- Page 1 OWNER’S MANUAL Wireless Sound Bar Please read this manual carefully before operating your set and retain it for future reference. MODEL SK5 (SK5, SPK5B-W) www.lg.com Copyright © 2018 LG Electronics Inc. All Rights Reserved.
- Page 2 Getting Started Safety Information WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. CAUTION: The apparatus should not be exposed to CAUTION water (dripping or splashing) and no objects filled RISK OF ELECTRIC SHOCK with liquids, such as vases, should be placed on the DO NOT OPEN apparatus.
- Page 3 Getting Started This device is equipped with a portable battery or CAUTION concerning the Power Cord accumulator. The Power Plug is the disconnecting device. In case of an emergency, the Power Plug must How to Safely remove the batteries or the remain readily accessible.
- Page 4 Refers to stand-by. available for download. Refers to “ON” (power). LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of Refers to dangerous voltage. performing such distribution (such as the cost of media, shipping and handling) upon email request to opensource@lge.com.
-
Page 5: Table Of Contents
Your BLUETOOTH Device Wireless subwoofer connection – Activate BLUETOOTH with “Music Flow – Using an OPTICAL cable Bluetooth” App – LG Sound Sync Sound adjustment – Using an HDMI cable – Setting sound effect – Additional information for HDMI – Adjust the woofer level settings Optional equipment connection –... -
Page 6: Getting Started
Indicates special notes and operating features. LG Sound Sync > Caution Controls volume level of this unit by the remote control of your LG TV that is compatible with LG Indicates cautions for preventing possible damages Sound Sync. from abuse. BLUETOOTH®... -
Page 7: Remote Control
Getting Started • • • • • • • • • • • • • • a • • • • • • • • • • • • • Remote control 1 (Standby) : Switches the unit ON or OFF. VOL (Volume) o / p : Adjusts speaker volume. -
Page 8: Front Panel
Getting Started Front panel A Remote sensor D o/p (Volume) : Adjusts volume level F (Function) : Selects the function and input B Standby LED (Red) source. C Function LED (White) 1 (Standby) : Switches the unit ON or OFF. Rear panel A DC IN : Connect to the AC adapter : Connect to a USB device... - Page 9 LG Sound Sync (Wireless) function is LG TV LED turns on. selected. HDMI IN LED turns on. HDMI IN function is selected. LG TV and HDMI IN LEDs turn PORTABLE function is selected. USB and BT (Bluetooth) LEDs ARC function is selected turn on.
- Page 10 Press and hold AUTO POWER ON on the Bluetooth deivce only on remote control for about 2 seconds in (Page 28) Bluetooth and LG TV functions. Bluetooth function. Initial setting of this function The standby LED blinks once. was set to off.
-
Page 11: Installing The Sound Bar
Getting Started Installing the sound bar You can hear the sound by connecting the unit to the other device : TV, Blu-ray disc player, DVD player, etc. Place the unit in front of the TV and connect it to the device you want. -
Page 12: Mounting The Main Unit On A Wall
Getting Started 1. Match the TV’ s BOTTOM EDGE of Wall bracket Mounting the main unit install guide with the bottom of TV and attach to the position. on a wall You can mount the main unit on a wall. 2. - Page 13 Getting Started > Caution 4. Fix the brackets with screws (A) as shown in the illustration below. y Do not install this unit upside down. It can damage the parts of this unit or be the cause of personal injury. y Do not hang onto the installed unit and avoid any impact to the unit.
-
Page 14: Connecting
Connecting Organizing cables Connecting the AC (Optional) Adapter You can organize the cable with cable ties. Connect the speaker to the power supply with the supplied AC adapter. 1. Hold the cables together with cable ties as shown below. 1. Connect the supplied AC power cord to the AC adapter. -
Page 15: Wireless Subwoofer Connection
Connecting Wireless subwoofer Manually pairing wireless subwoofer When your connection is not completed, you can connection check red LED on the wireless subwoofer and the wireless subwoofer does not make sound. To solve the problem, follow the steps below. 1. Press Pairing button on the rear of the wireless LED indicator of wireless subwoofer subwoofer. -
Page 16: Using An Optical Cable
Connecting Note Connecting to your TV y It takes a few seconds (and may take longer) for the main unit and the subwoofer to Please connect this unit and the TV using the optical communicate with each other and make digital cable or HDMI cable considering the capability sounds. -
Page 17: Lg Sound Sync
Connecting LG Sound Sync LG Sound Sync with wired connection 1. Connect your LG TV to the unit by using an optical cable. You can control some functions of this unit by your TV's remote control with LG Sound Sync. It is compatible with the LG TV that is supported LG Sound Sync. -
Page 18: Using An Hdmi Cable
Some functions of this unit are controlled by the y You can enjoy the TV audio through the TV’ s remote control when this unit and LG TV’ s with speakers of this unit. In the case of some TV SIMPLINK are connected through HDMI connection. -
Page 19: Additional Information For Hdmi
When the HDMI connection with HDCP is not controls. verified, TV screen is changed to black screen. ※ Trade names for CEC are SimpLink (LG) , Anynet+ In this case, check the HDMI connection, or (Samsung), BRAVIA Sync/ Link (Sony), EasyLink disconnect the HDMI cable. -
Page 20: Optional Equipment Connection
