BSL Giga-Vitesse CFS 3201 Original Operating Instructions

Short-cut forage wagon / short-cut forage wagon with dosing unit
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Translation of the Original
Operating Instructions
Short-cut forage wagon / Short-cut
forage wagon with dosing unit
Giga-Vitesse CFS 3201-4401,
Giga-Vitesse CFS 3601 DO-4401 DO
73200933
06.13 0.000

Advertisement

Table of Contents
loading

Related Manuals for BSL Giga-Vitesse CFS 3201

Summary of Contents for BSL Giga-Vitesse CFS 3201

  • Page 1 Translation of the Original Operating Instructions Short-cut forage wagon / Short-cut forage wagon with dosing unit Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 73200933 06.13 0.000...
  • Page 2 Cutting, charging, transport and distribution of green and dried-out forage Model: Giga-Vitesse CFS / Giga-Vitesse CFS DO Type: Giga-Vitesse CFS 3201, 3601, 4001, 4401 Giga-Vitesse CFS 3601 DO, 4001 DO, 4401 DO Vehicle/Machine ID number: W09726000_0S38001 - W09733000_0S38999 Trade name:...
  • Page 3 © Copyright B. Strautmann & Söhne GmbH u. Co. KG, 2013 All rights reserved. Reproduction, even in excerpts, only allowed with the permission of B. Strautmann & Söhne GmbH u. Co. KG. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 4 In case of any inquiries or problems, please refer to these operating instructions or call us. Regular service and maintenance and timely replacement of worn-out or damaged parts will result in a longer service life of your machine. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 5: Table Of Contents

    Activity-related safety instructions ................43 3.5.2 Important information ....................44 Warning and instructions signs .................... 45 3.6.1 Warning signs ......................45 3.6.2 Instruction signs ....................... 51 3.6.3 Placing of warning and instruction signs ..............52 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 6 5.14.1.2 Lower mechanical supporting leg to support position ......90 5.15 Propeller shaft ........................90 5.15.1 Couple propeller shaft to tractor ................92 5.15.2 Uncouple propeller shaft from tractor ..............92 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 7 Adjust length of propeller shaft to tractor ................145 Check machine for proper functioning ................146 Start-up after longer downtime ..................146 Hitch and unhitch machine ................147 Hitch machine ........................147 Unhitch machine ........................ 148 Settings ......................149 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 8 12.11.3 Set hydraulic brake system ................... 193 12.12 Chassis ..........................193 12.12.1 Maintenance instructions for FAD chassis ............193 12.12.2 Maintenance instructions for BPW chassis ............195 12.13 Transport floor ........................197 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 9 14.4 Electronics – ISOBUS control Field-Operator 120 – Sensors ........... 224 14.5 Electronics – ISOBUS control Field-Operator 120 – Control unit, extension module/LIN module ..........................226 14.6 Connection of lighting system .................... 228 14.7 Connection of additional electrical loads ................228 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 10: User Information

    Hand these operating instructions over to the buyer when the machine is sold. Location details in the operating instructions Any directional data in these operating instructions refer to the direction of motion. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 11: Applied Modes Of Specification

    … the component of an operating element system which is directly actuated by the operator, e. g. by pressing. An operating element may be an adjusting lever, a key button, rotary switch, key etc. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 12: Product Description

    (6) Hinged automatic charging system (Front (15) Access door and ladder panel) (16) Feed gearing, transport floor (7) Pick-up (17) Dosing drums (8) CFS drum (18) Body (9) Holding-down device with pulley Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 13: Safety And Protective Devices

    Risk to people of being crushed, drawn in and becoming entangled during operation of machine due to unprotected moving machine parts!  Start the machine only with the protective devices completely mounted.  Immediately replace defective protective devices. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 14 (3) Drawbar protective device with forced steering axle (optional extra) (4) Holding-down device with pulley (5) Drawbar protective device (6) Roller feeler (7) Protective casing, pick-up (8) Side protector (9) Access door (10) Side protector, dosing drum drive, left-hand Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 15 Fig. 4 (11) Side protector (12) Tunnel cover for dosing drum drive (13) Side protector, dosing drum drive, right- hand (14) Stop-cock (15) Bottom cover plates for feed shaft (16) Tailgate Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 16: Supply Lines Between Tractor And Machine

    Background: red Hydraulic connector "Return line"  Label Arrows: white Background: blue Explanation of hydraulic connector symbols  P: Pressure pipe (red)  T: Tank line (blue) Load-sensing connector  Label Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 17 Product description Explanation of the following symbols:  Load-sensing connector (blue)  Hydraulic brake system (red) Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 18: Traffic-Related Equipment

    Fig. 6 (1) Warning plates (5) License plate (2) Side reflectors (4 on each side of machine) (6) Speed sign (3) Chocks (7) Triangular reflectors (4) Multi-function light Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 19: Correct Use

    Any use beyond this is prohibited and will be regarded as incorrect. For any damage resulting from incorrect use:  the user will be solely responsible,  the manufacturer will not assume any liability. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 20: Hazardous Areas And Dangerous Spots

     within the area of the powered dosing drums,  within the area of the powered transport floor,  in the cargo space with the machine powered. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 21: Type Plate And Ce Symbol

    (9) Baujahr = Year of manufacture (10) Nenndrehzahl [min- ] = Rated speed [min (11) Zul. Hydr. Druck [bar] = Admissible hydraulic pressure [bar] (12) Zul. Höchstgeschw. [km/h] = Maximum admissible speed [km/h] Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 22: License Plate

    40 km/h: 255 mm x 130 mm.  for machines with an admissible maximum speed of more than 40 km/h: 340 mm x 200 mm. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 23: Technical Data

    57.0 64.6 60.8 72.2 68.4 79.8 76.0 pressing power Maximum travel speed km/h 25/40/60 Figures, technical data and weights may change due to technical development and are not binding for delivery. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 24: Dimensions Of Wagon

    With lifted folding drawbar approx. 0.60 Tyres taken as a basis for the measured dimension: 800/45 R26.5 Figures, technical data and weights may change due to technical development and are not binding for delivery. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 25: Tyre Pressure

