- Page 1 Roswell Installation Manual Model: 50797 Noble Bronze 50798 Brushed Nickel Fan weight ±2 lbs: 17.4 lbs (7.9 kg) ©2020 Hunter Fan Co. PG3910 r060820...
- Page 2 - All wiring must be in accordance with national and local electrical codes ANSI/NFPA 70. If you are unfamiliar with wiring, use a qualified electrician. c.2 - Use only Hunter replacement parts. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 3 We recommend that you pull everything out of the box and lay it out. We have grouped the drawn components below with the hardware you’ll need for those Hunter Pro Tip: parts. The screws below are drawn to scale to make it easier to identify what piece of hardware is needed to install each component.
-
Page 4: Choosing The Right Installation Location
A little more information on Angled Mounting: For optimum performance and appearance, a longer downrod should be used with your Hunter ceiling fan when installing on high or angled ceiling. If your ceiling is angled greater than 30° you will also need an Angled Mounting Kit. -
Page 5: Installing The Ceiling Bracket
Installing the Ceiling Bracket You have two options for installation. Pick which one works best for your location. Remove any existing bracket prior to installation. Only use the provided Hunter ceiling bracket that came in your fan’s box. Hunter Pro Tip:... -
Page 6: Hanging The Fan
If you are unfamiliar with wiring or uncomfortable doing it yourself, please contact a qualified electrician. You are going to need these: Hunter Pro Tip: Here is how to connect the wires: 4 Wire Nuts (these are in the... -
Page 7: Installing The Canopy
1886 Installing the Canopy Insert the two canopy screws found in the hardware bag. Canopy Screw Lift the canopy into place so that NOTICE the screw holes are aligned. If screw holes do not align properly then rotate the canopy Note: 180 degrees. - Page 8 1886 Installing the Blade Assembly 3 of 3 Assembly Screw Guide Hole Lift the blade assembly and align its screw holes with the screw holes in the motor Secure the blade assembly to the motor housing using the assembly screws, found in housing.
- Page 9 1886 Preparing the Wall Control Turning off the power Ensure the power is OFF at the outlet box and wall switch location before proceeding with installation. Remove battery door. Change the dip switch settings if they match a previously installed remote transmitter. Install A23 or MN21 alkaline battery in the proper polarity and replace the Battery...
-
Page 10: Troubleshooting
• Use the provided balancing kit and instructions to balance the fan. Remote Control of Fan is Erratic • Make sure the battery is installed correctly. • Install a fresh battery. Hunter Pro Tip: Cleaning the Fan Use soft brushes or cloths to prevent scratching. Cleaning products may damage the finishes. -
Page 11: Limited Lifetime Warranty
HUNTER FAN COMPANY IS NOT RESPONSIBLE FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES, DUE TO PRODUCT FAILURE, WHETHER ARISING OUT OF BREACH OF Please do not ship your fan or any fan parts to Hunter. Delivery will be refused. WARRANTY, BREACH OF CONTRACT, OR OTHERWISE. Some States do not allow the...
