WATER METERS
WM600
WM600C
Model Number:
Serial Number:
Date of Installation:
Baxter Mfg, a Division of ITW FEG, LLC • 19220 State Route 162 East • Orting, WA 98360-9236
Operator & Installation
ML-132392
ML-132392
___________
___________
___________
Phone: (360) 893-5554 • Fax: (360) 893-1337
www.baxtermfg.com
Manual
FORM 36716 (July 2010)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for baxter ML-132392
Summary of Contents for baxter ML-132392
- Page 1 Model Number: ___________ Serial Number: ___________ ___________ Date of Installation: Baxter Mfg, a Division of ITW FEG, LLC • 19220 State Route 162 East • Orting, WA 98360-9236 Phone: (360) 893-5554 • Fax: (360) 893-1337 FORM 36716 (July 2010) www.baxtermfg.com...
-
Page 2: Table Of Contents
Using the WM600/WM600C Water Meter ..................13 Using the Temperature Probe ......................14 Flush Time ............................. 15 Shutdown ............................15 CLEANING ............................15 MAINTENANCE ..........................16 Service and Parts Information ....................... 16 Calibration Check .......................... 16 TROUBLESHOOTING ........................20 ©BAXTER MFG, 2010 – 2 –... -
Page 3: General
Baxter Water Meters are produced with quality workmanship and material. Proper installation, usage and maintenance of your water meter will result in many years of satisfactory performance. -
Page 4: Installation Codes And Standards
4. Mark the position and hole location. 5. Mount the base to the wall using the appropriate mounting fasteners. 6. Slide the water meter, with the control panel facing up, downward onto the base. Make sure the horizontal groove on the back of the water meter is lined up with the top edge of the base. 7. - Page 5 Units with 120VAC Power Supply • Replace any UL listed fast-acting 0.5A/250VAC fuse inside the water meter if fuse is blown. Units with 230VAC/250VAC Power Supply • For 230VAC/250VAC operation, replace any UL listed fast-acting 3A/600V fuse inside the junction box if fuse is blown. Input power line and branch circuit protection will be provided and wired by customer.
-
Page 6: Water Supply
WATER SUPPLY The water meter requires separate hot and cold supply lines. A manual shutoff valve (not supplied) should be installed on each supply line at the water meter to accommodate servicing and shutdown. • HOT WATER INLET TEMPERATURE: 140°F (60°C) recommended. •... -
Page 7: Plumbing Connections
PLUMBING CONNECTIONS Water and waste piping and connections shall comply with the International Plumbing Code 2003, International Code Council (ICC), or to the Uniform Plumbing Code 2003, International Association of Plumbing and Mechanical Officials (IAPMO). Plumbing connections must comply with applicable sanitary, safety and plumbing codes and provide adequate backflow protection to comply with applicable federal, state and local codes. - Page 8 WATER METER WITH PLUMBING CONNECTIONS Hot Water Cold Water Supply Line Supply Line Power Cord (120 VAC Supply) Shutoff Valve (Not Supplied) Vacuum Breaker Dual Check Junction Valve Y-Strainer Pressure Regulator T-Fitting with Pressure Gauge (Set to 30 PSIG) 90 Elbow Dispenser Union Hose Hook...
-
Page 9: Assembly
ASSEMBLY The water meter is supplied with external fittings/components that must be assembled before the water supply is connected. Qty. FITTING/COMPONENTS Qty. FITTING/COMPONENTS Pressure Regulator Dual Check Valve 90 Degree Elbow Vacuum Breaker Dispenser Hose T-Fitting With Pressure Gauge Y-Strainer Hand Held Temperature Probe 20"... -
Page 10: Operation
OPERATION ENVIRONMENTAL CONDITIONS • Indoor use at altitudes up to 6,500 ft. (2,000 m). • Main supply voltage fluctuations up to +/-10% of nominal voltage. • Installation category III, pollution degree II. • The normal ambient operating temperature is between 41°F (5°C) and 105°F (40°C). The normal operating water temperature is between 32°F (0°C) and 125°F (52°C). - Page 11 Water Amount SETTING window - Displays the amount of water to be delivered, in pounds and ounces. Up to five digits may be entered; the last two digits are always for ounces. Setting ranges are as follows: Pounds: 0 to 999 Ounces: 0 to 15 Liters: 0 to 461 Centiliters: 0 to 99...
-
Page 12: Before First Use
Control Panel For complete control of the water meter functions, a numeric key pad and the following control keys are provided. CHANGE UNITS key - Press to change °F to °C and pounds to liters. If CHANGE UNITS key is locked, see Locking and Unlocking the Change Units on page 14. -
Page 13: Using The Wm600/Wm600C Water Meter
USING THE WM600/WM600C WATER METER Change Units (English/Metric) When the Water Meter is first powered up, press CHANGE UNITS to select the English units (Fahrenheit and Pounds) or Metric unit (Celsius and Liters). If the unit of measure DO NOT change, the CHANGE UNITS key is locked. -
Page 14: Using The Temperature Probe
Operating Hints • To interrupt the water delivery, press STOP/0. • To continue dispensing, press START/RESUME. • To cancel dispensing, press SET AMOUNT. • The amount of water dispensed is displayed in the WATER AMOUNT DELIVERED window. When the delivery is complete, the display will blink and indicate 0 POUNDS 0 OUNCES. •... -
Page 15: Flush Time
FLUSH TIME Water is circulated through the water chiller bypass line to the chiller tank. The flush time setting allows for a certain amount of time for the meter to find the set temperature, within +/- 2°F (1°C). The default flush time is 120 seconds. -
Page 16: Maintenance
MAINTENANCE Disconnect the electrical power to the machine and follow lockout / tagout procedures. On an annual basis, have the temperature, water volume and water weight settings calibrated by an authorized Bakery Systems service technician. At regular intervals, check the temperature probe, water volume and weight against a known constant for accuracy (see Calibration Check below). - Page 17 Calibrating Delivery Amount 1. Press SET TEMP. 2. Enter 32 using the numeric keypad. 3. Press SET AMOUNT. 4. Enter 93303 using the numeric keypad. The WATER AMOUNT SETTING window displays 933 lbs 03 oz. 5. Press START/RESUME. The WATER TEMPERATURE SETTING window displays the current calibration value.
- Page 18 Calibrating Delivery Temperature (Low and High Temperature Calibration) Low End Water Calibration 32°F (0°C) 1. Press SET TEMP. 2. Enter 32 using the numeric keypad. 3. Press SET AMOUNT. 4. Enter 96606 using the numeric keypad. The WATER AMOUNT SETTING window displays 966 lbs 06 oz.
- Page 19 Calibrating Hand Held Probe Temperature (Low and High Temperature Calibration) Low End Probe Calibration 32°F (0°C) 1. Press SET TEMP. 2. Enter 32 using the numeric keypad. 3. Press SET AMOUNT. 4. Enter 97707 using the numeric keypad. The WATER AMOUNT SETTING window displays 977 lbs 07 oz.
-
Page 20: Troubleshooting
TROUBLESHOOTING Symptom Problem Corrective Action Water meter indicator lights and No power. Plug power in and/or check circuit displays are off. breakers. Check fuse. Water temperature does not No hot or cold water supplied to Check that both hot and cold water stabilize.
