- Page 1 S5080 Duo 4-core HD LTE Quick Guide...
-
Page 2: Table Of Contents
Activation and screen unlock....13 Android system........14 Basic control........14 Making calls........20 Messages...........24 Choice of SIM for data connection..26 Photography........26 PC connection......…..…..28 Smart casing........30 Safety and ecology......32 Declaration of conformity....34 Before you start Thank you for buying of our ALIGATOR mobile phone. -
Page 3: Dual Sim Function
Before you start please read carefully this instruction manual. DUAL SIM function Your mobile phone can be operated with 1 or 2 SIM cards. If you insert only one SIM card the mobile phone works as an ordinary mobile phone. In case you insert 2 SIM cards at the mobile phone both are active at the same time. -
Page 4: Important Instructions
between them. Both cards are on line. Important instructions Do not use the mobile phone in the prohibited areas Do not use the mobile phone while driving the Do not use the mobile phone near the medical appliances without having the confirmation that the radio waves do not... - Page 5 Mobile phone can influence the function of the cardiac pacemakers or other implanted appliances – please consult your medical doctor Switch off the mobile phone in the aircraft Do not use mobile phone near the petrol stations. Always switch off the mobile phone near explosives.
- Page 6 damage of the mobile phone or explostion. Do not throw the battery in the fire nor expose it to the temperatures over +60°C. Danger of explosion or fire. SAR – mobile phone meets all prescriptions for maximal emision of electromagnetic radiation.
- Page 7 radiation absorbed by your body. Handle the mobile phone with care, protect it from falling on the ground, from mechanical damage, impurity or high temperatures. Never pick it to pieces ! Do not place the mobile phone or its holder in the area above the airbag in the car ...
- Page 8 Software and hardware of the mobile phone are continuously innovated. The importer reserves the right to alter the instruction manual or particular functions of the mobile phone without a prior notice. If your phone is equipped with E-compass (not standard), its function can be affected by the surroundings and by the...
-
Page 9: Insert Battery And Sim Card
substitution of ordinary compass. Inaccuracy E- compass is not grounds for complaint. Insert battery and SIM cards Slip your nail at the slot at the back side of the mobile phone and carefully pull down the cover. Insert firstly one or two SIM cards at the prepared slots. - Page 10 mobile phone. Put the battery cover back. Place the cover on the back side of the mobile phone and press gently around the circuit untill the cover clicks properly on its place.
-
Page 11: Mobile Controls
Mobile controls 1. Button : Offer 2. Button : Main screen 3. Button : Backwards... -
Page 12: Switch On / Off
4. Volume 5. Button : Switch On / Off 6. Earphones 7. Headphone connector 8. Front camera 9. Micro USB connectorSwitch On / Off Switch On / Off To Switch On - press the button (5). The start of the mobile phone can take few seconds. -
Page 13: Activation And Screen Unlock
To Switch Off – press and hold the button (5) till the indicator window of a switch off appears on display. Confirm it and the mobile phone will turn off. Activation and screen unlock The screen will turn off automatically after a certain time of inactivity. -
Page 14: Android System
Android system Your mobile phone is provided with the ANDROID operating system. The device is in reality a small personal computer that can be connected with internet from which you can download many useful applications (Goggle Play) Basic control Meaning of the touch buttons (1) to (3) (1) Menu –... - Page 15 (2) Main screen – a short press serves to return to a main screen. A long press displays the list of launched applications. (3) Backwards – serves to return by one level back (jump on the preceding screen, closing of offers or dialog windows on the screen.) System control...
- Page 16 By clicking on them you can choose the items , confirm dialogue windows and graphical buttons on the screen. Google account It is necessary to create the Google account which can be set up in following simple steps: 1.Press the button Menu (1) and choose „Set up“...
- Page 17 3. Further follow instructions on the screen Main screen Your main screen is devided into more pages that can be displayed by moving of your finger to the left/right. On the main screen you can place the short cuts of icons of applications and links or widgets.
