İÇİNDEKİLER A – GENEL BİLGİLER Sayfa 2 A1 – ÜRÜN TANIMI Sayfa 3 A2 – TEKNİK BİLGİLER Sayfa 3 A3 – TAŞIMA ve SAKLAMA ŞARTLARI Sayfa 4 A4 – PAKETİ AÇMA Sayfa 4 B – KURULUM Sayfa 5 C – GENEL UYARILAR Sayfa 6 D –...
Page 4
A – GENEL BİLGİLER BU KULLANIM KILAVUZUNDAKİ TÜM TALİMAT VE UYARILARI DİKKATLİCE OKUYUNUZ. BU KILAVUZ ÜRÜNÜNÜZÜN GÜVENLİ KURULUMU, KULLANIMI VE BAKIMI HAKKINDA ÖNEMLİ BİLGİLER VE CİHAZINIZDAN EN YARARLI BİÇİMDE FAYDALANMANIZ İÇİN GEREKLİ UYARILAR İÇERMEKTEDİR. BU KILAVUZU İLERDE GEREKLİ OLDUĞUNDA KULLANMAK ÜZERE GÜVENLİ VE KOLAY ULAŞILABİLİR BİR YERDE SAKLAYINIZ.
Page 6
B – KURULUM - Kurulum, talimatlara göre yetkili bir teknisyen tarafından yapılmalıdır. Firmamız, yanlış kurulumdan dolayı insanlara, hayvanlara veya eşyalara gelebilecek zararlardan sorumlu tutulamaz. - Cihazın arızalanması durumunda cihazı kapatınız. Cihaza sadece üretici tarafından yetkilendirilmiş bir servis merkezi hizmet vermelidir. Orijinal yedek parça isteyiniz. - Cihazın konulacağı...
Page 7
C – GENEL UYARILAR Bu cihaz yürürlükteki yönetmeliklere uygun olarak tesis edilmeli ve yalnız iyi havalandırılmış bir yerde kullanılmalıdır. Cihazın tesisi için ve kullanımdan önce talimatlara başvurun. Cihaz endüstriyel kullanım amaçlı yapılmış olup sadece cihazla ilgili eğitim almış elemanlar tarafından kullanılmalıdır Uygun koruyucu ekipmanlar kullanmadan cihaza müdahalede bulunmayınız.
Page 8
D – KULLANIM BİLGİLERİ Şekil 1 Kontrol Panosu Cihaz açık konumda iken butonları yardımıyla hız değeri A: HIZ AYARLAMA ayarlanır. Ekranda ayarlanan hız değeri gözükür. (1- Yavaş/10- Hızlı) B: MANUEL START Cihaz açık konumda iken butonuna basılı tutulduğu sürece önceden ayarlanan hız değerinde çalışır. C: CİHAZI AÇMA VE KAPATMA Cihazı...
Page 9
- Cihazın kullanımı: Cihazı ilk kullanımdan önce, karıştırma haznesi ve karıştırıcı aparatların temiz olduğundan emin olunuz. Cihaz açık konumda iken hazne yerine yerleştirilip start verilebilir. Hazne yerinde değil ise Ekranda E-1 hatası gözükmektedir. Cihaz çalışırken hazne yerinden alınırsa cihaz otomatik olarak stop konumuna geçer.
Page 10
F – SORUN GİDERME NEDENİ NASIL GİDERİLECEĞİ SORUN - Elektrik bağlantısını kontrol Cihaza elektrik gelmiyor ediniz. CİHAZ olabilir. - Sigortanın açık olup ÇALIŞMIYOR Sigorta açık olmayabilir. olmadığını kontrol ediniz. Yanlış hız kademesinde - Hız kademesini kontrol ediniz. olabilir. İYİ Kapasitesine uygun PARÇALAMIYOR - Malzeme miktarını...
Page 11
G – DEMONTE GÖRÜNÜŞ ve YEDEK PARÇA KAPAK SENSÖRLÜ...
Page 12
BAR BLENDERİ – KAPAK SENSÖRLÜ PARÇA ADI P.KODU KARIŞTIRICI MONTAJI BLE01 Karıştırıcı Hazne Tutucu Omk.YPC01.BLE01.001 BLE01 Karıştırma Haznesi Konum Mıknatısı Omk.YPC50.BLE01.020 Sensör Muhafaza Kapağı Omk.YPC01.PLS03.004 BLE01 Karıştırma Haznesi Kapak Sensörü Omk.YPC03.BLE01.005 Kapak Sensörü Omk.YPC03.SNS01.002 BLE01 Üst Ana Gövde Siyah Omk.YPC01.BLE01.005 BLE01 Üst Ana Gövde Beyaz Omk.YPC01.BLE01.006 BLE01 Üst Ana Gövde Kırmızı...
Page 15
G – DEMONTE GÖRÜNÜŞ ve YEDEK PARÇA KAPAK SENSÖRSÜZ...
Page 16
BAR BLENDERİ – KAPAK SENSÖRSÜZ PARÇA ADI P.KODU KARIŞTIRICI MONTAJI BLE01 Karıştırıcı Hazne Tutucu Omk.YPC01.BLE01.001 BLE01 Sensör Borusu Üst Muhafaza Tapası Omk.YPC01.BLE01.003 BLE01 Üst Ana Gövde Siyah Omk.YPC01.BLE01.005 BLE01 Üst Ana Gövde Beyaz Omk.YPC01.BLE01.006 BLE01 Üst Ana Gövde Kırmızı Omk.YPC01.BLE01.007 BLE01 Üst Ana Gövde Mavi Omk.YPC01.BLE01.008 BLE01 Üst Ana Gövde Sarı...
