QUICK START GUIDE:
SolarFlex 400i Package

TO CONNECT- Victron Product:

Enable Bluetooth on your phone.
1)
Open VictronConnect and your Controller will appear, tap on the controller.
2)
The first time you connect, the app will ask to pair with a Victron product. Enter your PIN code or enter
3)
the default PIN code: 000000.
If prompted to update, install the update. This is normal and updates to the app or firmware should
4)
always be done.
Once complete, you will reach the home screen for your Victron device.
5)
Solar Controller SETTINGS- VictronConnect:
Once paired to your Maximum Power Point Tracking (MPPT) Smart Solar Controller, you will be taken
1)
to the home screen. The settings page is accessed by clicking on the ( ) icon in the top right. This page
provides access to view
The MPPT Smart Solar Controllers are configured with
2)
preset battery charge algorithms and can easily be
modified via VictronConnect App. NOTE: (Gel Victron
Deep Discharge 1) battery type is the default setting
and preferred for Lead Acid Batteries. Please refer to
the Smart Controller Manual to confirm or change the setting.
Battery MONITORING- SmartShunt Settings:
Once paired with the SmartShunt, you will be brought to a home screen. The
1)
settings are accessed by clicking on the ( ) icon at the top right of the home page.
The settings page provides access to view or change the settings of the Battery Monitor.
This process is very important for accurate app readings and good battery life. Make sure when
2)
installing batteries, the following items are correct and comply with the battery manufacturer's settings:
RECOMMENDED SETTINGS Lead Acid
Battery Capacity
Charged Voltage (V)
Discharge Floor
Tail Current
Peukert Exponent
Charge Efficiency
Battery Starts Synchronized

INVERTER/BATTERY DISCONNECT INFORMATION:

Coach disconnect (if equipped) can be turned off any time
you wish to shut off all 12v power inside of coach. Inverter
disconnect should only be turned off when placing the
coach into dry storage or servicing
the inverted circuit outlets.
KEYSTONE RV
KEYSTONERV.COM
or change the charger settings and other features.
AGM
Lithium
Total Ah
Total Ah
Total Ah
13.4
13.1
14.1
50%
50%
0%
4%
2%
3.5%
1.25
1.1
1.05
94%
97%
99%
Uncheck
Uncheck
Uncheck
Inverter
Disconnect
REV 1.2

TO START: Download the VictronConnect App.

Add up
total Amp hours (Ah)
installed and insert value into Battery Capacity
Total Ah
column.
To convert
RC (Reserve Capacity)
the
RC
by 2.4 Ah=RC/2.4
As Equipped:
Magnum
Xantrax
FUTURE SOLUTIONS FSI-SOLUTIONS.COM
User Manual
for battery(s)
to
Ah
divide
