- Page 1 Gallegos Installation Manual Model: 51583 Flat Matte Black 51584 Matte Silver Fan weight ±2 lbs: 15.2 lbs (6.9 kg) ©2022 Hunter Fan Co. PG4069 r051022...
- Page 2 - All wiring must be in accordance with national and local electrical codes ANSI/NFPA 70. If you are unfamiliar with wiring, use a qualified electrician. c.2 - Use only Hunter replacement parts. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 3 We recommend that you pull everything out of the box and lay it out. We have grouped the drawn components below with the hardware you’ll need for those Hunter Pro Tip: parts. The screws below are drawn to scale to make it easier to identify what piece of hardware is needed to install each component.
-
Page 4: Choosing The Right Installation Location
A little more information on Angled Mounting: For optimum performance and appearance, a longer downrod should be used with your Hunter ceiling fan when installing on high or angled ceiling. If your ceiling is angled greater than 34° you will also need an Angled Mounting Kit. -
Page 5: Installing The Ceiling Bracket
You have two options for installation. Pick which one works best for your location. Remove any existing Hunter Pro Tip: bracket prior to installation. Only use the provided Hunter ceiling bracket that came in your fan’s box. The machine screws are the ones that came with your outlet box. -
Page 6: Hanging The Fan
1886 Hanging the Fan NOTICE To prevent damage to fan, ALWAYS lift holding either the fan housing or the downrod. Place the downrod ball into the slot in the ceiling bracket. Progress Check: Your fan should look like this. Note: Fan style may vary. -
Page 7: Wiring The Fan
If you are unfamiliar with wiring or uncomfortable doing it yourself, please contact a quali ed electrician. You are going to need these: Hunter Pro Tip: Here is how to connect the wires: 4 Wire Nuts (these are in the... -
Page 8: Installing The Canopy
1886 Installing the Canopy Insert the two canopy screws found in the hardware bag. Canopy Screw Lift the canopy into place so that the screw holes are aligned. Installing the Blades: Blade Screw Attach each blade to the blade iron using three blade assembly screws, found in the hardware bag. - Page 9 1886 Assembling the Switch Housing 2 of 3 2 of 3 Switch Switch Housing Housing Screw Screw Insert the third screw, Feed the wire plug through the found in the hardware center hole of the upper switch bag, into place and then Partially install two switch housing, then wrap keyhole tighten all three screws.
- Page 10 1886 Installing Wall Control Turning off the power WARNING Ensure the power is OFF at the outlet box and wall switch location before proceeding To avoid possible electrical shock, before with installation. installing your fan, disconnect the power by turning off the circuit breakers to the outlet box associated with the wall switch location.
-
Page 11: Troubleshooting
• Turn the power off, support the fan carefully, and check that the hanger ball is properly seated. • Use the provided balancing kit and instructions to balance the fan. Hunter Pro Tip: Cleaning the Fan Use soft brushes or cloths to prevent scratching. -
Page 12: Limited Lifetime Warranty
Hunter instructions, accidental damage caused by the fan owner or related parties, Please do not ship your fan or any fan parts to Hunter. Delivery will be refused. modifications to the fan, improper or incorrectly performed maintenance or repair,...
