RV2458 Router
Quickstart Guide
For Technical Assistance, please call (310) 735-2000,
or visit www.magnadyne.com
Patent No.: US D855,591 S
Patent No.: US 10,622,709 B2

Advertisement

loading
Need help?

Need help?

Do you have a question about the RV2458 and is the answer not in the manual?

Questions and answers

Related Manuals for Magnadyne RV2458

Summary of Contents for Magnadyne RV2458

  • Page 1 RV2458 Router Quickstart Guide For Technical Assistance, please call (310) 735-2000, or visit www.magnadyne.com Patent No.: US D855,591 S Patent No.: US 10,622,709 B2...
  • Page 2 RV2458 Can be used with either: RV2400 Extender Wi-Fi Only RV2402 Extender Wi-Fi / LTE...
  • Page 3 How to Activate your Data Plan If you have purchased the WF-CON-LTE system or upgraded from the Wi-Fi only RV2400 to the Wi-Fi / LTE enabled RV2402 you will need to activate a data plan to take advantage of the LTE benefits. To get started with your LTE Activation, the system needs to be installed and operational by completing Steps 1-6 in the following pages of this manual.
  • Page 4 RV2458 Software Quickstart Guide Step 1 Step 2 Press power button on the Go to the WiFi setting on your device RV2458 to power up the Router (phone, tablet, laptop, etc., make (approximately 2 min). sure your WiFi is turned on) and click on the RV2458-2.4G...
  • Page 5 Step 3 Step 4 In the Password field type in Wait until your device is the password RV2458WiFi connected to the RV2458-2.4G and click the Join button. Network. Password: RV2458WiFi *Case Sensitive...
  • Page 6 RV2458 Software Quickstart Guide Step 5 Step 6 Go to your web browser and in The Login screen will open. In the address field type in the Password field type in the 192.168.10.1 and click Go or password admin and click hit Enter.
  • Page 7 Step 7 Step 8 If WiFi is selected proceed to Wait until the scanning Step 8. If LTE is selected proceed countdown has completed to Step 15.
  • Page 8 RV2458 Software Quickstart Guide Step 9 Step 10 The Available WiFi List The password pop-up window will appear. screen will appear. Click on Type in the password for the chosen WiFi the WiFi Network that you host and click on the Connect button.
  • Page 9 Step 11 Step 12 The Connecting countdown In the Password field type in page will complete and then the the password admin and click Login screen will open. the Login button. If login is successful, the unit will 2 minutes You must wait proceed to Step 13.
  • Page 10 RV2458 Software Quickstart Guide Step 13 Step 14 If the password was not typed At this point you have successfully correctly a pop-up window will connected to the WiFi Host. appear stating that the connection If scan for WiFi is selected to the Network failed.
  • Page 11 Step 15 Step 16 If you are using the recommended During this time, the LTE module AT&T Preferred Plan, then click the is starting and establishing the Start LTE button to begin the LTE connection with LTE carrier connection. If using a different carrier, be sure to enter the correct APN, User Name and Password as required by the carrier.
  • Page 12 RV2458 Software Quickstart Guide Step 17 Step 18 At this time LTE has been In the Password field type in successfully started. the password admin and click the Login button. If login is successful, the unit will proceed to Step 13.
  • Page 13 Step 19 Step 20 At this point you have a success- During this time, LTE is being ful connection to the LTE carrier. turned OFF. If you want to turn OFF LTE, click the LTE Off button and proceed to Step 20.
  • Page 14 RV2458 Software Quickstart Guide Step 21 Once Step 20 is complete, you will receive this notice and returned to Step 7.
  • Page 15 Notes:...

  • Page 16: One (1) Year Limited Warranty

    ONE (1) YEAR LIMITED WARRANTY Magnadyne Corporation or its authorized agents will within one year from the date of sale to you, repair, replace or refund the retail sales price of said product or any part thereof, at the option of the Magnadyne Corporation or its authorized agents, if said product or part is found defective in materials or workmanship, when properly connected and operating on the correct power requirements designated for the specific product.