    According to the StVZO (note of transl.: German Road Traffic Licensing Code), the maximum internal tyre pressure may be 1.5 bar if the vehicle width of 2.55 m is exceeded due to wide-base tyres. Tyre pressures for tandem axle (22.5“) Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 26 A = 2.0 bar up to a max. speed of 60 km/h B = 2.2 bar up to a max. speed of 60 km/h Pick-up roller feeler = 2.5 bar 1 bar = 14.5 psi = 100 kPa Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 27 Product description Tyre pressures for tridem axle (22.5“) Pick-up roller feeler = 2.5 bar 1 bar = 14.5 psi = 100 kPa Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 28 A = 2.0 bar up to a max. speed of 60 km/h B = 2.2 bar up to a max. speed of 60 km/h Pick-up roller feeler = 2.5 bar 1 bar = 14.5 psi = 100 kPa Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 29: Required Tractor Equipment

    Given a free choice, we recommend a single-acting control device and a depressurized return line. The hydraulic hose pipes are marked by colours at the hydraulic plugs, see chapter „Marking of hydraulic supply lines“, page 16. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 30: Noise Specifications

    The workplace-related emission value (sound pressure level) is 74.0 dB(A), measured during operating mode at the driver's ear, the cabin being closed. The sound pressure level mainly depends on the tractor used. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 31: Safety Instructions

    Check tractor and machine for their road and operational safety before each startup. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 32: Organisational Measures

    If this is not part of the operator’s scope of tasks or he/she lacks adequate expert knowledge, the operator shall be obliged to report this defect to his/her superior or to the user. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 33: Qualification Of Staff

    Please note: A qualification which is equivalent to professional training may also be acquired by several years of practice in the corresponding field of work. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 34: Product Safety

    The manufacturer will not assume any liability for damage resulting from:  unauthorized alterations of the machine,  non-approved modification and accessory parts,  welding and drilling work on load-bearing parts of the machine. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 35: Spare And Wearing Parts, Auxiliary Materials

    Make sure that people leave the immediate vicinity of the machine before moving or starting the machine! Particularly be aware of children!  Never carry passengers, animals or objects on the machine! Carrying passengers and transport of animals or objects are not allowed on the machine! Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 36  must not chafe against external components!  Always park the unhitched machine in a stable position! Pay attention to the ground condition. Beware of soft surfaces. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 37 Observe the broad overhang and the flywheel mass of the machine when cornering with attached/hitched machine!  Set all movable machine parts to transport position and secure them before carrying out transport journeys! Use the transport locks provided for this purpose! Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 38: Hydraulic System

     disconnection: first disconnect the minus pole, then the plus pole!  Avoid sparking and open fire in the vicinity of the battery! Risk of explosion! Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 39: Propeller Shaft Operation

    Secure tractor and machine against accidental starting and rolling before carrying out any maintenance, cleaning, lubrication or setup work on machines powered by propeller shafts or before hitching/unhitching them!  Place the uncoupled propeller shaft on the respective holder! Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 40: Hitched Machines

     the air reservoir is damaged,  the type plate at the air reservoir is getting rusty, is loose or is missing! Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 41: Axles

    Climbing onto the transport floor is not allowed as long as the tractor engine is running!  Passengers are not allowed on the machine!  Unhitch the machine from the tractor only when empty! Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 42: Service And Maintenance Of Machine

     Dispose of oils, greases and filters properly!  Spare parts must at least comply with the specified technical standards of the manufacturer! This is guaranteed when using original parts! Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 43: Activity-Related Safety Instructions And Important Information

    Non-observance of the safety instructions marked by "CAUTION" may cause light or moderate bodily injury or material damage. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 44: Important Information

    INFORMATION marks user hints and particularly useful information. This information will help you to use all functions of your machine in the best possible way. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 45: Warning And Instructions Signs

    "Never reach into the dangerous spot as long as the tractor engine is running with the propeller shaft coupled/the hydraulic/ electronic system connected. Make sure that people leave the hazardous area of the machine before moving machine parts." Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 46 This risk may cause most serious injuries or even death. Never enter the cargo space as long as the tractor engine is running with the propeller shaft coupled/the hydraulic/electronic system connected. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 47 This risk may cause most serious injuries or even death. Secure the machine against accidental rolling before unhitching the machine from the tractor or before parking the machine. Use the parking brake and/or the chock(s) for this purpose. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 48 This risk may cause most serious injuries including loss of limbs. Never open nor remove protective devices as long as the tractor engine is running with the propeller shaft coupled/the hydraulic/electronic system connected. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 49 As a basic principle, the following work is not allowed:  mechanical processing of the chassis,  drilling at the chassis,  boring up of existing holes at the chassis frame or at load-bearing parts,  welding on load-bearing parts. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 50 Never reach into the hazardous are of powered working tools as long as the tractor engine is running with the propeller shaft coupled/the hydraulic system connected.  Ensure that people keep sufficient safe distance to powered working tools. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 51: Instruction Signs

    87010288 This pictograph illustrates fixing points for lifting equipment (jack). 87010285 Close the stop-cock (position 0) to secure the tailgate before carrying out work beneath the lifted tailgate. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 52: Placing Of Warning And Instruction Signs

    Safety instructions 3.6.3 Placing of warning and instruction signs The following figures illustrate the position of the warning and instruction signs on the machine. Fig. 11 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 53: Risks In Case Of Non-Observance Of Safety Instructions And Warning Signs

     risk to people due to mechanical and chemical effects,  threat to the environment due to leaking operating media.  lead to invalidation of any claims for damages. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 54: Loading And Unloading

    5.0 bar. Fig. 12 (1) Load bearing points (on both sides) (2) Contact surface (on both sides); use a suitable base (e.g. hardwood) Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 55  Use appropriate slings which are able to safely carry the machine’s weight.  Never stand within the lifting zone beneath the lifted machine. Fig. 13 (1) Spacer Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 56: Design And Function

    Dangerous spots exist within the area of the pick-up due to functional reasons. Fig. 14 Fig. 15 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 57: Pick-Up Drive

    (8) leading to the pick-up. The friction clutch (9) protects the powertrain leading to the pick-up against damage in case of overload and temporary torque peaks at the pick- Fig. 17 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 58: Silage Additive Pump

    The length of the chains (2) determines the distance between holding-down device/pulley and pick-up:  large swathe = large distance between holding-down device/pulley and pick-up  small swathe = small distance between holding-down device/pulley and pick-up Fig. 18 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 59: Feeder Rotor

