Advantage SENTRA SR Series Instruction Manual

Hide thumbs Also See for SENTRA SR Series:
Table of Contents

Advertisement

Quick Links

Download this manual
I.O.M. #197 updated : 04/03/2023
INSTRUCTION MANUAL
• INSTALLATION • OPERATION • MAINTENANCE
Units with the G300
Control Instrument
ADVANTAGE ENGINEERING, INC.
525 East Stop 18 Road Greenwood, IN 46142
317-887-0729 fax: 317-881-1277
Model:
Service Department fax: 317-885-8683
www.AdvantageEngineering.com
Serial Number :
sales@AdvantageEngineering.com

Advertisement

Table of Contents
loading

Related Manuals for Advantage SENTRA SR Series

Summary of Contents for Advantage SENTRA SR Series

  • Page 1 I.O.M. #197 updated : 04/03/2023 INSTRUCTION MANUAL • INSTALLATION • OPERATION • MAINTENANCE Units with the G300 Control Instrument ADVANTAGE ENGINEERING, INC. 525 East Stop 18 Road Greenwood, IN 46142 317-887-0729 fax: 317-881-1277 Model: Service Department fax: 317-885-8683 www.AdvantageEngineering.com Serial Number :...
  • Page 3 INSTRUCTION MANUAL SENTRA SR Series with G300 Control Instrument COVERING INSTALLATION OPERATION MAINTENANCE ADVANTAGE ENGINEERING, INC. 525 East Stop 18 Road Greenwood, IN 46142 317-887-0729 fax: 317-881-1277 Service Department fax: 317-885-8683 www.AdvantageEngineering.com E-mail: sales@AdvantageEngineering.com...

  • Page 4: Table Of Contents

    Sensor Probe Service Pressure Switch Service Electronic Instrument Repair Policy And Procedure Temperature Probe Calibration Heater Contactor and Pump Motor Starter Page: 4 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683www.AdvantageEngineering.com...
  • Page 5 Remote and Autostart Feature Configuration SPI Commands Communication Cable Optional Alarm Operation Standard G English Factory Default Settings Parts : #119 Pump Page: 5 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683 www.AdvantageEngineering.com...
  • Page 6 THIS PAGE INTENTIONALLY BLANK Page: 6...

  • Page 7: General

    Temperature Control Units : Sentra with G300 Series Instrument GENERAL Receiving Instructions Introduction Safety Water Treatment Components Page: 7 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683 www.AdvantageEngineering.com...

  • Page 8: Receiving Instructions

    Observe all warning and safety placards applied to the unit. Failure to observe all warnings can result in serious injury or death to the operator and severe mechanical damage to the unit. Page: 8 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277...
  • Page 9 Alerts the user to possible explosive danger. Alerts the user to a hot surface danger due to high operating temperatures. CAUTION Page: 9 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683 www.AdvantageEngineering.com...

  • Page 10: Water Treatment

    It is recommended that the services of a qualified water treatment specialist be engaged to determine what water treatment is required. Advantage assumes no responsibility for equipment failures which result from untreated or improperly treated water. Do not use deionized water in this unit. Some customized units may be compatible with deionized water.
  • Page 11 Galvanied Steel Base Casters for Portability (2” on units up to 3 hp & 16 kW, 3” on larger units) Page: 11 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683 www.AdvantageEngineering.com...
  • Page 12 THIS PAGE INTENTIONALLY BLANK Page: 12...

  • Page 13: Installation

    Temperature Control Units : Sentra with G300 Series Instrument INSTALLATION General To and From Process Connections Water Supply Connection Drain Connection Electrical Connection Page: 13 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683 www.AdvantageEngineering.com...

  • Page 14: General

    If installed, all such devices must be open and clean during unit operation. Page: 14 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277...

  • Page 15: Water Supply Connection

    The temperature difference between the unit set point and the cooling water temperature The cooling valve position Consult factory when selecting the correct cooling valve for your application. Page: 15 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683 www.AdvantageEngineering.com...

