Important Note - Intex 164414ND Owner's Manual

IMPORTANT NOTE

Proper inflation of the air bed.
The ambient temperatures of air have an effect on the air bed internal pressure. At low
ambient temperature the air will contract within the air bed and the air bed will feel softer:
add air as necessary. At high ambient temperature the air within the air bed will expand
significantly and the air bed will become hard and may burst: release air to avoid damage
to the air bed or to soften the feel. Do not expose the air bed to extreme temperatures
(hot or cold).
Stretching is a natural characteristic of new vinyl. During initial use, the air bed may
become soft and require additional inflation to maintain desired firmness. This is normal for
the first few days of use.
Dimensions shown are approximate and will vary due to the vinyl temperature and the air
temperature.
In no event shall Intex, their authorized agents or employees be liable for damages
(such as pin holes) to the air bed caused by negligence, ordinary wear and tear,
abuse and carelessness, or external forces.
DEFLATION
1. Plug in the AC power cord into an AC electrical outlet. See Fig (2).
2. Turn the control dial fully counterclockwise until it stops. The pump is now deflating the
air bed. See Fig (5).
Deflate
Position
3. When all the air is removed from the air bed, turn the control dial back (clockwise) to the
center position which closes the valve and turns the pump off.
4. Disconnect the AC power cord from the electrical outlet, coil the power cord and place it
inside the cord compartment, then close the cover. Make sure the power cord is free of
twists, kinks or knots.
5. With the air bed fully deflated begin rolling the air bed from the end opposite of the pump
towards the end where the pump is located. See Fig (6).
MANUAL INFLATION OPTION
If electrical power is not available, a conventional foot, manual, or battery-operated air
pump can be used by connecting it to the manual inflation port located inside the power cord
compartment. See Fig (7). Follow these steps:
SAVE THESE INSTRUCTIONS
(17IO) AP620D/AP620DP ELECTRIC PUMP ENGLISH 4.875" X 7.25" 05/29/2022
FIG (5)
Page 4
17
IO
FIG (6)