    The number of cutting knives (4) mounted in the cutting unit determines the cutting length of the loaded material. 45 cutting knives can be mounted. The shortest theoretical cutting length is then 35 mm. Fig. 20 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 60  "Cutting knife out" position:  as soon as a cutting knife evades to the rear,  as soon as the cutting unit is heavily soiled. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 61: Transport Floor

    Set feed rate of transport floor with ISOBUS control Field-Operator 120 The feed rate of the transport floor depends on the set filling degree. Observe the information in the chapter "Pre-select filling degree of loaded material in cargo space", page 126. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 62: Front Panel With Incorporated Automatic Charging System

    As soon as the deflected sensing band reaches the highest set position, the loaded material is conveyed to the back at maximum feed rate. The transport floor stops as soon as the front section in Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 63: Deactivate Automatic Charging System And Stop Transport Floor

    During discharge, the hydraulic drive of the transport floor automatically restarts as soon as the loaded material is no longer applying any pressure to the bottom dosing drum. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 64: Body Tarpaulin With Rewinding And Securing Mechanism

    4. Swivel the locking lever to its bottom position. Fig. 29  The body tarpaulin automatically starts to rewind. 5. Take hold of the body tarpaulin with both hands to prevent if from rewinding too fast. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 65: Tailgate

    The hydraulic cylinders only come into operation at the last moment to close the tailgate and lower it vertically onto the locking pin (4) for being locked. Fig. 31 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 66: Lock Tailgate

    The individual dosing drums are connected with each other by means of roller chains. Each roller chain is equipped with a chain tensioner. Fig. 33 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 67: Access Door And Ladder

    Access door (1), ladder (2) and handle (3) permit access to the cargo space. The locking mechanism (4) secures the closed access door and the folded-up ladder in transport position. Fig. 34 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 68: Hydraulic System Of Machine

    "Required tractor equipment", page 29. For information about the hose markings, refer to the chapter "Marking of hydraulic supply lines", page 16. (1) Hose holder for proper deposition of supply lines. Fig. 35 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 69: Electro-Hydraulic Control Block

    Optional: (4) End plate with directional seat valves for FAD or BPW steering axle (5) End plate with directional seat valves for tridem lift axle (optional extra) Fig. 37 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 70: Load-Sensing Hydraulic System

    Disconnect the load-sensing control line from the load-sensing connector of the tractor before operating the machine with free pressure regulator. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 71: Electrical System - Emergency Manual Operation

    Use a blunt object (3) to push in the armature of the solenoid at the respective control valve to actuate the required hydraulic functions.  Intermediate plates (4) and end plates (5): Screw in the knurled screw (6) at the required directional control/seat valve. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 72: Functional Diagram For Emergency Manual Operation

    Design and function 5.10.1.3 Functional diagram for emergency manual operation (X)Y12 (X)Y13 (X)Y1 (X)Y2 (X)Y3 (X)Y9 (X)Y10 (X)Y4 (X)Y6 (X)Y7 (X)Y7 (X)Y22 (X)Y21 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 73 1. Screw in the knurled screws (1, 2) at the directional seat valves (X)Y12 and (X)Y13. 2. Use a blunt object to push in the armature of the solenoid (X)Y31 (3).  The cutting unit retracts. 3. Unscrew the knurled screws completely again. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 74 Design and function Fig. 40 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 75: Hydraulic Hose Pipes

     Connected hydraulic hose pipes:  must easily give way to any movements during cornering without any stress, buckling or chafing,  must not chafe against external components. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 76: Disconnect Hydraulic Hose Pipes

    2. Unlock the hydraulic plugs from the hydraulic sleeves. 3. Use the dust caps to protect the hydraulic plugs and the hydraulic sleeves against soiling. 4. Put the hydraulic hose pipes down onto the hose holder. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 77: Chassis

    ISOBUS control set. The axle suspension is active with the road travel mode switched on, the axle suspension is locked with the road travel mode switched off. Fig. 41 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 78: Check Travelling Height Of Hydraulic Levelling System

    4. Check the distance X between the locating points on all 4 hydraulic cylinders (1). 5. The travelling height of the tandem axle assembly must be adjusted if the distance is not X = 600±10 mm. Fig. 43 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 79: Adjust Travelling Height Of Hydraulic Levelling System

    4. Connect the hydraulic hose pipe of the levelling valve with a single-acting control device of the tractor. Fig. 45 5. Turn the stop valve (5 or 6) to position Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 80: Hydro-Pneumatic Tridem Chassis With Hydraulic Levelling System

     ensures anti-roll stability on sloping ground and during fast cornering.  controls the hydraulic automatic load-sensitive brake pressure regulator of the dual-line compressed-air brake system. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 81: Adjust Travelling Height Of Hydraulic Levelling System

     ensures careful treatment of farmland during cornering,  reduces tyre wear during cornering on paved areas. The steering axle is unlocked and locked from the tractor via the control unit. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 82: Steering Axle For Electro-Hydraulic Forced Steering Axle System Ses

    (4).  The wheels of the tractor should now be in contact with the drawbar. Fig. 48  If the steering range was exceeded, the Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 83: Lock Forced Steering Axle

    The steering axle is locked in "Straight" position.  If the symbol is flashing, the end position could not be reached. An error has occurred. The steering system works. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 84: Drawbar

     a drawbar lug 40 according to DIN 11043 for a bolt-type coupling according to DIN 11028/ISO 6489-2,  a shell 80 (1) for a ball-type coupling 80. Fig. 50 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 85: Couple Drawbar

    4.2 Ensure that the automatic bolt-type coupling is locked (control pin, end position of operating lever, etc.). 5. Connect the supply lines. 6. Release the parking brake of the machine. 7. Lift the supporting leg to transport position. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 86: Ball-Type Coupling And Shell

    4. Lower the drawbar by means of the supporting leg until the ball head engages in the shell. 5. Lock and secure the holding-down device at the bearing block. 6. Release the parking brake of the machine. 7. Lift the supporting leg to transport position. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 87: Uncouple Drawbar