Connecting Optional equipment For enjoying both sound and picture You can enjoy both sound and picture from the connection external device you connect. HDMI connection You can enjoy the sound and picture from HDMI connection on external device. HDMI For enjoying sound only cable You can enjoy the sound from the external device you connect. -
Page 21: Optical In Connection
Connecting OPTICAL IN connection PORTABLE IN connection Connect an optical output jack of external devices to the OPTICAL IN jack. Portable cable Optical cable MP3 player, etc... To the optical output jack of external device 1. Connect the OPTICAL IN jack on the back of the unit to optical out jack of your external device. -
Page 22: Usb Connection
Connecting USB connection USB device requirement Connect USB memory device to the USB port on the y Devices which require additional program back of the unit. installation connected to a computer, are not supported. y Do not extract the USB device while in operation. y For a large capacity USB, it may take longer than a few minutes to be searched. -
Page 23: Playable File
Connecting Note Playable file y Folders and files on the USB are recognized Sampling Frequency as below. MP3 : within 32 to 48 kHz : Folder WMA : within 32 to 48 kHz OGG : within 32 to 48 kHz : File FLAC : 32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz and 192 kHz (16 bit/ 24 bit) -
Page 24: Operating
This function does not operate on LG TV's magic remote control. Note y This function may not work well when some y The resume point may be cleared when you... -
Page 25: Auto Power Down
15 from the TV connected by LG Sound Sync minutes. (Optical/Wireless). This unit also turns off after six hours if the Main... -
Page 26: Auto Function Change
Sound Sync (Wireless connection), this unit changes Quick start is off. the function to LG TV. You can hear the sound from y This function may not work depending on the your TV. -
Page 27: Using Bluetooth® Technology
In order to use Bluetooth wireless technology, 9C:02:98:4A:F7:08, you will see devices must be able to interpret certain profiles. T his “LG SK5 (08)” on your Bluetooth device. unit is compatible with following profile. y Depending on the Bluetooth device type, A2DP (Advanced Audio Distribution Profile) some device have a different pairing way. - Page 28 Bluetooth technology such as a You can limit Bluetooth connections to only medical equipment, a microwave or a BT (Bluetooth) and LG TV function to prevent wireless LAN device. unintended Bluetooth connections. y If Bluetooth connection does not work well, Press and hold AUTO POWER ON on the remote try pairing it again.
-
Page 29: Using Bluetooth App
Operating Using BLUETOOTH App Install “Music Flow Bluetooth” App through “Google Android Market (Google Play Store)” Note 1. Tap the “Google Android Market (Google Play y Only Android OS is available to use “Music Store)” icon. Flow Bluetooth” app with this unit. 2. - Page 30 Operating Note y “Music Flow Bluetooth” app will be available in the software version as follow; - Android O/S : Ver 4.0.3 (or later) y If you use “Music Flow Bluetooth” app for operation, there would be some differences between “Music Flow Bluetooth” app and the supplied remote control.
-
Page 31: Sound Adjustment
Operating Sound adjustment Adjust the woofer level settings You can adjust the sound level of subwoofer as your preference. Press WOOFER o / p button to adjust woofer level. Setting sound effect Note This system has a number of pre-set surround sound fields. -
Page 32: Troubleshooting
Bluetooth device. The AUTO POWER function does not y Check the state of SIMPLINK on your LG TV and turn off SIMPLINK. work. y Depending on the connected device, this function may not operate. y Check whether your LG TV supports LG Sound Sync. -
Page 33: Notes To Use Wireless
Troubleshooting PROBLEM CAUSE & CORRECTION The unit does y Turn off the Bluetooth connection lock function. (Page 28) not connect with Bluetooth device Check the details below and adjust the unit according to them. y With the sound bar connected with TV, change the AUDIO DIGITAL OUT setting on TV Setup Menu from [PCM] to [AUTO] or [BITSTREAM]. -
Page 34: Notes To Release Demo Mode
Troubleshooting NOTES to release Demo mode PROBLEM CAUSE & CORRECTION Can not change input source with F button such as y Unplug the power cord and plug it in again. If that BT (Bluetooth), HDMI etc. and All the function LEDs doesn’t work, press and hold F button (About 15 are turned on. -
Page 35: Appendix
The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by LG Electronics is under license. Other trademarks and trade names are those of Manufactured under license from Dolby their respective owners. -
Page 36: Specifications
Appendix Specifications General Refer to the main label. Power consumption Networked standby : 1.2 W (If all network ports are activated.) y Model : DA-38A25 y Manufacturer : Asian Power Devices Inc. AC adapter y Input : 100 - 240 V ~ 50 - 60 Hz 1.2 A y Output : 25 V 0 1.52 A Dimensions (W x H x D) Approx. - Page 37 Appendix Wireless subwoofer Power requirements Refer to the main label on the wireless subwoofer. Power consumption Refer to the main label on the wireless subwoofer. Type 1 Way 1 Speaker Impedance 3 Ω Rated Input Power 200 W RMS Max. Input Power 400 W RMS Dimensions (W x H x D) Approx.
-
Page 38: Maintenance
Appendix Maintenance Handling the unit When shipping the unit Please save the original shipping carton and packing materials. If you need to ship the unit, for maximum protection, re-pack the unit as it was originally packed at the factory. Keeping the exterior surfaces clean y Do not use volatile liquids such as insecticide spray near the unit.
