Pico Macom CA-30RK1000 Specifications

Headend & Electronics
Broadband 54-1000MHz frequen-
cy range (Channels CATV 2-135)
30dB gain for optimal carrier-to-
noise ratio and superior picture
quality
± 0.5dB flatness across band
provides low distortion and
excellent frequency response
Employs state-of-the art hybrid
push-pull technology for distor-
tion-free audio-video quality
Adjustable slope and gain con-
trols for easy system balancing
Front panel controls and test
point enable easy setup and
monitoring
Double shielded enclosure pro-
vides over 95dB RFI shielding
performance reducing leakage
and ingress
Built-in lightning and line volt-
age surge protection protects
the unit from damage
Also available in a wall mount
version as CA30-1000
Distribution Amplifier
www.picomacom.com
CA30RK1000
1GHz Broadband Push-Pull Headend Amplifier
CA30RK1000
1GHz Broadband Push-Pull Headend Amplifier
The Pico Macom CA30RK1000 is a professional re-broadcast grade push-pull
amplifier producing signals with extremely low noise and harmonic distortion.
The amplifier is capable of 135 channel operation over the 54-1000MHz range.
This rack-mounted amplifier makes an excellent headend launch amplifier and is
frequently used in conjunction with Pico Macom's passive headend combiners
(PHC12G or PHC24G) to overcome losses associated with signal combining in
broadband CATV systems. Also, the CA30RK1000 is ideally suited for amplify-
ing the cable input prior to Pico Macom's CEF channel elimination filter in
applications requiring "mix-and-match" channel applications or those requiring
local insertion. Pico Macom backs up this product with its industry leading
5-year limited warranty.
PICO MACOM, INC.
355 Parkside Drive San Fernando, CA 91340
Ph: 818-493-4300 Toll Free: 800-421-6511 Fax: 818-493-4433
A-57
Rev. 12/02