- Page 18 Applications All installed applications can be displayed by the button placed in the middle of the lower part of the main screen. In standard equipment of the mobile phone you can find applications for making calls, sending messages and e-mails or many other useful applications.
- Page 19 Before buying of any new application please try first its free of charge version if it works correctly in your mobile phone. Information and display of status So called status bar is placed in the upper part of the screen. You may find here the information about time, battery level and signal but...
-
Page 20: Making Calls
will get a detailed overview about all announcements and information including the possibility of a quick control of some mobile functions. Mobile phone set up All items of the telephone set up are clearly arranged at the settings menu. Press the button Menu (1) and select Set up . - Page 21 You can enter the tel.number with the use of the keyboard buttons. Similarly as on the common telephone there are the letters displayed on the buttons so you can enter also the name. The dialled number and all corrresponding items of the tel.directory will be displayed after entering of the letters on keys of the screen.
- Page 22 this button, dial selected number and make a call. Choice of SIM card for calls Click on the head-phone icon on the main screen. Now you can display the offer (which SIM card will be used for calling) for your choice by dragging down of the status bar.
- Page 23 the receiver is displayed on the screen. To answer the call : move the button to the right towards the symbol of a green receiver . Call flow and finish of the call The screen will automatically switch off when the mobile phone is attached to the ear.
-
Page 24: Messages
Messages 1. Click on the icon of Messages on the lower side of the main screen or open the screen with applications and select the item SMS a MMS. 2. A list of conversations containing received and sent SMS and MMS messages will be displayed. - Page 25 4. Now you can insert the receiver of the text message. 5. To send the text message press the arrow button placed on the right side of the text. Same as by calling you can choose by dragging down of the status bar which SIM card can be used for sending of messages.
-
Page 26: Choice Of Sim For Data Connection
Choice of SIM for data connection You can choose which SIM card will be used for a internet speed data connection : Press the icon Setup on the main screen Select SIM cards Continue to select Mobile data ... - Page 27 Aim the camera at the scene and tap your finger on the screen to the point that you want to focus on or wait a moment, the camera automatically focuses on the center. After focusing the scene, you can take a picture by pressing the shutter button on the side of the display.
-
Page 28: Pc Connection
the desired location on the screen. Beware! Always wait for focus and then press the shutter button, otherwise the images will be blurred. Press the button to switch the front and rear camera. Press the button to shoot the video. PC connection You do not need any special driver (valid for OS Windows... - Page 29 Now the internal storage at the mobile phone and inserted MicroSD card will be connected with the PC at the file Computer, in section Portable Devices , under the name ALIGATOR S5080. The connection can be interrupted by disconnection of the cable.
-
Page 30: Smart Casing
Smart casing Smart casing with a window can be bought as an accessories to the mobile phone. The phone is able to detect when the housing is open and when closed. After closing of the casing, the phone automatically locks the screen and after you press the power button (5) the time, date information and missed calls display at the window of the... - Page 31 button to answer or reject the call are displayed in the window. After opening the case, the phone automatically unlocks. This feature can be enable or disabled at the phone settings section Displaj – Unlock by opening of the housing. Troubleshooting Under certain circumstances (eg.
-
Page 32: Safety And Ecology
When using the smart casing the sensor function of the e-compass (if included with the phone) will not work correctly. This is due to the presence of a magnet which is used in a smart housing to detect open / close. Safety and ecology Used electric device Mobile phone is an... - Page 33 Battery liquidation Used/old batteries and accumulators do not belong to the common residential waste !!! They may contain the substances dangerous to the environment. Hand over the battery to the respective collection point which provides the ecological liquidation. Please contact your dealer to get more information how to deal with the used products.
-
Page 34: Declaration Of Conformity
Issued in accordance with the prescription EU R&TTE, 1999/5/EC Product: Mobile phone for GSM network Model : Aligator S5080 Duo Importer: ADART COMPUTERS s.r.o., Sokolovská 161, 180 00 Praha 8, Reg.No. 25074547 Evaluated product is a mobile phone intended for mobile nets of GSM standard and is planned to be used and stored in standard conditions.
