Seiko Y182 - Watch Manual

FEATURES

TIME/CALENDAR

• Hour & minute hands with small second hand
• Date displayed in numerals

ALARM

• Can be set on a 12-hour basis with small alarm hands.

STOPWATCH

• Measures up to 30 minutes in 1/5 second increments.
• Can measure repeatedly up to 6 hours.

TACHYMETER

• For models with tachymeter scale

DISPLAY AND CROWNS/BUTTONS

There are three buttons and two crowns.

1. Normal position
2. First click
3. Second click

DATE SETTING

1. Pull out to first click .
2. Turn clockwise until the date for the previous day appears.
3. Pull out to second click and turn until the desired date appears.
4. Push back in to normal position .

NOTES

1. Do not set the date between 9:00 p.m. and 3:00 a.m. Otherwise, the date may not change properly.
   * If it is necessary to set the date during that time period, first change the time to any time outside this period, set the date and then reset the correct time.
2. It is necessary to adjust the date at the end of February and 30-day months.

TIME SETTING

1. Pull out to second click when Second hand is at the 12 o'clock position.
2. Turn to set Hour and Minute hands.
3. Push back in to normal position in accordance with a time signal.

NOTES

1. When setting Hour hand, check that AM/PM is correctly set.
   * The watch is so designed that the date changes once in 24 hours. Turn the hands past the 12 o'clock marker to determine whether the watch is set for the A.M. or P.M. period. If the date changes, the time is set for the A.M. period. If the date does not change, the time is set for the P.M. period.
2. When setting Minute hand, advance it 4 to 5 minutes ahead of the desired time and then turn it back to the exact minute.

ALARM

• Alarm time is set on a 12-hour basis.
• ALARM hands move independently of MAIN TIME hands.

ALARM SETTING

1. Adjustment of ALARM hands
   • After the main time is adjusted, follow the procedure below, and then set the alarm.
     * The following procedure is necessary only after the main time is adjusted.

1. Pull out to second click .
2. Turn clockwise or counterclockwise to set ALARM hands to the current time (MAIN TIME).
3. Push back in to normal position .

2. Alarm time setting
   * Once ALARM hands are adjusted to the main time, alarm time setting can be made only by following the procedure below.

Pull out to first click .

Press to set ALARM hands to the desired alarm time.

Push back in to normal position .

NOTES

1. When setting ALARM minute hand to the current time in , advance it 4 to 5 minutes ahead of the desired time and then turn it back to the exact minute.
2. Alarm hands move quickly if Button C is kept pressed.
3. If CROWN 2 is pulled out to first click within 1 minute after being pushed back in to normal position in , the alarm sounds.

ALARM ENGAGEMENT/DISENGAGEMENT

• Alarm engagement

  Pull out to first click .


NOTES

1. Alarm rings at the designated time for 20 seconds.
   * To stop it manually, press Button A, B or C, or push CROWN 2 back in to normal position.
2. If CROWN 2 is pulled out to second click, the designated alarm time is canceled with a warning beep.
   * In that case, set ALARM hands to MAIN TIME again, push CROWN 2 back in to normal position, and then, pull it out to first click and set the desired alarm time again. However, if CROWN 2 is pushed back in to normal position before the warning beep stops, the designated alarm time will not be canceled.

STOPWATCH

• Stopwatch measures up to 30 minutes in 1/5 second increments.
• After 30 minutes, it will start counting again from "0" repeatedly up to 6 hours.

STOPWATCH OPERATION

• Before using the stopwatch:
  • Check that CROWNS 1 and 2 are set at normal position.
  • Press Button B to reset STOP- WATCH hands to "0" position. * If the hands do not return to "0" position, follow the procedure in "ADJUSTING THE HAND POSI- TION".

