- Page 1 FLB 3203 – 4G (Verizon) Extension Card INSTALLATION GUIDE IG-0025-00 1.1 en-US ENGLISH...
- Page 2 HMS Industrial Networks reserves the right to modify its products in line with its policy of continuous product development. The information in this document shall therefore not be construed as a commitment on the part of HMS Industrial Networks and is subject to change without notice.
-
Page 3: Table Of Contents
Table of Contents Page Preface ..........................3 About This Document .......................3 Document history ......................3 Related Documents ......................3 Trademark Information .....................3 Product Summary........................ 4 Safety, Environmental & Regulatory Information ............. 5 ESD Damage Prevention ....................5 Applicable Directives, Standards and Compliances ..............5 Official Modem Identification.....................6 Hardware Description ...................... - Page 4 This page intentionally left blank...
-
Page 5: Preface
Omni-directional antenna 4G - 3G - 2G Trademark Information ® Ewon is a registered trademark of HMS Industrial Networks SA. All other trademarks mentioned in this document are the property of their respective holders. IG-0025-00 1.1 en-US FLB 3203 – 4G (Verizon) Extension Card Installation Guide... -
Page 6: Product Summary
Product Summary 4 (18) Product Summary The present Installation Guide is focusing on the FLB 3203 - 4G (Verizon) extension card which, as such, needs to be inserted in one of the Flexy base units to work. The base units have their own Installation Guide which can be found in the Related Documents, p. -
Page 7: Safety, Environmental & Regulatory Information
Safety, Environmental & Regulatory Information 5 (18) Safety, Environmental & Regulatory Information The present heading addresses Safety, Environmental & Regulatory Information about the FLB 3203 - 4G (Verizon) extension card. This extension card belongs to the same compliance frame than the base units. In the present case of a telecommunication extension card, additional directives, standards and instructions apply. -
Page 8: Official Modem Identification
Safety, Environmental & Regulatory Information 6 (18) 3.2.3 Certifications The FLB 3203 has been certified by authorized bodies: UL Certificate of Compliance (COC) # E350576-20230306 • • CB certificate # DK-133387-UL These certificates can be downloaded as PDF files on the Ewon support web site: www.ewon.biz/ support Official Modem Identification... -
Page 9: Hardware Description
Hardware Description 7 (18) Hardware Description Mechanical Layout and Interfaces Fig. 1 Mechanical Layout SMA-F Female antenna connector SIM card drawer Backplane connector Extension Card Label 4.2.1 Label Location and Included Information The identification label of the extension cards is placed on the solder side of the PCB. The different parts of the label are described below: Label Description... -
Page 10: Front Panel Leds
Hardware Description 8 (18) 4.2.2 Part Number Structure for Extension Cards FLYXXXX_00/S FL is the prefix for the extensions of the Ewon Flexy family Only FL (constant) ●●○○ 1 alphabetic sign (CAP) 2 first slots only Defines the slots of the base module in which the extension card can be inserted. -
Page 11: Specifications Of The Lte Extension Card
The FLB 3203 must be inserted in one of the “B” slots of the base unit. The reference code of the extension cards includes a letter defining their compatibility: 4G antenna has to be purchased separately. HMS Industrial Networks SA offers such antenna under “FAC90901_0100” reference. - Page 12 Hardware Description 10 (18) • FLB xxxx: designate cards that fit into “B” slots. In addition to the card reference, each type of extension card bears a visual compatibility symbol on its front panel: Design Slot Type Flexy 205 Location Flexy 10x &...
- Page 13 Hardware Description 11 (18) Fig. 5 Position of the “B” Slots on a Flexy 10x & 20x. Cards that fit only in one slot type have a mechanical mistake-proof security to prevent them from being inserted in an incorrect slot type. IG-0025-00 1.1 en-US FLB 3203 –...
- Page 14 Hardware Description 12 (18) 4.6.2 SIM Card Insertion A SIM card obtained from a wireless phone provider is necessary to communicate through the FLB 3203. It must be inserted before inserting the extension card in the base unit as there is no external access to the SIM card holder.
-
Page 15: Extension Card Insertion
Hardware Description 13 (18) Extension Card Insertion 4.7.1 How to Insert into the Flexy Base Unit Wait 30 seconds after turning off the equipment before inserting (or removing) an extension card to avoid possible damage to the base unit and the extension cards. Remove the slot filler of the location the new card will be inserted. - Page 16 Hardware Description 14 (18) 4.7.2 Insertion of Multiple FLB 3203 Detection Order The boot sequence of the base unit includes an automated detection of the inserted extension cards. This detection is done sequentially, slot per slot starting from left to right (when holding the base unit with its logo on the right side).
- Page 17 Hardware Description 15 (18) The power requirements of each extension card is expressed in Energy Demand Points. This number is meant to check whether the balance with the Available Energy Points of a given base unit with extension cards is OK or not. The Energy Demand Points of the FLB 3203 is 8 The Installation Guide of the “eWON Flexy - Base...
-
Page 18: Check Card Detection On The Embedded Web Page
Check Card Detection on the Embedded Web Page 16 (18) Check Card Detection on the Embedded Web Page The Flexy extension cards require no software configuration. They are automatically detected by the base unit when the device boots. Connecting to the Embedded Web Server Configure the network parameters to set the computer being used to reach the web interface on the same IP range than the LAN of the Ewon device. -
Page 19: A Antenna Information
Appendix A: Antenna Information 17 (18) Antenna Information For more general & technical information concerning the antenna that can be combined with the FLB 3203, refer to the Knowledge Base: “Omni-directional antenna 4G - 3G - 2G” quoted in the Related Documents, p. - Page 20 © 2019 HMS Industrial Networks Box 4126 300 04 Halmstad, Sweden info@hms.se IG-0025-00 1.1 en-US / 2019-09-03 / 14612...
