Samsung YP-MT6 Quick Manual

Disconnecting the USB cable
After completing the file transfer, you must disconnect the cable in the following way:
1
Double-click on the green arrow in the
taskbar on the bottom right of the window.
2
When the [Stop a Hardware device] message appears,
press the [OK] button and disconnect the USB cable.
k
4
AH68-00000A (Rev 0.0)
YP-MT6 Quick Guide
Location of Controls
Display
Loop Repeating Button
Recording Button
Microphone
USB Cable
Connection Port
Hold Switch
ENC Jack
Turning Power On and Off
Power On : Press the button to turn on the power.
Power Off : Press and hold the button to turn off the power.
Pausing Music
Press the button to pause playback.
If no buttons are pressed within 10 seconds(changes depending on settings),
the yepp automatically powers off.
While in Pause mode, briefly press again to resume playback.
Neck strap Hook
MENU, Navigation button/
Move to Track/Speed Search/
Volume Button
Play/Pause Button
Battery Cover
Earphone Jack
Playing Music
Press the button.
Playback starts.
1
