Summary of Contents for Inswan INS-2
- Page 1 INS-2 USB Document Camera User Manual Package Content: - INS-2 USB Document Camera - Quick Guide - Microscope Adapters - Anti-Glare Sheet Customer Service Email : service@inswan.com Website : http://www.inswan.com TS-82-936-90020...
- Page 2 • Welcome: Thanks for purchasing this product. Please read the instructions carefully before using this product. • FCC Compliance Statement (Class A): This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received;...
- Page 3 Warning 1. Do not look directly at the LED light source, which may cause retinal damage. 2. Carry the product by holding the base of the main unit in both hands. Never hold the product by the arm or the camera head only. 3.
-
Page 4: Preparing The Document Camera
Preparing the Document Camera Knowing the Document Camera Parts 6 Auto Focus Button Microphone Led Indicator AF Switch Lamp Button LED Lamp Brightness Adjusting Button Arm Screw USB Cable Camera... -
Page 5: Working Area
Setting Up This section provides useful tips on how to adjust the document camera smoothly for your needs. 31.5cm Working Area 42cm Height 37cm for Max. working (31.5cmx 42cm) Minimum height 10cm Note : Use two coins to tighten the screws if the arm is loose. -
Page 6: Illumination Lamp
Illumination Lamp If you are in a dark environment, please turn the LED lamp on to make better exposure. Adjusting the Focus Press Focus button to do an one-time auto focus. Adjusting the Brightness Press Brightness button to increase or decrease the brightness level. -
Page 7: Basic Operation
Basic Operation Using Document Camera as a PC cam Starting the application 1. Connect the document camera to your computer Turn on your computer then connect the accessory USB cable to the USB port of your computer. Make sure the connector and the port are aligned correctly. 2. -
Page 8: Advance Operation
Advance Operation Connect to a microscope Connect to a microscope enables you to examine microscopic objects on a big screen. 1. Adjust the microscope and focus objects. 2. Choose an appropriate micoscope adapter. 3. Microscope adapter accessaries are applicable to Ø28mm ,Ø31mm, Ø33mm, and Ø34mm eyepieces. - Page 9 5. Connect the lens with microscope adapter to the microscope. If the image is not clear. Please adjust the focus of microcope. Press the Focus button to fine-tune the focus.
-
Page 10: Troubleshooting
Windows 7 does not support the image showing in Windows 7 to work on high resolution streaming higher than image streaming. 2592x1944 resolutions. http://www.codecguide. com/download_kl.htm If you have any questions, please feel free to contact us at service@inswan.com.