    7. Secure tractor and machine against accidental starting and rolling. 8. Lock and secure the holding-down device at the bearing block. 9. Disconnect the supply lines. 10. Place the supply lines onto the hose holder. 11. Move the tractor forward. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 88: Drawbar Suspension For Folding Drawbar

    Switch drawbar suspension off 1. Press the key again.  Road travel mode is switched off. At the same time, the drawbar suspension is automatically switched off. The Working menu appears. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 89: Supporting Leg

    (2) until the locking bolt engages into the borehole (5). 4. Check whether the locking bolt has completely engaged into the borehole and properly locks the supporting leg in its transport position. Fig. 53 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 90: Lower Mechanical Supporting Leg To Support Position

    Immediately have damaged or missing parts of the propeller shaft replaced by original parts from the propeller shaft manufacturer. Observe the fact that only an authorized workshop is allowed to repair a propeller shaft. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 91  Before siwtching the p.t.o. shaft on, observe the safety instructions for p.t.o. shaft operation included in the chapter "Basic safety instructions", page 35. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 92: Couple Propeller Shaft To Tractor

    Risk of burns due to contact with hot propeller shaft components! Do not touch considerably warmed-up propeller shaft components (particularly do not touch any couplings). Clean and lubricate the propeller shaft before longer downtimes. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 93: Brake System

    Full braking power is only reached after this running-in period.  Check the brake system for proper functioning before carrying out transport journeys. Observance of the maintenance intervals is indispensable for proper functioning of the dual-line compressed-air brake system. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 94: Dual-Line Compressed-Air Brake System With Mechanical Automatic Load-Sensitive Brake (Alb) Regulator

    (10) Drain valve (11) Test connection in front of ALB regulator (12) Test connection behind ALB regulator (13) Test connection, diaphragm brake cylinder (14) Test connection, compressed-air reservoir (15) Parking brake Fig. 57 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 95: Dual-Line Compressed-Air Brake System With Hydraulic Automatic Load-Sensitive Brake Pressure (Alb) Regulator

    (8) Hydraulic cylinders of the hydraulic levelling system (9) Compressed-air reservoir (10) Drain valve (11) Test connection, compressed-air reservoir (12) Test connection, diaphragm brake cylinder (13) Parking brake Fig. 58 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 96: Dual-Line Compressed-Air Brake System With Hydro-Pneumatic Automatic Load-Sensitive Brake Pressure (Alb) Regulator

    (17) ALB regulator (hydro-pneumatic), activated via the hydraulic levelling system of the hydro-pneumatic tridem chassis (18) Simulator connection for pneumatically activated ALB regulator (19) Quick-release valve with integrated two-way Fig. 59 valve Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 97: Braking Axle

    5.16.1.4 Braking axle (1) Diaphragm brake cylinder (2) Slack adjuster for brake camshaft (3) Brake camshaft (4) Connecting rods for parking brake (5) Test connection for pressure gauge Fig. 62 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 98: Connect Brake And Feed Line

    When connecting the feed line (red), the system pressure coming from the tractor automatically pushes the push button for the release valve on the trailer brake valve out. 6. Release the parking brake and/or remove the chocks. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 99: Disconnect Brake And Feed Line

    The controlled hydraulic service brake system is connected to the special brake valve of the tractor. If the brake pedal on the tractor is pressed, the machine is slowed down. (1) Hydraulic sleeve ISO 5676 Fig. 63 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 100: Emergency Brake Valve

    5. Set the operating lever back to its initial position. 6. Actuate the brake system of the machine several times.  The pressure accumulator is filled and the emergency brake valve is ready for operation again. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 101: Connect Hydraulic Service Brake System

     must not chafe against external components.  Check the hydraulic service brake system for proper functioning before carrying out transport journeys. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 102: Disconnect Hydraulic Service Brake System

    (1) Crank handle; in adjusting position (2) (2) Adjusting position (3) Resting position; swivelled by 180° compared to the adjusting position Fig. 67 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 103 1. Swivel the crank handle (1) from resting position (3) by 180° to adjusting position (2). 2. Turn the crank handle clockwise. The parking brake is applied via the cable (5).  Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 104: Operation

    The ISOBUS control set is automatically switched on and off when the tractor ignition is turned on and off. In case of longer downtimes of the machine, additionally disconnect the mobile tractor connecting cable. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 105 (8) to carry out the selected functions. Individual sensors (3) determine the respective operating state of the selected assembly, e. g. Steering axle locked or Steering axle unlocked. The operating states are graphically shown on the screen (9). Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 106 11) (10) Double feed rate of transport floor for complete emptying (transport floor level II)/Increase feed rate of transport floor Fig. 69 during discharge (in combination with key Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 107 (18) Retract cutting unit (19) Extend cutting unit (20) Lock steering axle (21) Unlock steering axle (22) Lift pick-up (23) Lower pick-up to open-centre position/ no open-centre position (rigid) Fig. 70 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 108: Display Information In Working Menu

    (10) Operating state "Cutting unit extended/retracted", here "Cutting unit retracted" (11) Operating state "Steering axle locked/unlocked", here "Steering axle unlocked" (12) Operating state "Crossover conveyor ccw rotation on/cw rotation/stop", here "Crossover conveyor cw rotation on" Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 109: Functions And Their Symbols