  • Page 16: Electrical Connection

    Models With Factory Included Disconnect Switch and Other Custom Features Some units may be customized and include a factory supplied power disconnect switch and/or higher specification electrical enclosure. Electrical power supply Page: 16 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277...
  • Page 17 Make certain no moisture or standing water is present inside the electrical cabinet. Page: 17 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683 www.AdvantageEngineering.com...
  • Page 18 Power Entry Transformer Fuse Blocks Pump Motor Controller Heater Contactor Control Transformer Bar Code Low Water Pressure Switch Typical Electrical Panel Page: 18 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683www.AdvantageEngineering.com...

  • Page 19: Start Up Sequence

    Instrument : Flow Menu (option) 3.12 Instrument : Options Menu 3.13 Instrument : Machine Menu 3.14 Shut Down / Disconnect 3.15 Page: 19 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683 www.AdvantageEngineering.com...

  • Page 20: General

    Entrained air in the system will adversely affect the unit’s ability to control process temperature and can cause heater failure when the heating elements are exposed to this air. Page: 20 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277...
  • Page 21 C. If the unit is phased incorrect, continue with step 2. To correct unit phase: Disengage the electrical power supply to the unit at the unit’s disconnect Page: 21 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277...
  • Page 22 This is done by opening the electrical panel cover and identifying the overload relay. WARNING: To correct phase ... switch power leads at the disconnect switch only. Page: 22 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277...
  • Page 23 If the amp draw is excessive (higher than the listed name plate amp rating), a throttling valve must be installed in the “from process” water Page: 23 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277...

  • Page 24: Instrument : Quick Start

    Adjust the valve for a minimum of 10 GPM. INSTRUMENT : QUICK START Arrow and Display Win- Power On Select Keys Button Power Off Button Page: 24 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683www.AdvantageEngineering.com...
  • Page 25 Features menu. Once the autovent sequence is complete the unit will heat or cool to maintain the setpoint temperature. Page: 25 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683 www.AdvantageEngineering.com...

  • Page 26: Instrument : Basic Navigation

    Prompts on Success Screens. Success screens appear once a value is changed and the new value is successfully saved. The screen shows the name of the parameter and Page: 26 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277...

  • Page 27: Instrment : Operating Screens

    100% to reduce process temperature to a safe shutdown temperature. The time and temperature of the pump seal cooling feature are programmed in the Feature Menu. Page: 27 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277...

  • Page 28: Instrument : Fault Screens

    Reverse any two power wires at the disconnect to correct phase. Do not reverse the unit’s internal wiring to correct a phase condition. Page: 28 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277...

  • Page 29: Instrument : Main Menu

    Once acknowledged, the unit will control to the new setpoint temperature. Press the Back button repeatedly to return to the Setpoints screen or press the home button to return to the Home screen. Page: 29 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277...
  • Page 30 Once acknowledged, press the Back button repeatedly to return to the Setpoints screen or press the home button to return to the Home screen. Page: 30 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277...

  • Page 31: Instrument : Utilities Menu

    When activated and supplied with compressed air, the mold or system purge system will expel process water from the mold to the drain. Advantage mold or system purge systems are supplied as a factory installed option or a field retrofitted kit.

  • Page 32: Instrument : Network Menu

    Press the Select button to select Protocol. Use the Up or Down arrow buttons to select the preferred protocol. Page: 32 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277...

  • Page 33: Instrument : Features Menu

    When the power button is pressed and the process temperature is below the “autovent” (factory default is 100°F) the controller will initiate the autovent cycle Page: 33 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683 www.AdvantageEngineering.com...
  • Page 34 WARNING: When the pump seal cooling feature is activated, pressing the stop button will not turn off the unit. To completely shut down the unit, press the Stop button twice. Page: 34 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683www.AdvantageEngineering.com...
  • Page 35 The range is 60°F - 100°F. The factory default is 100°F. Press the Select button to save the Pump Seal Temp and confirm success. Page: 35 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683 www.AdvantageEngineering.com...

