- Page 1 Hall Technologies • 1234 Lakeshore Dr Suite #150 Coppell, TX 75019 • halltechav.com HT-HV75-IFP, HT-HV86-IFP Hall Vision Interactive Flat Panel USER MANUAL June 2, 2023 Hall Technologies June 2, 2023 Page 1 of 34...
- Page 2 Do not allow a still picture or an active picture containing stationary text or icons to remain on the screen for too long. This will leave a “ghost” image on the screen and will not disappear after shutdown. Hall Technologies June 2, 2023...
-
Page 3: Table Of Contents
Table of Contents Introduction ................................ 4 Overview ..............................4 Features ..............................4 Package Contents ............................... 5 HT-HV55-IFP ............................5 HT-HV75-IFP ............................5 HT-HV86-IFP ............................5 Optional Accessories ..........................5 Panel Description ............................... 6 Front Panel Buttons ..........................6 Inputs/Outputs ............................7 Installation ................................ -
Page 4: Introduction
Two RJ-45 ports for LAN bridging • Built-in wireless video casting, both from and to participants • Built-in Hotspot for sharing internet connectivity to guests • Bluetooth connection for wireless audio playback • Optional Windows OPS Hall Technologies June 2, 2023 Page 4 of 34... -
Page 5: Package Contents
Package Contents HT-HV75-IFP • 1 x 75” Interactive Flat Panel • 1 x Power Cord • 1 x Remote Controller • 2 x Stylus Pens • 2 x Batteries • 1 x Wall-mounted Bracket HT-HV86-IFP • 1 x 86” Interactive Flat Panel •... -
Page 6: Panel Description
Decreases the audio level of the built-in loudspeakers Volume Up Increases the audio level of the built-in loudspeakers Wi-Fi Support for Wi-Fi Power Switch Powers on or powers off the display Hall Technologies June 2, 2023 Page 6 of 34... -
Page 7: Inputs/Outputs
INPUTS/OUTPUTS Hall Technologies June 2, 2023 Page 7 of 34... -
Page 8: Installation
3. Install the two panel mounts to the back of the display’s VESA receiving screws using the mounting screws provided. 4. Using at least two people to lift the panel, lift and hang the display mounts to the wall mount. Hall Technologies June 2, 2023 Page 8 of 34... -
Page 9: Application Wiring
Meet, Microsoft Teams, and Zoom enable remote learning and collaboration opportunities, allowing students to connect with experts from all over the world. Wireless presentation capabilities with HT- RANGER also allow teachers to showcase student work, facilitating collaboration and creativity. Hall Technologies June 2, 2023 Page 9 of 34... -
Page 10: Integration With Ht-Calipso
Integration with HT-ODYSSEY is similar to the integration with HT-CALIPSO but brings the microphone, speakers, and laptop connections to the table. Touch signals on the Hall Vision Interactive Flat Panel pass through the HDBaseT receiver back to the HT-ODYSSEY and into the connected laptop. Hall Technologies June 2, 2023 Page 10 of 34... -
Page 11: Control - Remote Control
Acts as an escape key to return to the previous screen/menu. Switch to the optional OPS source Switch to the writing page Take a screenshot Decrease, increase, and mute the volume Hall Technologies June 2, 2023 Page 11 of 34... -
Page 12: Basic Operations - Startup / Standby
15 minutes, the panel will not enter into standby mode • Before the panel enters standby mode, the Hall Vision panel will save the picture and sound settings. Upon restart these settings will be used. Hall Technologies June 2, 2023 Page 12 of 34... -
Page 13: Basic Operations - Sidebar Buttons
Calculator, Vote, Screenshot, Screen recorder, Stopwatch, Touch Lock, Spotlight, and Touch Sound. Screen drop-down button to move the screen content down to half of the panel height. Multi-task Manager button to view and manage background-running processes. Hall Technologies June 2, 2023 Page 13 of 34... -
Page 14: Switching Sources
2. Use the navigation keys to select the desired source and click “OK” Method 2: Sidebar Button 1. Open the Sidebar Button menu and click the “Source Settings” icon ( 2. On the screen touch the desired source to switch to that source Hall Technologies June 2, 2023 Page 14 of 34... -
Page 15: Source Settings
CEC for Automatic Startup When enabled, the IFP automatically starts up when an HDMI source turns on. CEC for Automatic When enabled, the IFP automatically shuts down when an HDMI source shuts down. Shutdown Hall Technologies June 2, 2023 Page 15 of 34... -
Page 16: Audio Settings
