2010 LCD front bezel

For access, remove these FRUs in order:
• "1010 Battery pack" on page 42
• "1160 Speakers, LCD unit and base cover" on page 62
Removal steps of the LCD front bezel
Remove the screws 1 .
Step Screw (quantity)
1
M2 × 4 mm, flat-head, nylon-coated (2)
Remove the LCD front bezel.
When installing: Ensure that all the latches are attached firmly. Then secure the bezel with the screws.

2020 Camera and microphone board

For access, remove these FRUs in order:
1
1
Color Torque
Black 0.181 Nm
(1.85 kgf-cm)
.