    Working menu appear: (1) Warning message (2) Pick-up down (3) Tailgate lifted (4) Transport floor powered (5) Dosing drums powered Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 110 (optional extra) are switched off,  the work light (optional extra) is switched on if the work light was on when carrying out the function "Switch on road travel mode". Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 111 The Discharge mode A II is automatically switched off when the tailgate is lowered. During discharge, the transport floor feed can be switched on and off as often as desired by pressing the key. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 112  With the dosing drums powered, the "Dosing drums On" symbol appears. With the transport floor powered, the "Feed On" symbol is permanently lit. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 113 The "Automatic charging system on" symbol appears. The screen shows: 2. Press the key again.  The automatic charging system is switched off. The "Automatic charging system off" symbol appears. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 114 The screen shows: 1. Press the key once during discharge.  The feed rate of the transport floor is doubled. The symbols "Double set feed rate" and "Double feed" appear. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 115 2. Press the key.  The transport floor starts running and conveys the loaded material away from the dosing drums for a maximum time of 3 seconds. The "Reverse feed" symbol appears. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 116 If the cargo space lighting is switched on:  the lighting is automatically switched off if the road travel mode is switched on,  the lighting is automatically switched on if the road travel mode is switched off. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 117 "Tailgate lifted" symbol appears. 2. Release the key and press it again.  The tailgate is lifted as long as the key is pressed or until the tailgate has been completely lifted. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 118 1. Press the key until the folding no additional symbol drawbar has been lowered to the desired position or has reached its end position.  The ground clearance of the pick-up is reduced. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 119 It is absolutely necessary to lock the steering axle:  before travelling over bunker silos,  at travelling speeds of more than 40 km/h,  on rough road tracks,  when traversing hills,  before carrying out reverse travels. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 120 In Discharge mode A I, the steering axle is automatically locked at speeds up to 12 km/h. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 121 If the symbol is flashing and a beep is emitted, there is a malfunction in the steering system. The follow-up steering is activated. Check the steering system. Only in discharge mode A I or A II respectively: Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 122 The steering system works. Lift pick-up The screen shows: 1. Press the key until the pick-up has no additional symbol been lifted to its end position.  The pick-up raises. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 123: Set Machine Parameters

    The machine parameters are set in the SET menu. Depending on the machine model and the machine's equipment, the indicated symbols may differ. The arrow in the centre indicates which parameter may currently be changed. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 124: Call Up Set Menu

    (6) Left: Display of current software version Right: Entry whether equipped with dosing drums or not; here "with dosing drums" (7) Entry of steering axle model (8) Vacant (9) Display of total number of service hours Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 125: Set Machine Model

    The parameter "Steering axle model" (7) is selected. 3. Press the key to change the setting. Observe the fact that the setting "BPW" must be selected both for BPW and FAD axles with single-acting hydraulic cylinders! Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 126: Pre-Select Filling Degree Of Loaded Material In Cargo Space

    The filling degree (1) is changed. „Ausladung“ = Filling degree „Wert ändern“ = Change value „zurück“ = Backwards 3. Press the key.  The Working menu appears with the "Automatic charging system on" symbol. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 127: Calibration

    9. The person in the cargo space swivels the Fig. 71 sensing band to the top position which shall be the start position for the transport floor running at maximum feed rate. 10. Press the key again. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 128: Operating Hours Counter, Service Hours Counter And Transported Loads Counter

    ISOBUS control set is in switched-on mode.  Total number of transported loads counter. The total number of transported loads counter registers the number of transported loads during the overall period of use of the machine. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 129: Call Up Counter Menu

    2. Press and hold the key once.  The daily service hours counter and the daily transported loads counter are reset. 3. Press the key once.  The Working menu appears. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 130: Sensor And State Overview

    Tailgate completely lifted No response of sensor Response of sensor Tailgate completely lowered No response of sensor Response of sensor Speed at dosing unit No response of sensor Response of sensor Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 131: Call Up State Overview

    (1) Sensor number (2) Sensor status (3) Number of sensor circuits 2. Press the key to display the next or preceding sensor. 2. Press the key once.  The Working menu appears. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 132: Ses System

     is equipped with a safety circuit such that in case of malfunctions the steering system works as a pure follow-up steering system,  allows error diagnosis. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 133: Steering Computer Displays

    The steering rods are not coupled or the specified steering range has been exceeded alarm code Error message; an active error has been detected xxx-xxx-xx If several active errors are detected, the respective error messages will be displayed one after the other. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 134: Error Diagnosis

    5. Press the key once.  The details referring to the selected error message are successively displayed. 6. Press the key once.  The Error diagnosis menu is exited. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 135: Commissioning

    This shall not apply to movements of devices:  in continuous action for constant loads,  with automatic control,  which, for functional reasons, require an open-centre or pressing position. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 136: Check Tractor's Compatibility

    The gross vehicle weight rating of the tractor, which is specified in the operating instructions/in the tractor's vehicle registration certificate, must exceed the sum of:  the tractor's empty weight,  the ballasting mass,  the tongue load of the hitched machine. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 137: Preconditions For The Operation Of Tractors With Rigid Drawbar Trailers

    Drawbar lug (hitch ring) ISO 5692-1 Draw pin (Piton-Fix) Drawbar lug (hitch ring) ISO 6489-4 ISO 5692-1 4000 kg ≤ 40 km/h Ball-type coupling 80 Shell 80 2000 kg > 40 km/h Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 138: C Value For Combination To Be Coupled

    Axle load/sum of axle loads of the machine charged with the admissible mass (loading capacity) in [t] without tongue load Gravitational acceleration (9.81 m/s²) Actual calculated D value for the Specified D values of the tractor's coupling combination device and the machine's drawgear  Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 139: Calculate Tractor's Admissible Towing Capacity

    Due to the D value of the tractor's coupling device, the admissible axle load is 14.5 t. This calculated axle load must not be exceeded when charging your rigid drawbar trailer. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 140: Mount Control Set On The Tractor

    ISO socket (5) of the mobile cable harness into the ISO plug of the control unit on the machine.  the ISO plug of the control unit into the ISO socket of the tractor. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 141: Mount Attachment Sections, Ropes And Body Tarpaulin

    4 m is not exceeded. 5. Screw the attachment sections (5) to the fixing supports (6). 6. Screw the two body tops (7) to the fixing supports at the front. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 142 10. Hang the respective rope hook of the rubber clamp into the rear tubular support (1). Fig. 80 11. Bend the rope hooks such that they are closed. Thus, unhooking of the ropes will be prevented. Fig. 81 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 143: Adjust Mounting Height Of Folding Drawbar

    3. Secure tractor and machine against accidental starting and rolling. 4. Unscrew the counter nut (2) of the threaded spindle (3). Fig. 83 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 144: Mount Shell To Folding Drawbar

    1. Mount the washer (1). 2. Fasten the shell (2) by means of the two screws (3). 3. Tighten the nuts of the screws (3) at a tightening torque of 2300 Nm. Fig. 85 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 145: Adjust Length Of Propeller Shaft To Tractor

     The adjustment of the propeller shaft only applies to the current tractor model. Readjustment of the propeller shaft may be necessary if hitching the machine to another tractor. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 146: Check Machine For Proper Functioning

