- Page 1 4-748-307-12(1) Television Reference Guide Customer Support and Contact: http://www.sony-asia.com/support KD-85X8500G / 75X8500G / 65X8577G / 65X8500G / 55X8577G / 55X8500G...
-
Page 2: Table Of Contents
Introduction To attach the Table-Top Thank you for choosing this Sony product. Stand, refer to the Setup Before operating the TV, please read this manual thoroughly and retain it for future reference. Guide. Note • Before operating the TV, please read the “Safety Information”... - Page 3 • Be sure to use the screws supplied with the Wall-Mount Bracket when attaching the Wall-Mount Bracket to the TV set. The supplied screws are designed as indicated by illustration when measured from the attaching surface of the Wall-Mount Bracket. The diameter and length of the screws differ depending on the Wall-Mount Bracket model.
- Page 4 Topple prevention KD-75/65/55X8500G, KD-65/55X8577G (Models with supplied support belt kit) Refer to the Setup Guide on top of the cushion. The supplied wood screw is only for affixing to a solid object made of wood. (Except models with supplied support belt kit) KD-85X8500G 10 mm –...
-
Page 5: Parts And Controls
Parts and Controls Controls and Indicators (Power) /+/– When the TV is off, Press to power on. When the TV is on, Press and hold to power off. Press repeatedly to change the function, then press + or – button to: •... -
Page 6: Using Remote Control
Using Remote Control Remote Control Parts Description The remote control shape, location, availability and function of remote control buttons may vary depending on your region/country/TV model. (Microphone) Use voice search*. (e.g., Search various content by voice.) //// (Navigation D-Pad) On screen menu navigation and selection. - Page 7 APPS EXIT Display a list of installed apps. Return to the previous screen or exit from the menu. When an Interactive Application (Input select) service is available, press to exit from the Display and select the input source, etc. service. (Quick settings) (Info/Text reveal) Display Quick Settings.
-
Page 8: Connection Diagram
Connection Diagram For more information on connections, refer to the Help Guide by pressing HELP on the remote control. Digital still camera/ Camcorder/USB storage media Headphone HDMI Device HDMI Device Audio System with eARC/ ARC/HDMI Device Router VCR/Video game equipment/ DVD player/Camcorder <... - Page 9 USB 1/2, USB 3 • Connecting a large USB device may interfere with other connected devices beside it. • When connecting a large USB device, connect to the USB 1 port. (Headphone) • Supports 3-pole stereo mini jack only. •...
-
Page 10: Installing The Tv To The Wall
Sufficient expertise is required for installing this product, especially to determine the strength of the wall for withstanding the TV’s weight. Be sure to entrust the attachment of this product to the wall to Sony dealers or licensed contractors and pay adequate attention to safety during the installation. Sony is not liable for any damage or injury caused by mishandling or improper installation. -
Page 11: Detaching The Table-Top Stand From The
Detaching the Table-Top Stand from the TV Remove one side of the Table-Top Stand at a time. Firmly hold the Table-Top Stand securely with both hands while the other people lift up the TV. KD-85X8500G KD-75/65/55X8500G, KD-65/55X8577G Repeat the previous step and remove the other side of the Table-Top Stand. Note •... -
Page 12: Troubleshooting
(mains lead) until the illumination LED stopped flashing in red, then turn on the TV. If the problem persists, disconnect the AC power cord (mains lead), and contact your dealer or Sony service centre with the number of times the illumination LED flashes. -
Page 13: Specifications
eARC/ARC (Enhanced Audio Return Channel/ Audio Return Channel) (HDMI IN 3 only) Specifications In eARC mode* Refer to the Help Guide for details. System In ARC mode Two channel linear PCM: 48 kHz 16 bits, Dolby Panel system Digital, Dolby Digital Plus, DTS LCD (Liquid Crystal Display) Panel, LED Backlight DIGITAL AUDIO OUT (OPTICAL) TV system... - Page 14 Dolby Laboratories. Confidential KD-75X8500G: 37.8 kg unpublished works. Copyright © 1992-2015 KD-65X8577G / KD-65X8500G: 25.3 kg Dolby Laboratories. All rights reserved. KD-55X8577G / KD-55X8500G: 18.7 kg • “BRAVIA”, and BRAVIA Sync are trademarks or registered marks of Sony Corporation.
- Page 15 • The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by Sony Corporation is under license. Other trademarks and trade names are those of their respective owners. • Netflix is a registered trademark of Netflix, Inc.
- Page 16 Help Guide http://rd1.sony.net/help/tv/gga2/h_ga/ http://www.sony.net/ © 2019 Sony Visual Products Inc.
