USB Connection
INFORMATION REGARDING USB DIRECT:
1. Compatibility of the USB connection on this
micro system:
a) This micro system supports most USB Mass
storage devices (MSD) that these devices are
compliant to the USB MSD standards.
i) Most common Mass storage class
devices are flash drives, memory sticks, jump
drives and etc.
ii) If you see a "Disc Drive" showing up on
your computer after you have plugged the mass
storage device into your computer, most likely it
is MSD compliant and it will work with this
micro system.
b) If your Mass storage device requires a
battery/power source, please make sure you
have a fresh battery in it or charge the USB
device first and then plug it into the micro
system again.
2. Supported Music type:
a) This device only supports unprotected music
with file extension: .mp3 .wma
b) Music bought from on-line music stores are
not supported because they are secured by
Digital Rights Management protection (DRM).
c) File name extensions that ended with the
following are not supported: .wav; .m4a; .m4p;
.mp4; .aac and etc.
3. No Direct connection can be made from a
Computer USB port to the micro system even
you have either or both mp3 or wma file in your
computer.

Listening to an external source

You can listen to the sound of the connected
external device through your system's speakers.
Using AUX IN (3.5 mm jack )
1
Use a cinch cable (not supplied) to connect
AUX IN jack of the main unit (3.5 mm, located
on the back panel) to an AUDIO OUT or
headphone jack on an external equipment (such
as CD player, or VCR).
2
Press SOURCE (or AUX on the remote
control) repeatedly until "AUX 1" is displayed.
Using AUX IN 2 (white/red jacks)
1
Use the audio cables (white/red, not supplied) to
connect AUX IN 2 (L/R) jacks of the main unit
(located on the back panel ) to the
corresponding AUDIO OUT jacks on an
external device (such as TV or VCR).
2
Press SOURCE (or AUX on the remote
control) repeatedly until "AUX 2" is displayed.

AUX
