- Page 1 Ixia APS-M1010/APS-ONE-100 Release 9.17 Installation Guide 202109300428-05:00...
- Page 2 EULA represents the exclusive without prior agreement and written con- authority by which the U.S. government sent from Keysight Technologies, Inc. as may use, modify, distribute, or disclose governed by United States and inter- the Software. The EULA and the license national copyright laws.
-
Page 3: Contacting Us
Ixia APS-M1010/APS-ONE-100 Contacting Us Keysight headquarters 1400 Fountaingrove Parkway Santa Rosa, CA 95403-1738 www.ixiacom.com/contact/info Support Global Support +1 818 595 2599 support@ixiacom.com Regional and local support contacts: APAC Support +91 80 4939 6410 support@ixiacom.com Australia +61-742434942 support@ixiacom.com EMEA Support +40 21 301 5699 support-emea@ixiacom.com... -
Page 4: Documentation Conventions
Documentation conventions Documentation conventions The following documentation conventions are used in this guide: Describing interactions with the UI You can interact with products by using different input methods: keyboard, mouse, touch, and more. So in most parts of the user documentation, generic verbs have been used that work with any input method. -
Page 5: Table Of Contents
Ixia APS-M1010/APS-ONE-100 Table of Contents Contacting Us Documentation conventions Chapter 1 Product overview Chapter 2 Related documentation Chapter 3 Unpacking and inspection Chapter 4 Rack mounting Chapter 5 Front panel indicators Chapter 6 Management Node and Compute Node ports and connectivity... -
Page 6: Chapter 1 Product Overview
Ixia APS-M1010/APS-ONE-100 HAPTER Product overview Welcome to the Keysight M4100/APS-ONE-100 (APS System) Documentation. An APS System provides next-generation ultra-high-performance Layer 4 - Layer 7 application and security testing, TLS support and 100G Interfaces. Industry-proven BreakingPoint (BPS) is the user interface application. -
Page 7: Chapter 2 Related Documentation
Chapter 2 Related documentation HAPTER Related documentation The latest documentation for each release can be found on the Ixia Support website Documentation Description APS-M1010/APS-ONE-100 Provides information about new features, resolved customer Release Notes issues, known defects and workarounds (if available). APS-M1010/APS-ONE-100 This guide describes the commands that make up the command- CLI Reference Guide... -
Page 8: Chapter 3 Unpacking And Inspection
Ixia APS-M1010/APS-ONE-100 HAPTER Unpacking and inspection Carefully unpack the APS System components. Each node that is described below is shipped in its own box. 1 Management Node (APS-M1010) A 1U Management Server 2 power cords 2 tool-less rackmount slide rails... -
Page 9: Chapter 4 Rack Mounting
Ixia APS-M1010/APS-ONE-100 HAPTER Rack mounting Follow the listed procedure to rack mount the APS-M1010/APS-ONE-100 chassis. 1. Pull the inner rail out of the slide rail until it clicks. 2. Detach the inner rail completely from the slide rail by pulling the white tab forward. - Page 10 Chapter 4 Rack mounting 5. Continue installing the outer rail bracket to the mounting frame. Attach the outer rail assembling to the frame and press the bracket to form a rack on both ends. Repeat to fully mount the bracket assembly on the other side. –...
- Page 11 Chapter 4 Rack mounting 6. Pull out the middle channel until the ball bearing retainer is locked forward. Verify ball bearing retainer is locked forward. – 11 –...
- Page 12 Chapter 4 Rack mounting 7. Slide the release tab and push barebone into rack. Make sure the barebone is completely installed onto the rack. 8. Repeat this procedure until all components are rack mounted. – 12 –...
-
Page 13: Chapter 5 Front Panel Indicators
Ixia APS-M1010/APS-ONE-100 HAPTER Front panel indicators Item Description Power button Power status LED indicator Drive activity LED indicator LAN LED indicator System alert LED indicator System reset LED indicator Reset button Luggage tag Shown on the preceding chassis image 2 x USB 3.0 Type a port Shown on the preceding chassis image The luggage tag can be pulled out from its recessed position (as shown in the following image). - Page 14 Chapter 5 Front panel indicators – 14 –...
-
Page 15: Chapter 6 Management Node And Compute Node Ports And Connectivity
Ixia APS-M1010/APS-ONE-100 HAPTER Management Node and Compute Node ports and connectivity Management Node (APS-M1010) RJ-45 Ports 1 -10 (white): Ports that are used to connect and manage Compute Nodes Ports 1 – 10 correspond with slots 2 – 11 in the BPS user interface. For example, a Compute Node connected to port 4 will be managed on slot 5 in the BPS UI. - Page 16 Chapter 6 Management Node and Compute Node ports and connectivity Ports and connectors that are not described may be available for use in a future release. – 16 –...