  • Page 36: Instrument : Options Menu

    Once acknowledged, press the Back button repeatedly to return to the Options screen or press the home button to return to the Home screen. Page: 36 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277...

  • Page 37: Instrument : Machine Menu

    Use the Up or Down arrow keys to select the Unit display and then press the Select button to save and confirm success. The factory default value is English. Page: 37 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277...

  • Page 38: Shut Down - Disconnect

    Press the stop button. Relieve residual static pressure before disconnecting or servicing the unit. Follow all lock-out tag-out requirements. Page: 38 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683www.AdvantageEngineering.com...

  • Page 39: Troubleshooting

    Unit will not start (Display is not Illuminated) Unit will not start (Display Illuminated) Unit Stops Unit Overheats Unit Underheats Pressure Relief Valve Leaks Page: 39 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683 www.AdvantageEngineering.com...

  • Page 40: Unit Will Not Start (Display Is Not Illuminated)

    Refer to Section 2.3 for additional System Fault Screen. information. Indiacates a water supply or a pump overload fault. Page: 40 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683www.AdvantageEngineering.com...

  • Page 41: Unit Overheats

    20 psi. If the differential is less than the factory recommendation, plant service personnel should take measures to reduce drain line pressure. Page: 41 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277...

  • Page 42: Unit Underheats

    This will increase the unit’s internal pressure causing the pressure relief valve to Page: 42 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683www.AdvantageEngineering.com...
  • Page 43 If this is the case, the operator must determine why the system internal pressure is excessive and correct the condition. Page: 43 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277...
  • Page 44 THIS PAGE INTENTIONALLY BLANK Page: 44...

  • Page 45: Maintenance

    Sensor Probe Service Pressure Switch Service Electronic Instrument Repair Policy & Procedure Temperature Probe Calibration Heater Contactor and Pump Motor Starter Page: 45 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683 www.AdvantageEngineering.com...

  • Page 46: Pump Seal Replacement

    Locate and remove the dust cap from the motor to expose slotted motor shaft. Pump casing bolts Page: 46 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683www.AdvantageEngineering.com...
  • Page 47 Seal components restart the unit. In many cases, a new pump seal will experience a small amount of leakage for a short Page: 47 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683 www.AdvantageEngineering.com...
  • Page 48 Seal components Figure 5.1I Stationary member Figure 5.1J Rotating member Figure 5.1K Aligning impeller and Figure 5.1L spring Page: 48 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683www.AdvantageEngineering.com...

  • Page 49: Heater Replacement

    Set new heater into tank. Aligning the bolt pattern of the heater and tank flanges. Remove heater Page: 49 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683 www.AdvantageEngineering.com...

  • Page 50: Cooling Valve Service

    Note the arrangement of the core spring and core assembly, diaphragm spring and diaphragm assembly. (See diagram.) Page: 50 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683www.AdvantageEngineering.com...
  • Page 51 Temperature Control Units : Sentra with G300 Series Instrument Coil and solenoid base sub assembly Valve body Core spring Core Body Diaphragm Diaphragm assembly assembly Gasket spring Page: 51 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683 www.AdvantageEngineering.com...

  • Page 52: Voltage Changeover

    VOLTAGE CHANGE Some units can undergo a field voltage conversion by qualified technicians. Consult with the Advantage Service Department to determine if your unit can be converted. Have your Serial Number ready and call 317-887-0729. Typical Conversions for 1/2 to 7.5 horsepower motors and 10 to 16 kW heaters:...
  • Page 53 Wiring schematics for 240 and 480 volt heaters Revised 4/11 Wiring Schematic for Tempco Brand Heaters : 10 kw & 16 kW Page: 53 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683 www.AdvantageEngineering.com...
  • Page 54 2.5 of this manual. Restart unit operations according to section 3 of this manual. Motor Starter and Overload Block Page: 54 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683www.AdvantageEngineering.com...

