WESTERSTRAND CIRCLE LINE 190420-00 User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Westerstrand Urfabrik AB
Box 133, SE-545 23 Töreboda
Tel.: +46 506 48000
User Manual
Westerstrand Tid System
User Manual
CIRCLE LINE
230VAC
190420-00
DOK11103en02
2023-03-31
www.westerstrand.se
info@westerstrand.se

Advertisement

loading
Need help?

Need help?

Do you have a question about the CIRCLE LINE 190420-00 and is the answer not in the manual?

Questions and answers

Related Manuals for WESTERSTRAND CIRCLE LINE 190420-00

Summary of Contents for WESTERSTRAND CIRCLE LINE 190420-00

  • Page 1 User Manual DOK11103en02 Westerstrand Tid System 2023-03-31 User Manual CIRCLE LINE 230VAC 190420-00 Westerstrand Urfabrik AB Box 133, SE-545 23 Töreboda www.westerstrand.se Tel.: +46 506 48000 info@westerstrand.se...

  • Page 2: Table Of Contents

    DOK11103en02 2023-03-31 2 (15) Index General ..............................3 Safety ............................... 3 Installation ............................... 4 Connection .............................. 5 Synchronisation ............................8 Programming ............................10 Technical specification .......................... 15...

  • Page 3: General

    DOK11103en02 2023-03-31 3 (15) General Digital clock is for indoor application with time display that has 4 digits and colon as time. The digits consist of 7 segments. The Digital clock can be configured to show the time/date/temperature alternately in 0- 25sec intervals.

  • Page 4: Installation

    DOK11103en02 2023-03-31 4 (15) Installation Wall mounted • Unscrew 4 screws, 2 pieces on each side. Remove the front and mount the back plate on the wall, using 4 screws suitable for the wall. We recommend Ø4mm and 30mm long screws.

  • Page 5: Connection

    DOK11103en02 2023-03-31 5 (15) Connection • The connecions are made on the inside of the back plate. Unscrew the cover and put aside without damaging the wire. • If operated by synchronisation, check the strapping according to the drawing page 6. Connect the cables according the schema page 5 and 6.
  • Page 6 DOK11103en02 2023-03-31 6 (15) Strapping/DIP switch setting for TC / MIN-impulse (default) Strapping/DIP switch setting for DCF-radio (2 –wire) computer board Strapping/DIP switch setting for DCF-radio (3 –wire) computer board...
  • Page 7 DOK11103en02 2023-03-31 7 (15) The DIP-switch on the computer board should be set as follows: Dip 1: OFF Display format is HH:MM. Display format is HH:MM:SS. Dip 2: OFF always OFF Dip 3: OFF TC/Min impulse-synchronisation. (default) DCF synchronisation. Dip 4: OFF TC/Min impulse or 3-wire DCF synchronisation.

  • Page 8: Synchronisation

    DOK11103en02 2023-03-31 8 (15) Synchronisation Stand-alone If the clock does not have an external synchronisation, it operates Stand-alone Minute impulse Make the strapping according to the drawing for strapping page 6. Connect the minute impulse wire according to the schema page 5. The clock can be set in synchronisation or slave mode.
  • Page 9 DOK11103en02 2023-03-31 9 (15) Connection temperature sensor (this is an option). Temperature sensor connection 1. Brown 2. Black 5. Screen Sync. input...

  • Page 10: Programming

    DOK11103en02 2023-03-31 10 (15) Programming The programming is made by push buttons (see below). R (Return) Enter the base mode (display time) F (Function) Next function / Accept displayed value P (Program) Enter the displayed function / Increase displayed value.
  • Page 11 DOK11103en02 2023-03-31 11 (15) Programming time Push [F] until display shows: ti ne yy 95 Push [P] display shows: year. Push [P] until desired year (00-99) Accept with [F]. nn 1 Display shows: month. Push [P] until desired month (1-12). Accept with [F].
  • Page 12 DOK11103en02 2023-03-31 12 (15) Setting light intensity The light intensity for the digits can be adjusted in 8 levels. An automatic dimmer function regulates the light intensity. di sp Push [F] until display shows: Push [P] di 1 Display shows: Light intensity 1 (weakest) - 8 (strongest) Push [P] for desired light intensity.
  • Page 13 DOK11103en02 2023-03-31 13 (15) Setting alternating time, Loop time LooP Push [F] until display shows: Push [P]. L1 4 Display shows: Alternating time for display time is 4 seconds. Push [P] for desired alternating time (0-25). Accept with [F]. Display shows: Alternating time for display temp.
  • Page 14 DOK11103en02 2023-03-31 14 (15) Setting DLS-function. With this function the DLS can be activated. Push [F] until display shows: Push [P]. Display shows: Push [P] for DLS or not. Push [R] for entering base mode or push [F] for next function. Setting12/24 h format.

  • Page 15: Technical Specification

    DOK11103en02 2023-03-31 15 (15) Technical specification General Art. no.: 190420-00 Denomination: Circle Line Mounting/Installation: Single sided, wall mount Digits: Single line red LED. Indicating time in HH:MM Digit height: 50 mm Polarised 24V impulse 1/1, TC, DCF Synchronisation: Accuracy: 0,1 sec/24 h at 22 C (free-running mode) Internal time keeping during power failure: 48 hours (display is turned off)
