OVERVIEW
INSTALLATION
Rigging
When installing the device, make sure there is no highly-inflammable
material (decoration articles, etc.) within a distance of min. 0.5 m.
The device can be installed on the ground or on the wall or ceiling.
Hanging installation
The installation of the device has to be built and constructed in a way that it can hold 10 times the weight for
1 hour without any harming deformation.
DANGER OF FIRE!
17/43
(1) Power switch
(2) Power supply
(3) Fuseholder
(4) DMX-512 OUT
(5) DMX-512 IN
(6) DC OUT
(7) Microphone
(8) Sensitivity control
00026151.DOC, Version 2.3
