- Page 1 Keysight AP0200A Vehicle Network Interface, 2x CAN-FD User Guide...
- Page 2 227.7103-5 (c), as applicable in any Do not proceed beyond a WARNING technical data. notice until the indicated conditions are fully understood and met. Keysight AP0200A Vehicle Network Interface, 2x CAN-FD User Guide...
-
Page 3: Table Of Contents
........24 Deutsch 9-Pin Hardware Connection Diagram ....24 Keysight AP0200A Vehicle Network Interface, 2x CAN-FD User Guide... - Page 4 ........38 Keysight AP0200A Vehicle Network Interface, 2x CAN-FD User Guide...
- Page 5 List of Pin Assignments for the AP0200A ..32 Figure 6-2 LED Indications and Modes for the AP0200A ..33 Keysight AP0200A Vehicle Network Interface, 2x CAN-FD User Guide...
- Page 6 THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK. Keysight AP0200A Vehicle Network Interface, 2x CAN-FD User Guide...
- Page 7 List of Tables Table A-1 Abbreviation and Definition .....36 Keysight AP0200A Vehicle Network Interface, 2x CAN-FD User Guide...
- Page 8 THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK. Keysight AP0200A Vehicle Network Interface, 2x CAN-FD User Guide...
- Page 9 Keysight AP0200A Vehicle Network Interface, 2x CAN-FD User Guide Introduction and Overview Introduction Check the Product Operational Overview Summary of Key Features Hardware and Software Requirements...
-
Page 10: Introduction And Overview
Introduction and Overview Introduction The AP0200A is a general-purpose interface tool, providing access to multiple channels of CAN-FD. The AP0200A can be used to monitor and transmit on CAN and CAN-FD networks. It can also create hardware simulations for network analysis. -
Page 11: Check The Product
Introduction and Overview Check the Product Upon receiving the AP0200A Vehicle Network Interface, 2x CAN-FD from Keysight Technologies, perform the following product inspection: – Inspect the outer shipping container, foam-lined instrument case, and product for damage. – Retain the outer cardboard shipping container until you have inspected the contents of the shipment for completeness, and you have checked the product mechanically and electrically. -
Page 12: Package Contents
AP0200A Package Contents Your Vehicle Network Interface, 2x CAN-FD package contains the following: Standard Items: – One AP0200A Vehicle Network Interface, 2x CAN-FD device – One “Startup Guide” to help you get going quickly with your device Optional Items: – AP0200A-OBD DB9 to OBD-II Cable (2 meters) –... -
Page 13: Visual Inspection
Install AP00000A-SPY Vehicle Spy or use a limited Vehicle Spy Trial, available from Keysight's partner, Intrepid Control Systems here. It is also possible to control the AP0200A from within other software using one of the APIs that the device supports... -
Page 14: Operational Overview
– data acquisition – simulation and scripting Vehicle Network Interfacing Using the cables provided, you can connect the AP0200A to either a bench test setup or a vehicle to monitor live network activity. All channels are monitored simultaneously and are hardware time-stamped. -
Page 15: Summary Of Key Features
This section includes a summary of the device's most important design, construction, operational, and performance features: Construction, Controls, and Cabling The following details the construction, controls, and cabling of the AP0200A: – Compact design: 2" x 1.3" x 0.5" – Lightweight: less than 3 oz (80 g) –... -
Page 16: Network Interfaces And Features
Introduction and Overview Network Interfaces and Features The following details the network interfaces and features of the AP0200A: – Two dedicated dual-wire CAN / CAN-FD channels (ISO 11898-2:2015) – Both dual wires CAN channels have CAN-FD support – Support for ISO CAN-FD and NON-ISO CAN-FD –... -
Page 17: Hardware And Software Requirements
Software The setup program for AP00000A-SPY Vehicle Spy will install the necessary drivers for the AP0200A. If you do not have a AP00000A-SPY Vehicle Spy license, you can use the Vehicle Spy trial version for basic network interfacing and driver setup. - Page 18 Introduction and Overview THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK. Keysight AP0200A Vehicle Network Interface, 2x CAN-FD User Guide...
- Page 19 Keysight AP0200A Vehicle Network Interface, 2x CAN-FD User Guide AP0200A Hardware Case and Overall Design Cable Options...
-
Page 20: Ap0200A Hardware
Connectors are ruggedized by using reinforced metal connectors, and it has a rubber boot to protect the device against bumps and drops. Temperature Specification The AP0200A is operational in a temperature range from -5 °C to 60 °C. Keysight AP0200A Vehicle Network Interface, 2x CAN-FD User Guide... -
Page 21: Overview Of The Ap0200A
AP0200A Hardware Overview of the AP0200A The label of the AP0200A shows the device serial number and the pinouts of its DB-9 connector. Figure 2-2 shows the pinouts for the AP0200A connector and cable. There are three LEDs on the device indicating the status of AP0200A and its CAN connections. -
Page 22: Cable Options
– AP0200A-DB9 DB9 to J1939 Deutsch 9-pin (1.83 meters) AP0200A-OBD DB9 to OBD-II Cable (2 meters) This cable allows an AP0200A to connect and communicate over dual CAN channels on a vehicle network using a standard OBD-II port. Figure 2-3 AP0200A-OBD DB9 to OBD-II Cable (2 m) AP0200A-DB9 DB9 to J1939 Deutsch 9-pin (1.83 meters) - Page 23 Keysight AP0200A Vehicle Network Interface, 2x CAN-FD User Guide Hardware Setup Connection Diagrams Vehicle Network and Power Connections PC Connection...
