- Page 1 Triple Display Stand (V2) Assembly Instructions P/N: VS-MS-V2 Revision 1.1 2022-07-21 © VOLAIR SIM . ALL RIGHTS RESERVED.
- Page 2 VESA 400 x 400 VOLAIR SIM TRIPLE DISPLAY STAND SPECIFICATIONS Your Volair Sim triple display stand is shipped in one box (67lbs) 34”x21”x8”. We recommend that you find an open space to carefully unpack and inventory everything before beginning the assembly process. Please refer to TABLE 1 and TABLE 2 to verify that you have all of your mounting hardware.
- Page 3 No. DESCRIPTION PHOTO Thumb Machine Screw M8x20mm Thumb Machine Screw M6x40mm M8x20 Hex bolt M8x35mm hex bolt M8x55mm hex bolt M8x60mm hex bolt M8 nylon nut TABLE 1: HARDWARE LIST © VOLAIR SIM. ALL RIGHTS RESERVED. Page 3 of 15...
- Page 4 TABLE 2: DISPLAY MOUNTING HARDWARE KIT - 3 IDENTICAL BAGS (CONTENTS OF ONE BAG SHOWN ABOVE) © VOLAIR SIM. ALL RIGHTS RESERVED. Page 4 of 15...
- Page 5 (4) M8x20mm Hex Bolts and four (4) M8 nylon locknuts: NOTE: The connecting tabs should be on the OUTSIDE of the “ears” as shown above. Do not tighten all the way at this time. © VOLAIR SIM. ALL RIGHTS RESERVED. Page 5 of 15...
- Page 6 Attach two (2) center support posts to both horizontal support sections using four (4) M8x60 bolts and four (4) M8 nylon locknuts. HINT: ensure that the orientation of the circled parts and fasteners is as shown below: © VOLAIR SIM. ALL RIGHTS RESERVED. Page 6 of 15...
- Page 7 (32” – 50” in diagonal). HINT: You can use little silicone grease or spray on the sliding parts. © VOLAIR SIM. ALL RIGHTS RESERVED. Page 7 of 15...
- Page 8 STEP 4 Attach the “T” post to the square tubing using M8x35mm bolt and M8 nylon locknut. Repeat for the 2 “T” post. © VOLAIR SIM. ALL RIGHTS RESERVED. Page 8 of 15...
- Page 9 (2) M8x20mm thumb screws. Repeat for the other post. HINT: The “L” support should face outward as shown above to provide adequate space for Volair Sim’s cockpit pedal base. © VOLAIR SIM. ALL RIGHTS RESERVED. Page 9 of 15...
- Page 10 STEP 6 Attach the horizontal support assembly completed in STEP 3 to the posts completed in STEP 4 and secure with two M8x20mm thumb screws and adjust the approximate desired height. © VOLAIR SIM. ALL RIGHTS RESERVED. Page 10 of 15...
- Page 11 Attach the Left display arm to the horizontal support sections completed in prior step using two (2) M8x20 hex bolts and two (2) M8 nylon locknuts. Repeat for the Right display arm. Do not overtighten. © VOLAIR SIM. ALL RIGHTS RESERVED. Page 11 of 15...
- Page 12 M8 thumb screws. The post extensions will support the weight if the left and right displays and help with horizontal alignment with respect to the center display. © VOLAIR SIM. ALL RIGHTS RESERVED. Page 12 of 15...
- Page 13 Slide Left and Right horizontal display support sections completed in prior step on the assembly completed in STEP 7. Adjust the height of the left and right support post so that the left and arms are horizontal. © VOLAIR SIM. ALL RIGHTS RESERVED. Page 13 of 15...
- Page 14 Next, thread the four (4) Thumb Machine Screw M6x40mm into the two VESA brackets a few turns. HINT: Do not tighten the mounting screws all the way at this time as to allow each display to slide up/down in the oval slots. © VOLAIR SIM. ALL RIGHTS RESERVED. Page 14 of 15...
- Page 15 When satisfied, tighten all fasteners to prevent further movement. After completing all electrical connections, one can use zip ties to secure and conceal display wiring. ENJOY YOUR TRIPLE DISPLAY STAND! © VOLAIR SIM. ALL RIGHTS RESERVED. Page 15 of 15...
