Scell-it ELEMENT 007 Operating Instructions page 2

Cordless setting tool
Hide thumbs Also See for ELEMENT 007:

Advertisement

1
7
8
3
4
1
Puller
2
Stroke setting dial
3
Trigger
4
Unlock battery buttons
● ADJUSTING THE STROKE:
Use the stroke setting knob
on the back of the E-007:
2
• The stroke range is 4 to 40mm
• Each pitch is 1.2mm
In general, the stroke required for a perfect installation depends on the length of the hollow
wall anchor.
But this can vary according to the
different designs of the HWA on
the market.
ADVICE
Refer to the table for
recommended stroke settings.
Blank test a HWA and adjust the
setting if necessary.
● WARNING:
E-007 does not have a clutch system. If the stroke is set too high, it could lead to damage
of the anchor or the plasterboard wall.
To avoid this, it is strongly recommended to carry out a «blank» test on a sample wall
before installing the anchor on the wall.
A good installation will be a deformation of the anchor legs between 90° to 110° (see
pictures below), which allows a good locking without damaging the wall (a slight
penetration of the legs into the wall is tolerated and even recommended for a tighter hold):
90°
MAINTENANCE / TROUBLESHOOTING / SAFETY INFORMATION
See details and illustrations in user manual.
OPERATING INSTRUCTIONS
2
5
6
5
Battery charge test button
6
Battery charge indicator
7
LED lights
8
Reverse button
RECOMMENDED
STROKE SETTING
(data for information
HWA
only)
LENGTH
mm
mm
23
8-12
33-37-40
16-18
46-47-50-53
24-26
63-66
24-26-28
75
38
40
80
110°
Beacon Industrial Estate - Weston road - Stafford ST18 0DG - Tel: 01785 246539 - sales@scellit.co.uk - www.scellit.co.uk
● HOLLOW WALL ANCHOR INSTALLATION:
1
Drill the wall to the
recommended diameter of
the HWA.
4
Check «reverse button»
set correctly (pressed on the
right side).
Pull the trigger to expand the
HWA and cause it to grip the
wall securely.
● REMOVE THE BATTERY:
Battery is locked to the riveting tool with a spring.
To remove the battery, press the 2 unlock buttons
Do not force it.
● BATTERY LEVEL INDICATOR:
4 lights on the battery panel allows you to check the remaining power. Press and hold the
blue button
5
4 lights on : 100% remaining
3 lights on : 75% remaining
2 lights on : 50% remaining
1 light on : 25% remaining
The information on the battery panel can vary (+/- 5%) due to
environmental conditions.
Green light on the charger:
the battery is fully charged
● LED LIGHTS:
The tool is equipped with 3 powerful LED lights
the working area.
Turn on the light only
Press the trigger half way to turn on the light. The lights will
shutdown after 10 seconds.
Turn on the tool with the lights on
Press the trigger
seconds after the trigger is released.
T E C H N I C A L S E R V I C E
2
Slightly unscrew the screw
from the HWA to insert the
carriage of the puller
between the screw head and
the flange of the HWA.
5
Release the trigger: the puller
is
8
will automatically go back to
the initial position.
Then release the tool.
4
to check the battery level:
Red light on the charger:
the battery has to be charged
7
. The lights turn on and remain on until 10
3
3
Insert the HWA into the hole:
the flange of the HWA should be
flush to the surface of the wall
1
(the small lugs slightly recessed
in the wall).
6
Remove the screw / place your
object / re-screw to fix it.
and slide the battery.
100%
75%
50%
25%
to light up
