COMMERCIAL MICROWAVE OVEN
Original Instruction
OPERATION MANUAL -
This operation manual contains important information which you should read carefully
EN
before using your microwave oven.
IMPORTANT:
There may be a serious risk to health if this operation manual is not followed or if the oven is modified so that it
operates with the door open.
YB-S4202AE 2100W(IEC 60705)
Advertisement
Table of Contents
Related Manuals for Sharp YB-S4202AE
Summary of Contents for Sharp YB-S4202AE
- Page 1 This operation manual contains important information which you should read carefully before using your microwave oven. IMPORTANT: There may be a serious risk to health if this operation manual is not followed or if the oven is modified so that it operates with the door open. YB-S4202AE 2100W(IEC 60705)
- Page 2 Return is free of charge. If the equipment has been used for BUSINESS PURPOSES, please contact your SHARP dealer who will inform you about take-back. You might be charged for the costs arising from take-back. Small equipment (and small quantities) might be taken back by your local collection facility.
-
Page 3: Table Of Contents
TITLE CONTENTS PART NAMES ..........EN-3 MANUAL OPERATION ........EN-11 IMPORTANT SAFETY INSTRUCTIONS ..EN-4 OTHER CONVENIENT FUNCTIONS ... EN-14 INSTALLATION INSTRUCTIONS ....EN-6 CARE AND CLEANING ......... EN-16 ACCESSORIES ..........EN-7 SERVICE CALL CHECK ....... EN-17 SHORT DESCRIPTION OF FEATURES ..EN-7 GUIDE ............ -
Page 4: Part Names
PART NAMES OVEN 1 Control panel 2 Door lock openings 3 Ceramic floor 4 Splash cover 5 Oven lamp 6 Air intake filter 7 Air intake openings 8 Oven cavity 9 Door seals and sealing surfaces 10 Door hinges 11 Door 12 Safety door latches 13 Door open handle 14 Outer cabinet... -
Page 5: Important Safety Instructions
6. Do not store or use the oven outdoors. SHARP service agent in order to avoid a hazard. 7. Clean the splash cover and the oven cavity after 11. WARNING: Liquids and other foods must not use. - Page 6 SHARP service agent. packaging (e.g. self-heating materials) designed 3. Do not immerse the power supply cord or plug in to make food crisp, as they may be extra hot.
-
Page 7: Installation Instructions
4. Do not place anything on the outer cabinet during 2. Neither the manufacture nor the dealer can operation. accept any liability for damage to the oven or 5. Do not use the oven near a steamer or a fryer. personal injury resulting from failure to observe the correct electrical connection procedure. -
Page 8: Accessories
NOTE: • When you order accessories, please mention the two items: part name and model name to your dealer or SHARP authorized service agent. • The model name is printed on the door of the microwave oven. SHORT DESCRIPTION OF FEATURES... -
Page 9: Programme Operation
PROGRAMME OPERATION This oven has 20 memory banks (1-20) which can store cooking programmes. The memory banks 1-10 have been programmed previously as shown in the table. These preprogrammed memory banks can be changed individually if required. Please see page EN-9. In addition for all memory banks a magnification factor 1.8 for the double quantity is stored. - Page 10 MEMORY SETTING You can change memory programmes for 20 memory banks. Up to three sequences on any power level can be programmed for each memory. See cooking sequence chart on page EN-11 for time maximums. Setting time and power level Example : Suppose you want to set 4 minutes at 60 % for the 1st sequence and 2 minutes at 30 % for the 2nd sequence for 1 serving in the memory 1.
- Page 11 Setting magnification factor It is possible to change the magnification factor for double quantity in the memory. Example : Suppose you want to set the magnification factor to 1.67 for double quantity in memory 1. Step Action Press key Display Choose set mode.
-
Page 12: Manual Operation
Checking the magnification factor Example : Suppose you want to know the magnification factor for double quantity in memory 1, programmed 1.67. Step Action Press key Display Choose checking mode. CHECK NUMBER Choose double quantity. CHECK NUMBER DOUBLE Choose memory number. CHECK NUMBER DOUBLE... - Page 13 TIME COOKING Example : Suppose you want to cook for 2 minutes and 30 seconds at 50 %. Choose the manual cooking. Enter desired cooking time. Touch SELECT POWER key. POWER Choose desired power level. Start to cook. Check the display. NOTE: 1.
- Page 14 EXPRESS DEFROST Use the EXPRESS DEFROST key to defrost faster and better different types of food. Enter desired defrost time, referring to the EXPRESS DEFROST CHART on pages EN-13 and EN-14. Example : If you want to defrost for 1 minutes and 30 seconds. Step Action Press Key...
-
Page 15: Other Convenient Functions
OTHER CONVENIENT FUNCTIONS COUNTER CHECK The number of times when the oven will be used are automatically accumulated for each key. You can check how many times the oven was used. Example : Suppose you want to know total using time, times of using each memory and times of manual cooking. - Page 16 INFORMATION WITH ERROR MESSAGES If ERROR messages are displayed, follow the below instructions. ERROR MESSAGES EE1, EE2, EE3, Please contact your dealer or an authorized Sharp service agent because the EE6, E10, EE16, oven must be out of order. EE19 Exhaust air temperature is too high. Checking that nothing is blocking the ventilation openings or that room temperature is very hot or that oven cavity is empty during operation.
-
Page 17: Care And Cleaning
CARE AND CLEANING CLEAN THE OVEN AT REGULAR INTERVALS AND REMOVE ANY FOOD DEPOSITS - Keep the oven clean, or the oven could lead to deterioration of the surface.This could adversely affect the life of the appliance and possibly result in a hazardous situation. VERY IMPORTANT CAUTIONS: Splash cover •... -
Page 18: Service Call Check
B. At the end of this time, is the water warm? YES _____ NO ______ If “NO” is the answer to any of the above questions, call your dealer or an authorized SHARP Service Agent and report the results of your check. -
Page 19: Guide
GUIDE USEFUL THINGS TO KNOW ABOUT MICROWAVES Metals Microwaves set the water molecules contained in the food vibrating. The resulting friction generates should not, as a rule, be used in microwave ovens heat that can be used to defrost or cook the food. because microwaves cannot penetrate metals and reach the food inside. - Page 20 INFORMATION ABOUT POWER LEVEL 100%-70% power: The high power is perfect for warming up or regenerating food. You can also use it to make food boil e.g. water and then cook further with lower power. (e.g. for rice or noodles) 60%-40% power: For longer cooking times and compact types of food.
- Page 21 Recipes Bacon Place 2 thin slices of bacon between paper towels and cook approx. 15 sec. Omelette Toast Hawaii Sprinkle a normal plate with fat. Beat three eggs Prepare toasts and spread with butter. Place one with some salt and pepper. Pour the eggs on the plate slice of ham, pineapple and cheeses on a plate and and cook for approx.
-
Page 22: Specifications
(This product is designed for commercial application only and as such it falls outside the scope of Regulation (EC) 1275/2008 implementing EU Directive 2005/32/EC on eco-design requirements for standby and off mode electric power consumption. Sharp do not recommend the product for domestic application and will not accept any liability for such use.) - Page 23 NOTE EN-22...
- Page 24 Manufacturer: SHARP Corporation 1 Takumi-cho, Sakai-ku, Sakai-shi, Osaka 590-8522, Japan Authorised Representative: SHARP Electronics GmbH, Nagelsweg 33 - 35, 20097 Hamburg, Germany SDA/MAN/0301 V2 www.sharpconsumer.eu TINSZA339WRRZ-H31...