    After a longer downtime of the machine:  bleed the friction clutch of the pick-up, in order to ensure its proper functioning, see chapter "Bleed friction clutch of pick-up", page 200. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 147: Hitch And Unhitch Machine

    Observe the course of the supply lines during hitching. The supply lines:  must easily give way to any movements during cornering without any stress, buckling or chafing,  must not chafe against external components. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 148: Unhitch Machine

    5. Disconnect the hydraulic hose pipes. Observe the information in the chapter "Disconnect hydraulic hose pipes", page 76. 6. Disconnect the brake system. Observe the information in the chapter "Disconnect brake and feed line", page 99. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 149: Settings

     make sure that third persons (children) leave the tractor,  secure lifted machine parts against accidental lowering. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 150: Pick-Up

    (3) of the roller feeler (4), while using your other hand to hang the perforated strut of the pick-up spindle into the desired borehole. 5. Secure the pick-up spindle by means of the bottom linch pin. Fig. 86 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 151: Set Additional Roller Feelers

    The frame must be beneath the check screws (7). The minimum distance between the additional roller feelers and the CFS drum (8) must be 10 mm. Adjust the distance if necessary. Fig. 88 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 152: Set Holding-Down Device With Pulley

    Small swathe = small distance; if the distance is too large, the material to be loaded is not picked up properly 1. Set the desired distance between pick-up and holding-down device/pulley by means of the chain length (4). Fig. 89 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 153: Set Cutting Length

     if tractor and machine have not been secured against accidental rolling by means of their respective parking brake and/or the chocks. Close open protective devices before powering the machine. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 154 Clean the cutting unit, in particular the retainer of the cutting knives, and the cutting knives themselves every day. Permanent oil circulation between tractor and machine is required for initiating the individual hydraulic functions. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 155: Charging

    152.  check whether the desired cutting length of the loaded material can be achieved by means of the number of mounted cutting knives, see chapter "Set cutting length", page 153. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 156 When the machine is fully charged, the ISOBUS control set generates an acoustic signal (horn sound) and a visual signal "Forage wagon full". The automatic charging system is deactivated and the automatic feed function for the transport floor is switched off. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 157: Determine Admissible Loading Capacity

    "Technical data", page 23. Max. admissible load = Admissible axle load - Empty weight Max. load [kg] Max. admissible loading capacity Specific weight of loaded material [kg/m Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 158: Bulk Densities Of Different Materials

    The following functions will be automatically carried out one after the other: 4.1 Lift tailgate 4.2 Switch transport floor on when the tailgate reaches its end position. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 159 Risk of being drawn in and becoming entangled within the area of powered dosing drums when opening and closing the tailgate and when discharging the machine! Make sure that people leave the swivelling range of the tailgate before pressing the key. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 160 6.6 Let the tractor's p.t.o. shaft smoothly start to run such that the dosing drums are able to loosen themselves.  The dosing drums start to run and after a short delay, the transport floor automatically starts. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 161 20 mm. 13. Press the key once to switch on the Road travel mode for transport journeys. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 162: Eliminate Clogging At The Pick-Up And The Feeder Rotor

    Secure tractor and machine against accidental starting and rolling before manually eliminating clogging/blockages. 1. Switch the p.t.o. shaft off. 2. Secure tractor and machine against accidental starting and rolling. 3. Eliminate the clogging/blockages.. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 163: Secure Tractor And Machine Against Accidental Starting And Rolling

    7. Secure the machine against rolling:  on even ground by means of the parking brake or the chocks,  on extremely uneven ground or downhill gradients by means of the parking brake and the chocks. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 164: Transport Journeys

    Only with the lift axle completely lowered is the ALB regulator able to properly control the required braking force. 2. Deactivate the automatic charging system and close the front panel. 3. Activate the Road travel mode on your control set. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 165: Transport Journeys With Partly Discharged Machine

    50%. The transport floor may be reversed for a short time (max. 3 seconds) for this purpose. Observe the fact that the driving characteristics of the tractor are influenced by the load, in particular if the machine is partly empty. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 166: Service And Maintenance Of Machine

    In case of higher loads and amount of stress, maintenance work must be carried out at respectively shorter intervals. This shall in particular apply to the brakes. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 167 Risk of crushing and impact to people due to accidental lowering of the lifted tailgate. Secure the lifted tailgate against accidental lowering by means of the stop-cock before entering the hazardous area beneath the lifted tailgate. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 168: Service And Maintenance Plan - Overview

      the parking brake for smooth action. Lubricate all movable parts of the parking brake if necessary. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 169 Check spring clamps for tightness, retighten alternately and in several steps if necessary,  check spring bearing bolts for tightness, retighten alternately and in several steps if necessary,  check axle bolts for tightness, retighten alternately and in several steps if necessary. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 170  BPW chassis:  Check dash pots for tightness, seal if necessary,  check fastening device of dash pots for tight fit and wear, retighten or have replaced if necessary, Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 171: Tightening Torques

    ** "Dry" means that normal or galvanized screws without any lubrication are used. The tightening torques listed in the above table are reference values. They apply provided that these operating instructions do not specify other tightening torques for certain screws or nuts. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 172: Tightening Torques Of Wheel Nuts

    Flat collar nut with spring washer M22 x 1.5 630 Nm Spherical collar nut M22 x 1.5 450 Nm 460 Nm 460 Nm 505 Nm Flat collar nut with spring washer Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 173: Enter Cargo Space

    Lubricate the machine after cleaning, especially after cleaning by means of a pressure washer/steam blaster or fat dissolving agents.  Continuously inspect the machine for corrosion damage! Remedy corrosion damage by touching up paintwork. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 174: Lubrication Of Machine

    Damage to bearings, seals etc. may occur if the grease gun used is not equipped with a protective device. Observe the included sub-supplier documentation for lubrication of the propeller shaft(s)! Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 175: Lubrication Plan

    Service and maintenance of machine 12.5.1 Lubrication plan Giga-Vitesse CFS Fig. 91 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 176 Service and maintenance of machine Giga-Vitesse CFS DO Fig. 92 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 177: Preservation/Longer Downtimes

    EP80W-90 SAE 500 h Rotor gear Carter EP 680 23.0 Angular switchgear Carter EP 680 Dosing unit Angular gear CFS Carter EP 680 Angular gear, dosing drums EP80W-90 SAE 2000 h Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 178: Feed Gearing Of Transport Floor

