Charcoal Spit Roaster Large
• Steel firebox construction
• High temperature powdercoated
• 3 Chrome plated grills
• Stainless steel skewer, prongs
and braces
FOR OUTDOOR USE ONLY
DO NOT OPERATE THIS APPLIANCE BEFORE READING THE INSTRUCTION BOOKLET
DO NOT PLACE ARTICLES ON OR AGAINST THIS APPLIANCE
DO NOT STORE CHEMICALS OR FLAMMABLE MATERIALS OR SPRAY AEROSOLS NEAR THIS APPLIANCE
DO NOT OPERATE THE APPLIANCE INDOORS
DO NOT OPERATE IN AN ENCLOSED AREA. ACCESSIBLE PARTS MAY BE VERY HOT. KEEP YOUNG CHILDREN AWAY.
MINIMUM CLEARANCES FROM COMBUSTIBLE MATERIALS: 3 METRES
Gasmate
is a registered trademark of:
®
Important: Retain these instructions for future use.
03027 04/13
Model No. GSB002
• 240V x 50Hz Motor
• 2 Rubber tread wheels and 2
• Cooking surface
• Overall dimensions
Sitro Group Australia Pty Ltd
Aber, Hamilton, N.Z
feet
850mm x 400mm
1110mm x 440mm x 860mm
www.sitro.com.au
www.gasmate.co.nz
Advertisement
Table of Contents
Related Manuals for Sitro Group Gasmate GSB002
Summary of Contents for Sitro Group Gasmate GSB002
- Page 1 DO NOT OPERATE IN AN ENCLOSED AREA. ACCESSIBLE PARTS MAY BE VERY HOT. KEEP YOUNG CHILDREN AWAY. MINIMUM CLEARANCES FROM COMBUSTIBLE MATERIALS: 3 METRES Gasmate is a registered trademark of: Sitro Group Australia Pty Ltd www.sitro.com.au ® Aber, Hamilton, N.Z www.gasmate.co.nz...
-
Page 2: Important Safety Warnings
IMPORTANT SAFETY WARNINGS READ ALL SAFETY WARNINGS AND INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING AND OPERATING YOUR BARBECUE. • Never use charcoal that has been pre treated with lighter fluid. Use only a WARNING high grade plain charcoal or charcoal/ wood mixture. •... - Page 3 IMPORTANT SAFEGUARDS • Never leave coals and ashes in barbecue ROTISSERIE MOTOR unattended. Before barbecue can be left unattended, remaining coals and When using electrical appliances, basic ashes must be removed from barbecue. safety precautions should always be Use caution to protect yourself and followed, including the following: property.
-
Page 4: Exploded Diagram
EXPLODED DIAGRAM PARTS LIST PART NO. DESCRIPTION PART NO. DESCRIPTION Wing Nut Axle Leg Brace Bracket Brace Prong Skewer Hook Bracket Motor Skewer Split Pin Counter Weight Fixing Pin Cooking Grate Support Assembly A Charcoal Grate Wheel Side Leg Assembly Leg Assembly Hexagon Screw Leg End Cap... -
Page 5: Tools Needed
ASSEMBLY INSTRUCTIONS Tools Needed 2 Adjustable spanners. Step 1 Attach the legs using six M8x35mm bolts and nuts. Attach the wheels using two axles and nuts. M8x35 6 PC 6 PC 2 PC... - Page 6 Step 2 Slide the support assemblies onto the posts and secure with the fixing pin and split pin.
- Page 7 Step 3 Place the charcoal grate into the bottom of the body. The cooking grates fit into the top of the body if required.
- Page 8 Step 4...
-
Page 9: Completed Assembly
Completed Assembly... -
Page 10: Cleaning And Care
OPERATING INSTRUCTIONS COOkING This appliance is designed for use only with Cooking directly over hot coals, ideal for quality charcoal briquettes, lump charcoal or searing in juices and grilling food requiring wood. less than 25 minutes of grilling time, such as steaks,ham burgers, hotdogs, chickenparts, First Use vegetables and fruit. -
Page 11: Rotisserie Cooking
ROTISSERIE COOkING Rolled Meat A rolled piece of meat only requires the Rotisserie cooking produces foods that are rotisserie skewer to be inserted through the moist, flavourful and attractive, as the turning centre of the length of meat then secured and food self bastes.
