- Page 1 AVIONICS PANEL G1000 P/N: VS-AP1-G1000 ASSEMBLY INSTRUCTIONS Rev. 1.0 © Volair Sim. All Rights Reserved.
- Page 2 Thank you for purchasing the Avionics Panel G1000 for the Volair Sim chassis! We hope that it will further increase the sense of realism and immersion during flight simulation. Although we have designed the Avionics Panel with ease of assembly in-mind, please read these instructions carefully first.
- Page 3 Volair Sim Avionics Panel G1000 ships with the following adapter plates: 1. Blanking Plate for Logitech Pro Flight Accessory (Left of Yoke) 2. Adapter Plate for attaching Additional Logitech Flight Instrument Panels 3. Blanking Plate for Honeycomb Bravo Throttle (Right of Yoke) 4.
- Page 4 ASSEMBLY INSTRUCTIONS STEP 1: Unpack the Volair Sim G1000 Avionics Panel and lay it front-down on a soft surface in order to protect the panel and the RealSimGear (RSG) components. Next, test-fit the RealSimGear PFD and MFD displays to ensure that the four (4) mounting holes in the Avionics Panel align with the respective holes in the PFD and MFD.
- Page 5 STEP 2: Detach all avionics/accessories from the Volair Sim avionics table except for the yoke (if installed). If you do not have the yoke installed, test-fit it now. Volair Sim Avionics Panel G1000 is compatible with the following flight yokes: Logitech (Saitek), Honeycomb Alpha, Yoko, and Brunner.
- Page 6 STEP 2B: Next, place the smaller extender bracket on top of the longer extender bracket and verify that the two open holes line-up properly and that the front lip of the avionics table is uniform with the bracket as shown: PAGE...
- Page 7 STEP 3: Use the rightmost two holes on the extender bracket to line up with the two rightmost holes in the G1000 Avionics Panel as shown below and use the remaining M4x12mm screws, washers, and nuts to secure the avionics panel to the avionics table uniformly along the front lip. Use the universal wrench to prevent the nuts from turning while tightening.
- Page 8 See Appendix A and B for tips on attaching Honeycomb Alpha yoke and Bravo throttle. Use the provided rectangular blanking plates to cover-up unused openings. See Appendix C for instructions on installing Seat Riser Kit to raise Volair Sim Chassis seat height. PAGE...
-
Page 9: Appendix A - Honeycomb Alpha Flight Yoke Installation
APPENDIX A – HONEYCOMB ALPHA FLIGHT YOKE INSTALLATION There are two options for installing the Honeycomb Alpha Flight Yoke: OPTION – 1 (PREFERRED) Remove the decorative trim from the yoke as shown in STEP 1 below. Next, Attach the Alpha yoke to the Avionics Table using strips of dual-sided 3M tape (e.g. - Page 10 STEP 2 – Install the Honeycomb micro suction mounting plate on the Volair Sim avionics table. The front of the plate must be positioned behind the two holes drilled on the front of the avionics table as circled in red.
-
Page 11: Appendix B - Honeycomb Bravo Throttle Quadrant Installation
NOTE: IT MAY BE HELPFUL TO TEMPORARILY REMOVE THE MFD OR LOOSEN THE MOUNTING SCREWS OF THE AVIONICS PANEL DURING THE INSTALLATION. ALSO, YOU MAY WANT TO RELOCATE THE KEYBOARD TRAY FROM RIGHT TO LEFT USING THE OPTIONAL LEFT-HAND KEYBOARD MOUNT (AVAILABLE FOR PURCHASE FROM VOLAIR SIM). PAGE... -
Page 12: Appendix C - Installing Seat Riser Kit (P/N: Vs-Srk)
APPENDIX C – INSTALLING SEAT RISER KIT (P/N: VS-SRK) STEP 1: Remove the left, center, and right-hand mounts from the chassis. Next, remove the seat with seat sliders from the seat cross-bars. Lastly, remove the cross-bars from the seat risers. STEP 2: Install the seat riser kit as shown below by running the long...