Bass Increases or decreases the low frequencies to the loudspeakers. Treble Increases or decreases the higher frequencies to the loudspeakers. Hall Technologies June 2, 2023 Page 16 of 34... -
Page 17: Screen Drop-Down
IFP. MULTITASK MANAGER Select the sidebar menu and click the file icon ( ) to view and manage background running processes. Press the ‘X’ to close an application. Hall Technologies June 2, 2023 Page 17 of 34... -
Page 18: Basic Operations - System Settings
Channel: Changes the Wi-Fi channel to be broadcast on. • QR Code Share: When enabled it provides users with a QR code to quickly connect to the Hotspot. Bluetooth Enables or disables the Bluetooth feature. Hall Technologies June 2, 2023 Page 18 of 34... -
Page 19: Volume And Display
To access Volume and Display settings, click on the applications sidebar settings button ( UI Element Description Select and control the desired audio input when an external USB and/or wired Audio Input microphone is connected. USB Camera Select the USB camera. Hall Technologies June 2, 2023 Page 19 of 34... -
Page 20: Wallpaper
3840x2160. (To maintain best performance of the IFP, keep the file size smaller.) Select how often wallpaper shuffles. Options are Off, 10 Minutes, 30 Minutes, 1 Hour, or 6 Wallpaper Shuffling Hours. Hall Technologies June 2, 2023 Page 20 of 34... -
Page 21: Date And Time
Enabled: Follows the 24-hour time format. 24-hour Format • Disabled: Follows the 12-hour time format. Time Zone Setting Sets the appropriate time zone. Date Format Changes the format of the date. Hall Technologies June 2, 2023 Page 21 of 34... -
Page 22: Language And Input Method
To access Language and Input Method settings, click on the applications sidebar settings button ( UI Element Description Select Language Select the desired language. Select Input Method Select the desired keyboard input method. Hall Technologies June 2, 2023 Page 22 of 34... -
Page 23: Power Settings
Disabled: the panel does not automatically wake up when a source is connected. • Enabled: the panel automatically wakes up with a LAN connection. Wake On LAN • Disabled: the panel does not automatically wake up with a LAN connection. Hall Technologies June 2, 2023 Page 23 of 34... -
Page 24: Security Settings
When enabled, locks out the ability to use the remote controller. Button Lock When enabled, locks out the physical IFP buttons except for the power button. USB Lock When enabled, turns off all USB ports. Hall Technologies June 2, 2023 Page 24 of 34... -
Page 25: Other
Float Bar and dragging to the desired location. When idling the Float Bar will minimize. When enabled, the screen will automatically refresh during the set time when there is no Smart Screen Protection activity. Hall Technologies June 2, 2023 Page 25 of 34... -
Page 26: About
To access the About menu, click on the applications sidebar settings button ( UI Element Description Update Opens a window to perform a local firmware update. Device Name Changes the device name. Hall Technologies June 2, 2023 Page 26 of 34... -
Page 27: Basic Operations - Utilities
Volume Increases/decreases the volume. Brightness Increases/decreases the brightness of the display, or sets it to auto detection. Common App Shortcuts Click the plus sign to add a shortcut to favorite apps. Hall Technologies June 2, 2023 Page 27 of 34... -
Page 28: Basic Operations - Android Home Page
The Android Home Page provides the date and time, flash drive information, network information, hot spot information and shortcuts for S-Write whiteboard and File Manager. Note: Users can install additional applications using the Google Play app. Hall Technologies June 2, 2023 Page 28 of 34... -
Page 29: S-Write
Lasso Move Quit Hold-all Side bar change left and right Previous Step Menu Next Step QR code scanning and sharing Previous Page Hide bottom sidebar Current Page Add Pages Next Page Hall Technologies June 2, 2023 Page 29 of 34... -
Page 30: File Manager
Clicking on the “File” icon ( ) opens File Manager. Long pressing the files and folders allows for moving, copying, or deleting the selection. The File Manager also supports the playing of images, videos, audio, etc. Hall Technologies June 2, 2023 Page 30 of 34... -
Page 31: Technical Parameters
Technical Parameters Mode Display HDMI Mode Resolution Refresh Rate 720x480 70Hz 720x576 50Hz 1280x720 50Hz 1280x720 60Hz 1920x1080 50Hz 1920x1080 60Hz 3840x2160 30Hz 3840x2130 60Hz Hall Technologies June 2, 2023 Page 31 of 34... -
Page 32: Troubleshooting
USB cable of the touch USB cable 2. Change to a shorter or better quality touch USB cable 2. The touch USB cable is too long or of low quality Hall Technologies June 2, 2023 Page 32 of 34... -
Page 33: Specifications