    (1) Oil inspection plug (2) Oil filling screw (3) Oil drain plug Fig. 93 12.7.3 Main gearbox of cutting unit (1) Oil inspection plug (2) Oil filling screw (3) Oil drain plug Fig. 94 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 179: Rotor Gear Of Cutting Unit

    (3) Oil drain plug Fig. 95 12.7.5 Angular switchgear of cutting unit Check the oil level with the pick-up lowered. (1) Oil inspection plug (2) Oil filling screw (3) Oil drain plug Fig. 96 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 180: Angular Gear Of Cfs Unit

    Angular gear of CFS unit (1) Oil inspection plug (2) Oil filling screw (3) Oil drain plug Fig. 97 12.7.7 Angular gear of dosing unit (1) Oil filling screw (2) Oil drain plug Fig. 98 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 181: Check/Top Up Oil Level

    7. Fill the specified oil quantity in through the oil filler neck. 8. Clean the oil filling screw and screw it in. 9. Check the oil level after 5 service hours. The oil must be visible at the oil inspection plug. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 182: Hydraulic System

     Depressurize the hydraulic system before carrying out work on the hydraulic system. 1. Relieve the respective hydraulic cylinder via the corresponding operating element with the hydraulic pump switched off. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 183: Depressurise Folding Drawbar With Drawbar Suspension

    6 years. Example: Date of manufacture Period of use expires 07/10 = October 2007 October 2013 After expiration of the period of use, the hydraulic hose pipe must no longer be used. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 184: Inspection Criteria For Hydraulic Hose Pipes

    Replacement of the hydraulic filter is not allowed with the hydraulic system being under operating pressure.  Only replace the hydraulic filter when the hydraulic system of the machine is not connected to the tractor. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 185 10. Tighten the screwed connection at a torque of 150 Nm. 11. Switch the hydraulic system on and bleed the filter at an appropriate point. 12. Check the filter for leaks. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 186: Hydraulic Levelling System

    (2) with hydraulic oil. When the chassis rebounds, the hydraulic cylinder takes in hydraulic oil from the oil storage tank thus continuously moistening the piston chamber with hydraulic oil. Fig. 102 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 187: Drain Condensate

    Fig. 104 Torque = 75 Nm 7. Properly readjust the travelling height of the hydraulic levelling system. Observe the information in the chapter "Adjust travelling height of hydraulic levelling system", page Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 188: Check/Top Up Oil Level

    6.11 Retighten the screwed connection. 7. Properly readjust the travelling height of the hydraulic levelling system. Observe the information in the chapter "Adjust travelling height of hydraulic levelling system", page 81. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 189: Tyres

     Only qualified personnel equipped with appropriate fitting tools is allowed to carry out repair work on tyres and wheels.  Never use or repair damaged rims. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 190: Change Tyres

    3. Tighten the wheel nuts at the required tightening torque, see chapter "Tightening torques of wheel nuts", page 172. 4. Check the wheel nuts for tightness after 10 service hours. Retighten wheel nuts if necessary Fig. 108 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 191: Brake System

    (1) in the hose couplings of the brake and feed line before connecting the hose couplings to the tractor. The filter element can be inspected through the opening (2) beneath the plastic lid. Fig. 109 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 192: Set Compressed-Air Brake System

    5 mm in case of riveted linings,   2 mm in case of glued linings. 4. Replace the brake linings if necessary. Fig. 111 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 193: Set Hydraulic Brake System

    Check the spring clamps for tightness after the first journey with loaded material and every 250 service hours! Observe the fact that welding work on the link spring is not allowed! Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 194 4. Secure the crown nuts by means of the safety bolt. Check bushings for wear: 1. Remove the axle bolts. 2. Check the bushings for wear. 3. Insert the axle bolts with grease. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 195: Maintenance Instructions For Bpw Chassis

    (1) Lubrication points of dash pot 1. Grease the lubrication points at the top and bottom of the dash pot on the empty machine until fresh grease is coming out of the bearings. Fig. 114 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 196 2. In case of a loosened screwed connection, tighten the nuts alternately and in several steps. M24: Torque = 650 Nm (605-715 Nm) Observe the fact that welding work on the link spring is not allowed! Fig. 117 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 197: Transport Floor

    Fig. 120 The chains of the transport floor:  are automatically pre-tightened,  must be tightened equally, but not too firmly,  are only allowed to sag slightly. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 198: Shorten And Tighten Transport Floor Chain

    14. Close the access door. 15. Fold the ladder up. 16. Lock the ladder and the access door by means of the locking mechanism. 17. Use the stop-cock to unlock the tailgate. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 199: Lubricate Chain Tensioners And Deflection Points Of Transport Floor

    Powering of the pick-up is not allowed with the side protector opened and/or the protective casing of the pick-up removed. Fix the protective casing of the pick-up properly to the machine and close the right-hand movable side protector before operating the machine. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 200: Bleed Friction Clutch Of Pick-Up

    Torque of friction clutch: 900-1000 Nm 12. Lock the groove nut. 13. Fix the protective casing of the pick-up to the machine by means of the two screws. Fig. 125 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 201: Check/Retighten Tension Of Roller Chain For Pick-Up Drive

    12.15.1 Bleed friction and compensating clutch of CFS drum The friction and compensating clutch must be bled before the first start-up and after longer downtimes to ensure its proper functioning. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 202: Remove/Mount Friction And Compensating Clutch Of Cfs Drum

    9. Pull the friction and overrunning clutch (7) off to the side. 10. Mount the friction and overrunning clutch in reverse order. 11. Close the right-hand movable side protector Fig. 129 and lock it in protective position. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 203: Align Switch Rods With Respect To The Switch Levers Of The Angular Switchgear

    12. Close the tailgate. 12.16 Cutting unit CAUTION Risk of cuts when carrying out assembly work on sharp cutting knives! Wear cut-proof protective gloves when carrying out work on the cutting knives. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 204: Clean Cutting Unit

