Summary of Contents for Beko DN134100

  • Page 1 Refrigerator DN134100 DN133500 DN134100S DN133500S DN139110 RDNE340K12S DN139110S RDNE340K12S SKDTRIAL EN AR EWWERQWEW...
  • Page 2 Please read this user manual first! Dear Customer, We hope that your product, which has been produced in modern plants and checked under the most meticulous quality control procedures, will provide you an effective service. Therefore, read this entire user manual carefully before using the product and keep it as a reference.
  • Page 3: Table Of Contents

    CONTENTS 4 Preparation 1 Your Refrigerator 5 Using your refrigerator 13 2 Important Safety Warnings Temperature setting button ....13 Intended use ........4 Setting the temperature of your General safety ........4 refrigerator ........13 For products with a ......7 Dual cooling system ......
  • Page 4: Your Refrigerator

    Your Refrigerator 1.Freezer compartment door shelf 12.Chiller compartment 2.Temperature setting button 13.Key 3.Butter & Cheese sections 14.Wine cellar 4.Fridge compartment door shelf 15.Fridge compartment glass shelves 5.Egg holders 16.Blower 6.Rotary storage container 17.Ice container 7.Bottle holder 18.Icematic 8.Shelter wire 19.Freezer compartment 9.Bottle shelf 20.Fridge compartment 10.Adjustable legs...
  • Page 5: Important Safety Warnings

    Important Safety Warnings frostbite in your mouth.) Please review the following • For products with a freezer information. Failure to observe compartment; Do not put this information may cause bottled and canned liquid injuries or material damage. beverages in the freezer Otherwise, all warranty and compartment.
  • Page 6 • In case of any failure or during dangerous with respect to a maintenance or repair work, electrical safety. • Contact authorized service disconnect your refrigerator’s when there is a power cable mains supply by either damage to avoid danger. turning off the relevant fuse or • Never plug the refrigerator unplugging your appliance.
  • Page 7 unplugged. A possible problem in power cable may cause fire. • The plug’s tip should be cleaned regularly with a dry cloth; otherwise, it may cause fire. • Refrigerator may move if adjustable legs are not properly secured on the floor. Properly securing adjustable legs on • Do not plug the refrigerator if the floor can prevent the...
  • Page 8: For Products With A

    For products with a Compliance with WEEE water dispenser; Directive and Disposing of • Pressure for cold water inlet the Waste Product: shall be maximum 90 psi (6.2 bar). If your water pressure This product complies exceeds 80 psi (5.5 bar), use a with EU WEEE Directive pressure limiting valve in your (2012/19/EU).
  • Page 9: Hc Warning

    If you want to contribute to the re- amount of food items in the freezer evaluation of the packaging materials, when you remove the shelf or drawer you can consult to your environmentalist of the freezer. Energy consumption organizations or the municipalities value stated for your refrigerator has where you are located.
  • Page 10: Installation

    Installation In case the information which are given in the user manual are not taken into account, manufacturer will not assume any liability for this. Points to be paid attention to when the relocation of the refrigerator Your refrigerator should be unplugged.Before transportation of your refrigerator, it should be emptied and cleaned.
  • Page 11: Electrical Connection

    Disposing of your old Electrical connection refrigerator Dispose of your old refrigerator without Connect your product to a grounded giving any harm to the environment. socket which is being protected by a • You may consult your authorized fuse with the appropriate capacity. dealer or waste collection center of Important: your municipality about the disposal...
  • Page 12: Adjusting The Legs

    • The condenser of your appliance Adjusting the legs is located on the back as shown If your refrigerator is unbalanced; below. In order to achieve better You can balance your refrigerator energy efficiency with lower energy by turning its front legs as illustrated consumption, please pull the in the figure.
  • Page 13: Preparation

    Preparation • Your cooler/freezer should be not thaw thanks to its Advanced installed at least 30 cm away from Electronic Temperature Control heat sources such as hobs, ovens, System. For the first installation, the central heater and stoves and at least product should NOT be placed under 5 cm away from electrical ovens and low ambient temperatures.
  • Page 14: Using Your Refrigerator

    Using your refrigerator Vacation Function If the doors of the product are not opened for 12 hours after the thermostat is switched to the hottest position, then the vacation function will be activated automatically. Open the door of the product or change the thermostat setting to cancel the function.
  • Page 15: Freezing Fresh Food

    Freezing fresh food Recommendations for preservation of frozen food • It must be preferred to wrap or cover the food before placing them in the • Prepacked commercially frozen food refrigerator. should be stored in accordance • Hot food must cool down to the with the frozen food manufacturer's room temperature before putting instructions for a...
  • Page 16: Deep-Freeze Information

    Stopping your product Delicatessen Freshzone products (cheese, If your thermostat is equipped with “0” compartment butter, salami and position: etc.) Deep-freeze information - Your product will stop operating Food must be frozen as rapidly as when you turn the thermostat button possible when they are put in a to “0”...
  • Page 17: Chill Compartment

    Chill compartment Making ice Chill compartment is ideal for storing *optional solid dairy products meat, fish and Fill the ice container with water and poultry. Chill compartment temperature place it into the freezer compartment. remains between -2°C and +3°C, Your ice will be ready approximately in slightly colder than freshfood two hours.
  • Page 18: Rotary Storage Container

    Rotary storage container Icematic and ice storage container (in some models) Sliding body shelf can be moved to left *May not be available in all models or right in order to allow you place the Using the Icematic tall bottles, jars or boxes to the lower Fill the Icematic with water and place shelf (Fig.
  • Page 19: Description And Cleaning Of Odor Filter

    Description and cleaning of odor filter *May not be available in all models Odor filter prevents unpleasant odor build-up in your refrigerator. Pull the cover into which the odor filter is installed downwards from the front section and remove as illustrated. Leave the filter under sunlight for one day.
  • Page 20: Reversing The Doors

    Reversing the doors Proceed in numerical order . 45 ° 180°...
  • Page 21: Maintenance And Cleaning

    Maintenance and cleaning Never use gasoline, benzene or similar Never use cleaning agents or water substances for cleaning purposes. that contain chlorine to clean the outer surfaces and chromium coated We recommend that you unplug the parts of the product. Chlorine causes appliance before cleaning.
  • Page 22: Troubleshooting

    Troubleshooting Check this list before contacting the service. Doing so will save you time and money. This list includes frequent complaints that are not related to faulty workmanship or materials. Certain features mentioned herein may not apply to your product. • Defrosting is active.
  • Page 23 warm air moving inside will cause the temperature in the freezer compartment. product to run longer. Do not open the Wait until the temperature of relevant doors too frequently. parts reach the sufficient level by • The freezer or cooler door may be ajar. changing the temperature of cooler or >>>...
  • Page 24 • The doors were opened frequently or If The Surface Of The Product Is kept open for long periods. >>> Do not Hot. open the doors too frequently; if open, • High temperatures may be observed close the door. between the two doors, on the side • The door may be ajar.
  • Page 27 Frost...
  • Page 28 45 ° 180°...
  • Page 31 :«0 1»...
  • Page 37 R600a R134a...
  • Page 38 90psi WEEE .WEEE 0.6) :RoHS EU/2011/65 RoHS...
  • Page 42 WEEE :RoHS...
  • Page 44 EWWERQWEW...
  • Page 45 57 3798 0000/AJ EN-AR www.beko.com.tr www.beko.com...