  • Page 55: Sensor Probe Service

    Reconnect the service connection. Restart the unit as outlined in section 3 of this manual. Page: 55 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277...

  • Page 56: Pressure Switch Service

    Install the brass elbow fitting. Teflon tape and leak preventative paste should be used to prevent water leakage. Install the capillary tube and resume operations. Page: 56 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277...

  • Page 57: Electronic Instrument Repair Policy And Procedure

    Temperature Control Units : Sentra with G300 Series Instrument ELECTRONIC INSTRUMENT REPAIR POLICY AND PROCEDURE All control instruments used in Advantage temperature control units are covered by the machine’s warranty. Proprietary ‘tailor made’ instrument are manufactured specifically for Advantage. IN WARRANTY SERVICE INCIDENT Call the factory for diagnostic assistance.

  • Page 58: Temperature Probe Calibration

    Locate the “to process” calibration potentiometer using Figure 1 as a guide. Use the small screwdriver to turn the potentiometer. Page: 58 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683www.AdvantageEngineering.com...
  • Page 59 Stop the unit following the shutdown procedure described in the manual and place all process probes back in the unit to return to normal operation. Calibration potentiometer Page: 59 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683 www.AdvantageEngineering.com...

  • Page 60: Heater Contactor And Pump Motor Starter

    Typical Pump Motor Starter Failure to maintain the contactor may result in overheating of the WARNING: components and catastrophic electrical failure. Page: 60 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683www.AdvantageEngineering.com...

  • Page 61: Components

    Temperature Control Units : Sentra with G300 Series Instrument COMPONENTS Mechanical System Electrical System Page: 61 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683 www.AdvantageEngineering.com...

  • Page 62: Mechanical System

    The electrical cabinet cover is hinged. The unit base is made of pressed steel with galvanized zinc coating. The rear access panels can be lifted off after removing the fasteners. Page: 62 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277...

  • Page 63: Electrical System

    Standard models with 24kW and 34kW heaters are not supplied with a power cord and the customer must provide a 3 conductor with 1 ground wire sized for the unit. Page: 63 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683 www.AdvantageEngineering.com...
  • Page 64 THIS PAGE INTENTIONALLY BLANK Page: 64...

  • Page 65: Related Drawings

    Physical : Cabinet Style for Units with 5 & 7.5 HP Pumps Regulator / Bypass Dual Zone Dolly Stacking Rack Page: 65 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683 www.AdvantageEngineering.com...

  • Page 66: Physical : Cabinet Style For Units Up To 16 Kw Heaters And Pumps To 3 Hp

    Temperature Control Units : Sentra with G300 Series Instrument PHYSICAL : Cabinet Style for Units up to 16 kW Heaters and Pumps to 3 HP Page: 66 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277...

  • Page 67: Physical : Cabinet Style For Units Up To 24 & 34 Kw Heaters And Pumps To 3 Hp

    Cabinet Style for Units with: 24 & 34 kW Heaters and Pumps to 3 HP Provided for display purposes only. Refer to electrical drawing supplied with unit for details. Page: 67 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683 www.AdvantageEngineering.com...

  • Page 68: Physical : Cabinet Style For Units Up To 5 & 7.5 Hp Pumps

    Temperature Control Units : Sentra with G300 Series Instrument PHYSICAL : Cabinet Style for Units with : 5 & 7½ HP Pumps Page: 68 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683www.AdvantageEngineering.com...

  • Page 69: Regulator/Bypass Installation

    PRESSURE REGULATOR VALVE WATER BYPASS VALVE TYPE: WATTS U5B 1/2" SUPPLY TYPE: WATTS BP-30 1/2" 25-75psi RANGE. 45-100psi RANGE. Page: 69 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683 www.AdvantageEngineering.com...

