- Page 1 Kanga TS pediatric frame Item # KG P800 KG 1000 KG 1200 KG 1400 EU Authorized Representative Drive Medical LTD Ainley’s Industrial Estate Elland, West Yorkshire, United Kingdom HX5 9JP www.drivemedical.com www.drivemedical.com...
- Page 2 5. Loosen the rigidizer bar (C) by turning yellow knob assembly (D). Depress push pin (E) and adjust width accordingly. 1. Open frame by pulling right and left side apart and pushing down on the cross brace until fully extended. 2.
- Page 3 folding adjustments 1. Raise armrests. Seat Depth 2. Turn yellow rigidizer bar knob (D) to loosen bar. Seat depth can be adjusted by removing rear wheels and 3. Lift levers (F) and fold canes? Allen screw (G) pushing/pulling seat rail to desired posi¬- 4.
- Page 4 Armrests Anti Tippers Height can be adjusted by removing Allen screws (K) and Height can be adjusted by pulling on chrome disc (N) to raising or lowering black bracket. Return Allen screws release anti tipper. Raise or lower to one of the five pre- and tighten.
- Page 5 Pelvic straps: Headrest: The pelvic straps have Velcro on the bottom side. Mount Mount headrest onto back by inserting screws through straps around frame as per diagram. . plate and into back. Use 4mm allen wrench. Laterals: Footrests: Mount laterals onto back by inserting screws through the Mount footrests hangars onto pins.
- Page 6 Heel & Toe Loops Abductor/Hip Guides. The heel and toe loops get installed by inserting screw Insert the hip guides directly into brackets that are through the front and back of the footplate and tighten- attached to the seat. ing the nut. Use 4mm allen wrench. Seat &...
- Page 7 Place four aluminum black seats and back brackets general care (circled below) over frame and fasten with knobs provided. Wipe aluminum parts with a clean, soft cloth at least once a week. All metal parts can be cleaned with auto wax or similar products.
- Page 8 This can cause wheelchair to tip over. When trying to extend arms over back, only reach as far as your arm If you have a question about your Drive device or can extend without having to alter your seating position.
