Status indicator is lit when there is a management connection to the device. The Status indicator is lit for 30 seconds after you connect to the device with the Fireware Web UI or the command line interface. It is also lit when the device is polled by WatchGuard System Manager. Mode The Mode indicator shows the status of the external network connection.

  • Page 11: Rear

    The Ethernet interfaces have standard RJ45 connectors and support link speeds of 10, 100, or 1000 Mbps. The Firebox T45-PoE has five network interfaces. These interfaces are labeled 0/WAN, 1/LAN, 2, 3, 4/PoE+. Interface 4 is a PoE+ (Power over Ethernet) interface, compliant with the IEEE 802.3at standard.

  • Page 12: Ac Power Adapter

    With the internal silver connector exposed, continue to pull to disconnect the cord. The Firebox T45-PoE includes a power cable to connect to the AC power adapter. The suffix on the Firebox SKU indicates the type of power plug included with the device. Note that the suffix is not restrictive –...
  • Page 13 Firebox T45-PoE Hardware Guide Plug SKU Suffix Type Used in regions Photo US, Canada, Japan, Taiwan, Central America, Some countries in South America, Philippines United Kingdom, Ireland, Hong Kong, Singapore, Malaysia, some African countries Europe, Middle East, Korea, Indonesia, some African countries China, Australia, New Zealand WatchGuard Technologies, Inc.

  • Page 14: Rack Mount Installation For Firebox T25 And T45

    Firebox T45-PoE Hardware Guide Rack Mount Installation for Firebox T25 and T45 The optional rack mount installation kit (available separately) enables you to install a rack mount bracket on the front or rear of the Firebox for installation in a network rack. The bracket also includes a shelf for the Firebox power adapter.

  • Page 15: Precautions

    Firebox T45-PoE Hardware Guide 4. Insert the power connector from the power adapter into the Firebox power input. 5. Insert the power plug from the power adapter into a power source. Precautions Do not place other devices directly on the Firebox, or use the Firebox as a shelf or work space.

  • Page 16: Wall Mount Installation

    Firebox T45-PoE Hardware Guide Wall Mount Installation The optional wall mount plate (available separately) enables you to mount the Firebox on a wall in a good location to increase the wireless range. You need four screws 1/8" (3 mm) wide and at least 3/4" (18 mm) long to install the mount plate.

  • Page 17: Notices

    警 示 本電 池 如 果 更換 不 正 確 會有 爆 炸 的 危險 ， 請 勿 自 行更 換 電 池 Disclaimer WatchGuard shall not be held liable if the end user alters, modifies, or repairs any WatchGuard hardware appliance.

  • Page 18: Sicherheitshinweis

    Sicherheitshinweise. Aviso De Seguridad Todos los productos WatchGuard están diseñados y probados para satisfacer estrictos requisitos de seguridad. Estos requisitos incluyen la homologación de productos de seguridad y otras normas de cumplimiento global. Por favor, lea atentamente las siguientes instrucciones antes de utilizar el producto, y se refieren a ellos como sea necesario para garantizar el funcionamiento seguro y continuo de su producto.

  • Page 19: Federal Communications Commission Interference Statement

    Europe – EU Declaration of Conformity (Wireless) This device complies with the essential requirements of the RED 2014/53/EU. The following test methods have been applied in order to prove presumption of conformity with the essential requirements of the RED 2014/53/EU: WatchGuard Technologies, Inc.

  • Page 20: Ce Notice

    France. CE Notice symbol on your WatchGuard Technologies equipment indicates that it is in compliance with the Electromagnetic Compatibility (EMC) directive and the Low Voltage Directive (LVD) of the European Union (EU).

  • Page 21: Weee Statement

    WEEE statutes, and that the recovery of our product per the specific EU country legislative requirements is seamless for our product’s end users. If you have a WatchGuard product that is at its end of life and needs to be disposed of, please contact WatchGuard Customer Care Department at: U.S.

  • Page 22: Industry Canada Statement

    France (Wireless) Les dispositifs fonctionnant dans la bande 5150-5250 MHz est réservé à une utilisation en intérieur pour réduire le risque de brouillage préjudiciable aux systèmes mobiles par satellite utilisant les mêmes canaux; propia operación no deseada. WatchGuard Technologies, Inc.

  • Page 23: Japan Vcci Notice (Class A Ite)

    第 十 四條 低 功 率 射頻 電 機 之 使用 不 得 影 響飛 航 安 全 及干 擾 合 法 通信 ； 經 發 現 有干 擾 現 象 時 , 應 立 即 停 WatchGuard Technologies, Inc.

  • Page 24: Mexico Notice

    WatchGuard Technologies, Inc. (“WatchGuard”) and you agree as set forth below or on the reverse side of this card, as applicable. 1. LIMITED WARRANTY. WatchGuard warrants that upon delivery and for one (1) year thereafter (the “Warranty Period”): (a) the Product will be free from material defects in materials and workmanship,...
  • Page 25 Product shall not extend the Warranty Period. Any Product, component, part or other item replaced by WatchGuard becomes the property of WatchGuard. WatchGuard shall not be responsible for return of or damage to any software, firmware, information or data contained in, stored on, or integrated with any returned Products.
  • Page 26 OF THE ENTITY’S OBLIGATIONS UNDER THE WARRANTY DO NOT VIOLATE ANY THIRD- PARTY AGREEMENT TO WHICH THE ENTITY IS A PARTY. No change or modification of the Warranty will be valid unless it is in writing and is signed by WatchGuard. WatchGuard Technologies, Inc.

  • Page 27: Declaration Of Conformity

    Declaration of Conformity Declaration of Conformity WatchGuard Technologies, Inc.