-
Page 17: Chapter 7 Connect Power To The Management Node And Compute Nodes
Ixia APS-M1010/APS-ONE-100 HAPTER Connect power to the Management Node and Compute Nodes 1. Connect supplied power cords into the power cord sockets of the APS System chassis. 2. Plug the power cords into appropriate power receptacles. Note the following power specifications:... -
Page 18: Chapter 8 Accessing The Breakingpoint User Interface
Ixia APS-M1010/APS-ONE-100 HAPTER Accessing the BreakingPoint user interface This procedure assumes that your MN network has a DNS and DHCP server. If not, please configure a static IP address as described in the IP Configuration using KCOS CLI section. Then proceed to step 2 shown below. -
Page 19: Ip Configuration Using The Kcos Cli
Chapter 8 Accessing the BreakingPoint user interface IP Configuration using the KCOS CLI 1. Connect to the MN server: a. Connect to the micro-usb serial interface at the back of the MN (baud:115200, data bits: 8, stop bits 1, parity: None, flow control: XON/XOFF). b. - Page 20 Chapter 8 Accessing the BreakingPoint user interface The local network should not be in the subnet 192.168.0.0/24 which is used for internal communication. 6. Optionally, to configure additional IP settings/troubleshoot connectivity issues, you may want to run the following IP configuration commands: a.
- Page 21 This page intentionally left blank. – 21 –...
-
Page 22: Chapter 9 Getting Started With The Bps User Interface
Ixia APS-M1010/APS-ONE-100 HAPTER Getting Started with the BPS user interface Open a new BPS session 1. Log in to BPS as described in Accessing the BreakingPoint user interface .The BPS dashboard will display. 2. Select the New Session button under the BreakingPoint icon. -
Page 23: Access The Bps Device Manager And Reserve Ports For Testing
Chapter 9 Getting Started with the BPS user interface Access the BPS Device manager and reserve ports for testing 1. Access the Device Manager in BPS. The connected Compute Nodes should be visible. After the management node has booted up KCOS (Keysight Cluster Operating System) and initialized, the Compute Nodes that are connected to the backplane ports should automatically be powered on and registered to the current cluster. -
Page 24: Chapter 10 Connect Duts For Testing
Ixia APS-M1010/APS-ONE-100 HAPTER Connect DUTs for testing Each Compute Node supports up to two 100GE active ports for testing as shown in the following diagram. Please connect ports 1 and 3 on each compute node QSFP28 interface to run emulated traffic. -
Page 25: Chapter 11 Add Bps-Ati Licenses
Ixia APS-M1010/APS-ONE-100 HAPTER Add BPS-ATI licenses From the Device Manager access: Control Center > Administration > Licensing . Import the license files corresponding to the Compute Nodes that will be used. – 25 –... -
Page 26: Chapter 12 How To Install Software Packages
Ixia APS-M1010/APS-ONE-100 HAPTER How to install software packages Before upgrading, creating a snapshot is recommended. To create a snapshot of the current Management Node state, run the following from the admin command line: kcos snapshot create <alphanumerical name of snapshot>... -
Page 27: Chapter 13 Sample Kcos Debug Commands
Chapter 13 Sample KCOS debug commands HAPTER Sample KCOS debug commands This section lists KCOS commands that allow you to debug issues you may encounter with your APS System. Check Compute Node connectivity 1. Connect to your APS System Management Node using SSH and log in with admin/admin. 2. -
Page 28: Appendix A Safety Information
Ixia APS-M1010/APS-ONE-100 PPENDIX Safety information Before setting up and using the unit, read all of the safety information in this section and take all necessary measures to ensure your safety. Safety symbols – 28 –... -
Page 29: Safety Symbols
Appendix A Safety information Safety symbols This is the safety alert symbol: . It is used to indicate a hazard. Specific keywords and additional graphical representations are used to explain the specific nature of each hazard. The following table describes the safety warning and equipment damage icons and textual conventions used in this document. -
Page 30: Index
Ixia APS-M1010/APS-ONE-100 Index customer assistance 3 documentation conventions 4 keyboard interactions 4 mouse interactions 4 product support 3 safety symbols 29 support services 3 technical support 3 touch interactions 4 – 30 –... - Page 31 © Keysight Technologies, 2021 This information is subject to change without notice. www.keysight.com...