  • Page 70: Dual Zone Dolly

    DUAL ZONE DOLLY Molders often need to run different temperatures on each mold half to produce the best quality part. Advantage can provide a dual zone dolly that holds two standard single zone temperature control units to meet this need.

  • Page 71: Stacking Rack

    Temperature Control Units : Sentra with G300 Series Instrument STACKING RACK Page: 71 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683 www.AdvantageEngineering.com...
  • Page 72 THIS PAGE INTENTIONALLY BLANK Page: 72...

  • Page 73: Appendix

    Remote and Autostart Feature Configuration SPI Commands Communication Cable Optional Alarm Operation Standard G English Factory Default Settings Parts : #119 Pump Page: 73 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683 www.AdvantageEngineering.com...

  • Page 74: Model Number & Suffix Coding

    90 = 90 GPM @ 5 Horsepower 100 = 100 GPM @ 7 1/2 Horsepower Maximum Temperature Blank = 250°F 300 = 300°F Page: 74 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683www.AdvantageEngineering.com...

  • Page 75: Interpretation Of Process Pressure Gauges

    ∆ P values. This spike is called “water hammer”. Page: 75 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683 www.AdvantageEngineering.com...

  • Page 76: Operation Of Mold Purge

    Mold purge is started immediately. If the pump is running, the follow message will be displayed. If the pump is not running, the mold purge will start. Page: 76 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277...
  • Page 77 Valve must be closed during mold purge operation DRAIN CONNECTION AVT VALVE Closed to prevent purge of unit (inside unit) Typical mold purge equipment configuration. Page: 77 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683 www.AdvantageEngineering.com...

  • Page 78: Remote And Autostart Feature Configuration

    Place manual on/off switch in the on position to activate AutoStart. Follow the instructions in 8.4.G to enable the AutoStart option on the control panel. Remote Start Contacts Page: 78 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683www.AdvantageEngineering.com...
  • Page 79 Press the select button to advance to the enable/disable screen. Select Enabled to enable the Remote Start or AutoStart option Press the Select button to acknowledge and save the selection. Page: 79 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277...

  • Page 80: Spi Commands

    There are many acceptable ways used to ‘set’ the device address and data rate. ADVANTAGE equipment provides access to the information via the front panel operators and displays. Other manufacturers may use internal DIP switches or jumpers.
  • Page 81 15 14 13 12 11 10 PROCESSING ALARM - SYSTEM ALARM - PROCESS ALARM - MACHINE ALARM - SENSOR Page: 81 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683 www.AdvantageEngineering.com...
  • Page 82 20 30 Setpoint 20 32 High alarm deviation 20 34 Low alarm deviation 20 40 Status process 20 70 To process temperature Page: 82 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683www.AdvantageEngineering.com...

  • Page 83: Communication Cable

    Temperature Control Units : Sentra with G300 Series Instrument COMMUNICATIONS CABLE Page: 83 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683 www.AdvantageEngineering.com...

  • Page 84: Optional Alarm Operation

    Sensor probe malfunction BEACON AND AUDIBLE ALARMS ARE SILENCED DURING AN ALARM CONDITION BY PRESSING THE START BUTTON ON MICROPROCESSOR CONTROLLER Page: 84 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683www.AdvantageEngineering.com...

  • Page 85: Standard G English Factory Default Settings

    Cooling Valve Size : 1/2" 500:1 Cooling Valve Size : 3/4" 1000:1 Max Set Point 250°F Units English Heat Only Mode Disablced Page: 85 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683 www.AdvantageEngineering.com...

  • Page 86: Parts : #119 Pump

    Adapter, SS304, J56, 5/8" SEal, with Stls plugs 3301135X GAsket, Case, Buna 137.003.072 Seal, 5/8", Type 21, EPDM-CARB/CM with Retainer 101.000.327 Page: 86 Advantage Engineering, Inc. 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-0729 Fax: 317-881-1277 Service Department Fax: 317-885-8683www.AdvantageEngineering.com...