    12.16.2 Clean knife security system Mounting lever and knife lever are accommodated in the holder (1) on the left-hand machine side (in direction of motion) in the vehicle frame at the cutting unit. Fig. 131 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 205 2.4 Hang up the spring at the outer ring of the knife holder by means of the mounting lever. 2.5 Repeat steps 2.1 to 2.4 for the other knife holders. Fig. 133 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 206: Remove And Install Cutting Knives

    (4) out of the holder (5). The holder is positioned on the left-hand machine side (in direction of motion) in the vehicle frame at the cutting unit. Fig. 135 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 207: Install Cutting Knives

    Extending the cutting unit into the conveyor duct is not allowed if:  people are beneath the machine,  people may reach or reach into the dangerous spots alongside the cutting unit. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 208: Grind Cutting Knives

    (every 24 hours).  Use a right-angle grinder with a flap grinding wheel when grinding the cutting knives.  Only grind the cutting knives on their smooth side, never on their corrugated side. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 209: Set Distance Between Cutting Knives And Rotor

    5.2 Remove the bolt (4) to loosen the upper link fork (Fig. 140/3) from the receiver pipe (5). 5.3 Turn the respective upper link fork to set the distance between the cutting knives and the rotor. Fig. 139 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 210: Check Distance Between Strippers And Rotor

    17 mm over the complete width of the rotor. The distance must not fall below the minimum value. Reasons for a too small distance between strippers and rotor are:  worn strippers or  deformed stripper holders. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 211 3.3 Remove worn strippers by pulling them out to the bottom. 3.4 Mount new strippers in reverse order. 4. Have deformed stripper holders replaced by an authorised workshop. (Shop work) Fig. 141 Fig. 142 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 212: Set "Cutting Unit Retracted" Sensor

    2. Lubricate the roller chains by means of grease or engine oil. 3. Close the protective devices and lock them in protective position. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 213: Check/Retighten Tension Of Roller Chains Of Dosing Drums

    Fig. 145 3.3 Retighten the tightening wheel bolt. 4. Lubricate the respective roller chain by means of grease or engine oil. 5. Close the protective devices and lock them in protective position. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 214: Malfunctions And Remedy

    Replace hydraulic plug Too little hydraulic power in Hydraulic plugs too small Provide appropriately large load-sensing mode hydraulic plugs Load-sensing control pressure Possibly use pressure too low intensifier; consult the manufacturer Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 215: Electrics

    The display of a function does Defective wiring (short-circuit) Check wires, replace them if not show a status message on necessary the control set Sensor not properly set Adjust sensor Defective sensor Replace sensor Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 216: Working

    Cutting unit cannot be extended Cutting unit soiled between Clean cutting unit cutting knives and conveying trough Conveyor duct clogged Clean conveyor duct Cutting knives bent Align or replace cutting knives Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 217 Adapt charging degree machine side significantly lowers escaping via pressure limiting valve Plug screw at level block not Tighten plug screw tightened Unequal load of axle one and Possibly adjust travelling height Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 218: Circuit Diagrams

    Circuit diagrams Circuit diagrams 14.1 Hydraulics – ISOBUS control Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 219 (14) Y23 and Y24 with active drawbar suspension energised (15) Levelling system (16) Electro-hydraulic forced steering axle (17) Steering cylinder (X) only mounted with crossover conveyor (Y) only mounted with electro-hydraulic forced steering axle Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 220: Electronics - Isobus Control Field-Operator 120 - Cable Harness Overview

    (3) Silage additive pump (4) Pre-selection Y31 (5) Proportional (6) Return line of transport floor (7) Pre-selection Y30 (8) Steering axle (9) Folding drawbar (10) Tailgate (11) Pick-up (12) Cutting unit (13) Central lubrication Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 221 Circuit diagrams This page has intentionally been left blank. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 222: Electronics - Isobus Control Field-Operator 120 - Valves

    Circuit diagrams 14.3 Electronics – ISOBUS control Field-Operator 120 – Valves Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 223 Ground, valves 1 16/42 Ground, transport floor level II 27/42 Ground, valves 4 28/42 Tailgate 29/42 Folding drawbar 30/42 Ground, silage additive pump 41/42 Ground, valves 3 42/42 Ground, valves 2 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 224: Electronics - Isobus Control Field-Operator 120 - Sensors

    Circuit diagrams 14.4 Electronics – ISOBUS control Field-Operator 120 – Sensors Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 225 Tailgate lowered, left-hand Tailgate completely lifted Speed, dosing drums, left-hand Speed, dosing drums, right-hand Potentiometer, automatic charging system Knife protection system (transmitter) Knife protection system (receiver) Machine is full Pressure switch Axle unlocked Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 226: Electronics - Isobus Control Field-Operator 120 - Control Unit, Extension Module/Lin Module

    Circuit diagrams 14.5 Electronics – ISOBUS control Field-Operator 120 – Control unit, extension module/LIN module Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 227 (7) Lift axle (optional extra) (8) Lower axle (optional extra) E1 Work lights, front grating E2 Work light, rear, left-hand E3 Work light, rear, right-hand E4 Work lights (optional extra) E5 Warning beacon (optional extra) Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

  • Page 228: Connection Of Lighting System

    Additional electrical loads are e. g. a silage additive pump or additional lighting (more than 2 lamps). We offer an additional control for additional loads which triggers these additional loads via relays. Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 229 Discharging ..........158 Cargo space lighting ........116 Dosing drums ..........66 CFS drum Maintenance ..........212 Maintenance ..........201 Drawbar ............84 Chassis ............77 Ball-type coupling ........ 86, 87 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 230 Reset daily counter ......... 129 Roller feelers ..........151 ISOBUS control set Field-Operator 120 Ropes ............141 Calibrate automatic charging system ..127 Counter ............ 128 Functions ..........109 Safety and protective devices ....... 34 Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...
  • Page 231 Operating height of pick-up ...... 150 Warning message ........109 Shop work ............33 Warning signs ..........45 Silage additive pump ........58 Warranty ............35 Spare and wearing parts ....... 35 Steering axle Giga-Vitesse CFS 3201-4401, Giga-Vitesse CFS 3601 DO-4401 DO 06.13...

This manual is also suitable for:

Giga-vitesse cfs 3601Giga-vitesse cfs 4001Giga-vitesse cfs 4401Giga-vitesse cfs 3201 doGiga-vitesse cfs 3601 doGiga-vitesse cfs 4001 do ... Show all

Table of Contents