1. Standard measurement



4. Measurement of two competitors


NOTES

1. If CROWN 1 is pulled out to second click, STOPWATCH hands are reset to "0" position.
2. If CROWN 2 is pulled out to first or second click, STOPWATCH hands are reset to "0" position.
3. When stopwatch has been reset and Button A is pressed before the hands reach "0" position, stopwatch still starts counting when Button A is pressed.

* Tachymeter scale can be used only when the time required is less than 60 seconds.

Ex. 2: If the measuring distance is extended to 2 km or miles or shortened to 0.5 km or miles and STOPWATCH second hand indicates "90" on tachymeter scale:
"90" (tachymeter scale figure) x 2 (km or mile) = 180 km/h or mph
"90" (tachymeter scale figure) x 0.5 (km or mile) = 45 km/h or mph

To measure the hourly rate of operation

1. Use the stopwatch to measure the time required to complete 1 job.
2. Tachymeter scale indicated by STOPWATCH second hand gives the average number of jobs accomplished per hour.

Ex. 2: If 15 jobs are completed in 20 seconds:
"180" (tachymeter scale figure) x 15 jobs = 2700 jobs/hour

ADJUSTING THE HAND POSITION

If STOPWATCH hands will not return to the 12 o'clock position when the stopwatch is reset or when the battery is replaced with a new one, follow the procedure below.

Pull out to second click .

Press repeatedly to reset STOPWATCH minute hand to the 12 o'clock position.

Press repeatedly to reset STOPWATCH second hand to the 12 o'clock position.

Push back in to normal position .

NOTES

1. Hands move quickly if the respective buttons are kept pressed.
2. After adjusting the hand position, set the main time.

RESETTING THE BUILT-IN IC

In case any of the hands should move improperly, follow the procedure below to adjust the hand movement.

Pull out to second click .

Press simultaneously.

Push back in to normal position .

NOTE
Before using the watch again, be sure to adjust the position of STOPWATCH hands and set the main time and alarm.

BATTERY LIFE INDICATOR

When the battery nears its end, the small second hand moves at two-second intervals instead of normal one-second intervals to indicate that the battery needs to be replaced with a new one.
* If the alarm is used while the second hand is moving at two-second intervals, the watch may stop operating. Therefore, if you see the second hand moving at two-second intervals, replace the battery with a new one as soon as possible.

BATTERY CHANGE

The miniature battery which powers your watch should last approximately 2 years. However, because the battery is inserted at the factory to check the function and performance of the watch, its actual life once in your possession may be less than the specified period. When the battery expires, be sure to replace it as soon as possible to prevent any malfunction.
For battery replacement, we recommend that you contact an AUTHORIZED SEIKO DEALER and request SEIKO SR927W battery.

• Do not remove the battery from the watch.
• If it is necessary to take out the battery, keep it out of the reach of children. If a child swallows it, consult a doctor immediately.

Never short-circuit, heat or otherwise tamper with the battery, and never expose it to fire. The battery may burst, become very hot or catch fire. The battery is not rechargeable. Never attempt to recharge it, as this may cause battery leakage or damage to the battery.

SPECIFICATIONS

1. Frequency of crystal oscillator 32,768 Hz (Hz = Hertz... Cycles per second)
2. Loss/gain (monthly rate) Less than 20 seconds at normal temperature range (5°C ~ 35°C) (41°F ~ 95°F)
3. Accuracy of alarm ±1 minute
4. Operational temperature range –5°C ~ +50°C (23°F ~ 122°F)
5. Driving system Step motor, 4 pieces
6. Display system
   Time Three hands (Hour, minute and small second hands)
   Date Displayed in numerals.
   Stopwatch Minute and 1/5 second hands
   The stopwatch can measure up to 30 minutes in 1/5 seconds.
   Alarm Small hour and minute hands The alarm is set on a 12-hour basis.
7. Battery SEIKO SR927W, 1 piece
8. IC (Integrated Circuit) C-MOS-LSI

* The specifications are subject to change without prior notice for product improvement.
