Summary of Contents for Safescan 6175
- Page 1 User Manual English 6175 Money Counting Scale...
-
Page 2: Table Of Contents
5.4. Counting coin rolls Rechargeable battery (Optional accessory) 5.4.1. Counting coin rolls/bags with automatic coin roll 9.1. Installing the Safescan LB-205 rechargeable battery recognition ‘AUTO’ 9.2. Rechargeable battery status indication 5.4.2. Counting coin rolls / bags that are similar in weight 5.4.3. -
Page 3: Package Contents
1. Поставете устройството на равна повърхност и platformę na pieniądze. присъединете платформата за пари. Safescan® is a registered trademark of Solid Control Holding B.V. No information may be reproduced in any form, by print, copy or in any other way without prior written 2. Podłącz urządzenie i zasilacz. 2. Свържете устройството и захранващия адаптер. permission of Solid Control Holding B.V. Solid Control Holding B.V. reserves all intellectual and industrial property rights such as any and all of their patent, trademark, design, 3. Włącz urządzenie ( ) bez korzystania z pojemnika na... -
Page 4: Display And Buttons
MENU 12. Power ON / OFF 13. Open settings menu 14. Clear entry / back 15. Navigation keys 16. Confirm selection / Add value to total More info, articles, tutorials and videos support.safescan.com More info, articles, tutorials and videos support.safescan.com... -
Page 5: Set Region (Location Of Use)
UK, USA, S-E ASIA and will be used. save your preference. with the smallest denomina- AUSTRALIA). tion. MENU MENU 3. Once you have selected the correct region, press “OK”. MENU More info, articles, tutorials and videos support.safescan.com More info, articles, tutorials and videos support.safescan.com... -
Page 6: Counting Instructions
The 6175 will automatically switch to the next coin denomination. Alternatively, use the ( ) buttons to select a denomination. After the highest value coin denomination has been counted,... -
Page 7: Counting Banknotes
Please do so in small batches of maximum 25 banknotes to ensure the most accurate count. 360.00 360.00 360.00 360.00 More info, articles, tutorials and videos support.safescan.com More info, articles, tutorials and videos support.safescan.com... -
Page 8: Too Many Banknotes On The Platform
The display shows “Remove Some”. Remove a few banknotes (max. 5 notes at a time) until the 6175 has been able to determine the number of banknotes. Continue to add more banknotes on the platform in small batches. -
Page 9: Counting Coin Rolls
5.4.1. Counting coin rolls/bags with automatic coin roll If the weight difference between the different versions is not within the limit, the Safescan 6175 may ask you to count them seperately. recognition ‘AUTO’ The versions are indicated on the display. -
Page 10: Counting Coin Rolls / Bags That Are Similar In Weight
Some currencies have coin packages that are different in denomination but similar in weight. When such a package is detected, the Safescan 6175 will give you the opportunity to select the correct denomination. Please see an example below of how to operate this function. -
Page 11: Counting/Viewing Coin Rolls/Bags Per Denomination
Place one complete coin roll of A beep sounds after the selected denomination on confirming the coin roll. The the money platform. quantity, value and roll- denomination is shown. More info, articles, tutorials and videos support.safescan.com More info, articles, tutorials and videos support.safescan.com... -
Page 12: Ending A Count
“accept” to save the count to select ‘AUTO’ coin rolls and press “OK” to view the separate result. When you have saved one or more counts in the 6175’s coin roll results. memory, click on the Count Data icon to download these count results from the Safescan 6175 to your computer. -
Page 13: General Operation
6.2. Menu structure This chapter contains operational instructions and explains the You can enter the device menu by pressing the “MENU” button. different menu structures of the Safescan 6175. To navigate through the items, use the ( ) buttons. To enter a option, press “OK”. -
Page 14: New Count
A ‘*’ will show in the screen and the value will change back to zero. Once the default item is removed, it’s weight will show as a negative value. More info, articles, tutorials and videos support.safescan.com More info, articles, tutorials and videos support.safescan.com... -
Page 15: Currency
When you want to change the The active currency is now currency, press “OK” when shown, with 2 blinking arrows. Besides loose coins and banknotes, the Safescan 6175 can also the “CURRENCY” screen is Use ( ) to navigate to the count coin rolls, coin bags, banknote bundles, non-cash items shown. -
Page 16: Calibrating Non-Cash Items
English English 6.7. Calibrating non-cash items The Safescan 6175 can also count non-cash item such as vouchers, coupons, token and chips. Follow the instructions below to calibrate these items and make them available in the count menu. 6.7.1. Calibrating vouchers... -
Page 17: Calibrating Tokens
Press “OK” to confirm. next voucher for calibration. Press “OK” to calibrate the next voucher or press “CE” to exit the calibration menu. More info, articles, tutorials and videos support.safescan.com More info, articles, tutorials and videos support.safescan.com... -
Page 18: Calibrating A Second Coin Cup
Press “OK” to return to the count screen. From now on, once you start up the Safescan 6175, you will be asked to confirm which cup has to be set as preference: the cup that comes with the device as a default (CUP 1) or the cup that was calibrated (CUP 2). -
Page 19: Set Device
33.5 grams. If your cash drawer contains cups with a different weight, you can configure the Safescan 6175 to recognise them. Press “OK” to enter this menu item. When in the ”SET DEVICE” mode, use the ( ) buttons to navigate through the sub-items. - Page 20 English English B. AUTO ADD By activating the AUTO ADD function, the Safescan 6175 will automatically add the quantity and value of the counted denomination to the total results when the denomination is removed from the platform. The AUTO ADD function is always turned on by default.