-
Page 24: Hardware Setup
DB9 to J1939 Deutsch 9-pin OBD II Hardware Connection Diagram Figure 3-2 shows the OBD II hardware connection diagram. Figure 3-2 AP0200A Hardware Connection Diagram with AP0200A-OBD DB9 to OBD-II Cable Keysight AP0200A Vehicle Network Interface, 2x CAN-FD User Guide... -
Page 25: Vehicle Network And Power Connections
Vehicle Network and Power Connections The integrated DB9 connector connects the vehicle/bench CAN network(s). CAN termination is integrated into the AP0200A and can be enabled from the neoVI Explorer software interface. The AP0200A can only be powered via the USB cable. -
Page 26: Pc Connection
Connect the USB Type A to a USB port on the PC. It is possible to use a powered USB hub to connect the AP0200A, but performance varies due to the quality of the hub and its ability to provide power. Make sure to use a high-power USB hub and test the hub with the AP0200A before use. -
Page 27: Device Configuration
Keysight AP0200A Vehicle Network Interface, 2x CAN-FD User Guide Device Configuration Overview... -
Page 28: Overview
Device Configuration Overview The AP0200A ships from the factory with default settings. Default settings to consider are as follows: – Both CAN-FD networks enabled – Classical CAN mode set to 500 Kbps – CAN-FD mode set to 2 Mbps – CAN termination disabled –... -
Page 29: Core Features
Keysight AP0200A Vehicle Network Interface, 2x CAN-FD User Guide Core Features Overview... -
Page 30: Overview
Advanced users may wish to skim or even skip to the last 2 examples. The examples use Vehicle Spy 3 Professional (AP00000A-SPY). It is the ideal tool for working with your AP0200A. Due to the complexity of AP00000A-SPY Vehicle Spy, only the basics necessary are described for the examples; for full details on this software tool, press F1 on the keyboard in AP00000A-SPY VSpy to bring up the help or see the separate AP00000A-SPY VSpy documentation here. - Page 31 Keysight AP0200A Vehicle Network Interface, 2x CAN-FD User Guide Reference for Connector Pinouts and Cable Signal Mappings AP0200A Connector Pinouts LED Indications and Modes...
-
Page 32: Reference For Connector Pinouts And Cable Signal Mappings
Reference for Connector Pinouts and Cable Signal Mappings AP0200A Connector Pinouts Figure 6-1 shows the connector pinouts for AP0200A. Figure 6-1 List of Pin Assignments for the AP0200A Keysight AP0200A Vehicle Network Interface, 2x CAN-FD User Guide... -
Page 33: Led Indications And Modes
Reference for Connector Pinouts and Cable Signal Mappings LED Indications and Modes Figure 6-2 shows the LED indications and modes for AP0200A. Figure 6-2 LED Indications and Modes for the AP0200A Keysight AP0200A Vehicle Network Interface, 2x CAN-FD User Guide... - Page 34 Reference for Connector Pinouts and Cable Signal Mappings THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK. Keysight AP0200A Vehicle Network Interface, 2x CAN-FD User Guide...
-
Page 35: Appendix
Keysight AP0200A Vehicle Network Interface, 2x CAN-FD User Guide Appendix List of Abbreviations... -
Page 36: List Of Abbreviations
Table A-1 Abbreviation and Definition Abbreviation Definition Application Program Interface Controller Area Network CAN-FD Controller Area Network Flexible Data-Rate Electronic Control Unit International Organization for Standardization Personal Computer VSpy Vehicle Spy Keysight AP0200A Vehicle Network Interface, 2x CAN-FD User Guide... -
Page 37: Appendix
Keysight AP0200A Vehicle Network Interface, 2x CAN-FD User Guide Appendix Service and Support... -
Page 38: Service And Support
800 810 0189 0120 (421) 345 1 800 375 8100 Hong Kong Korea Taiwan 800 938 693 080 769 0800 0800 047 866 Other Asian Countries: (65) 6375 8100 www.keysight.com/find/contactus Keysight AP0200A Vehicle Network Interface, 2x CAN-FD User Guide... - Page 39 0805 980 333 0800 80 53 53 +32 800 58580 *0.125 €/minute United Kingdom Netherlands Germany 0800 0260 637 0800 0233 200 0800 6270 999 Other Unlisted Countries: www.keysight.com/find/contactus Keysight AP0200A Vehicle Network Interface, 2x CAN-FD User Guide...
- Page 40 Appendix THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK. Keysight AP0200A Vehicle Network Interface, 2x CAN-FD User Guide...
- Page 41 This information is subject to change without notice. Always refer to the English version at the Keysight website for the latest revision. © Keysight Technologies 2020-2021 January 2021 www.keysight.com...