- Page 21 D. AUTO BANK By activating the AUTO NEXT function, the machine automatically When activating the AUTO BANK feature, the Safescan 6175 will switches to the next denomination once the items are removed ask you to set your bank amount at the start of each new count.
- Page 22 English F. Recalibrate load cell E. AUTO REF When activating the AUTO REF feature, the Safescan 6175 will ask If (due to an overload or heavy you to insert a reference number at the start of each new count. impact) the load cell / weighing...
-
Page 23: View Saved Count Results
Press “OK” to start resetting the machine. If you want to start updates (when applicable) are available via www.safescan.com. fresh with your Safescan 6175, you can reset the device back to Download the firmware update package and follow the included its default factory settings. -
Page 24: Clear All Counts
) keys to navigate through the different features and press ‘’OK’’ to select one. If the two arrow keys are blinking, you are able to navigate between the available menu items. More info, articles, tutorials and videos support.safescan.com More info, articles, tutorials and videos support.safescan.com... -
Page 25: Count Menu Structure
If you want to use another feature(s) of the count menu, then press “OK” again to open the count menu. See 7.6. Print count result See 7.5. Add reference number More info, articles, tutorials and videos support.safescan.com More info, articles, tutorials and videos support.safescan.com... -
Page 26: Set Bank
Press “CE” to enter a new result which will be deducted menu, then press ‘’OK’’ again to reference code. from your total count. open the count menu. More info, articles, tutorials and videos support.safescan.com More info, articles, tutorials and videos support.safescan.com... -
Page 27: Print
English English 7.6. Print 8. Troubleshooting This chapter describes the operation of the Safescan 6175, as well as the menu structure of the device. Error message Description SUSPECT - CHECK ITEM Incorrect number of coins detected in a coin roll /... - Page 28 Remove all weight from the the platform while the 6175 platform. If the message tares itself. disappears: continue using your 6175 as normal. If the message remains: switch off Counted quantity is not the 6175 and switch it back Counted quantity is not correct.
- Page 29 Remove .. - .. PCS REMOVE SOME The weight on the scale is too Valid for banknote counting high for the 6175 to determine only. The weight on the scale is the exact number of coins or illogical. Caused by the weight banknotes.
-
Page 30: Rechargeable Battery (Optional Accessory)
Description BATTERY LOW Battery power is lower than 5%. 9.1. Installing the Safescan LB-205 rechargeable battery 1. Disconnect the power adapter. 2. Remove the money platform from the scale. 3. Turn the device upside down and open the battery lid (see chapter 3.1). -
Page 31: Updates
- Always place the 6175 on a flat and stable surface and keep the area around the money platform clear. - To avoid damaging the device or any malfunctions, clean the device with a dry cloth. -
Page 32: Optional Accessories
- Carefully place items on the weighing platform, do not Thermal receipt printer throw or drop them. Safescan TP-230 - Do not drop, hit or shake the 6175. - Never place items weighing more than 1.5 kg on the Money Counting Software 6175. -
Page 33: Specifications
- Can also be used as precision weighing scale (note: not “approved legal for trade”). Currencies Depends on region - see www.safescan.com for more information Dimensions (LxWxH) 22.3 x 14.2 x 14.7 cm / 8.8 x 5.6 x 5.8 inch Display 4.1 inch high contrast LCD Interface USB-B to PC, RJ-10 to printer Power requirements Power supply 12V/0.5A...