Page 18
KAPAK SENSÖRSÜZ KARIŞTIRICI DETAY PARÇA ADI P.KODU BLE01 Tokmak Omk.YPC01.BLE01.019 BLE01 Karıştırma Haznesi Malzeme Doldurma Ağzı Kapağı Omk.YPC01.BLE01.021 BLE01 Karıştırma Haznesi Takımı Omk.YPC01.BLE01.023 BLE01 Blender Bıçağı Omk.YPC50.BLE01.024 BLE01 Blender Bıçak Somunu Omk.YPC01.BLE01.025 BLE01 Blender Bıçak Montaj Braketi Omk.YPC01.BLE01.026...
Page 19
H – ELEKTRİK ŞEMASI KAPAK SENSÖRLÜ AŞIRI YÜK KORUMA TERMİĞİ 15A MOTOR 2200 W 220-240V 50-60 HZ SÜRAHİ ALT SENSÖR SÜRAHİ KAPAK SENSÖR...
Page 20
H – ELEKTRİK ŞEMASI KAPAK SENSÖRSÜZ AŞIRI YÜK KORUMA TERMİĞİ 15A MOTOR 2200 W 220-240V 50-60 HZ SÜRAHİ ALT SENSÖR...
Page 21
I – GARANTİ BELGESİ ÜRETİCİ/İTHALATÇI FİRMA ÜNVANI: ADRESİ: TLF – FAX: KAŞE – İMZA: SATICI FİRMA ÜNVANI: ADRESİ: TLF – FAX: KAŞE – İMZA: FATURA TARİHİ – NO CİNSİ MARKA ÜRÜN ADI ÜRÜN MODELİ SERİ NO ÜRÜN TESLİM TARİHİ ve YERİ GARANTİ...
A – GENERAL INFORMATION READ CAREFULLY ALL INSTRUCTIONS AND WARNINGS IN THIS USER MANUAL. THIS MANUAL CONTAINS IMPORTANT INFORMATION ABOUT THE SAFE INSTALLATION, USE AND MAINTENANCE OF YOUR PRODUCT AND NECESSARY WARNINGS FOR YOU TO USE THE MOST USEFUL FROM YOUR DEVICE. KEEP THIS MANUAL IN A SAFE AND EASY REACH FOR FUTURE USE.
B – INSTALLATION - Installation should be done by a qualified technician according to the instructions. Our company cannot be held responsible for any damage to people, animals or property due to incorrect installation. - In case the device malfunctions, turn off the device. Only a service center authorized by the manufacturer should service the device.
C – SAFETY INSTRUCTIONS This device must be installed in accordance with current regulations and used only in a well-ventilated area. Consult instructions for setting up the device and before use. The device is made for industrial use and should only be used by personnel trained in the device Do not interfere with the device without using appropriate protective equipment.
D – OPERATION INFORMATION Figure 1 Control Panel A: SPEED ADJUSTMENT When the device is on, the speed value is adjusted with the help of buttons. The set speed value appears on the screen. (1- Slow / 10- Fast) While the device is on, it will operate at the speed you have set before, as B: MANUALLY START long as the...
- Usage: Before using the appliance for the first time, make sure that the mixing chamber and agitator attachments are clean. While the device is on, the chamber can be placed in its place and started. If the chamber is not in place, the E-1 error will appear on the Display.
F – TROUBLESHOOTING PROBLEM REASON HOW TO REMOVE The device may not be - Check the electrical connection. THE APPLIANCE receiving electricity. - Check the fuse box DOESN’T Circuit breaker may not be connection. OPERATE open. It may be at the wrong speed range.
G – EXPLODING DRAWING AND SPARE PART LIST WITH LID DENSOR...
Page 31
BAR BLENDER – WITH LID SENSOR PART NAME P.CODE MIXING MANTAGE BLE01 Mixing Bowl Holder Omk.YPC01.BLE01.001 BLE01 Mixing Bowl Position Magnet Omk.YPC50.BLE01.020 BLE01 Sensor Tube Hole Cover Omk.YPC01.PLS03.004 BLE01 Mixing Bowl Lid Sensor Omk.YPC03.BLE01.005 BLE01 Mixing Bowl Lid Sensor Tube Omk.YPC03.SNS01.002 BLE01 Main Body Top (Black) Omk.YPC01.BLE01.005...
Page 33
WITH LID SENSOR CONTAINER DETAIL PART NAME P.CODE BLE01 Mixing Knob Omk.YPC01.BLE01.019 BLE01 Magnet For The Mixing Bowl Lid Omk.YPC50.BLE01.002 BLE01 Mixing Bowl Filling Funnel Omk.YPC01.BLE01.022 BLE01 Mixing Bowl Set Omk.YPC01.BLE01.023 BLE01 Blender Blade Set Omk.YPC50.BLE01.024 BLE01 Blender Blade Nut Omk.YPC01.BLE01.025 BLE01 Blender Blade Montage Bracket Omk.YPC01.BLE01.026...
Page 34
G – EXPLODING DRAWING AND SPARE PART LIST WITHOUT LID SENSOR...
Page 35
BAR BLENDER – WITHOUT LID SENSOR PART NAME P.CODE MIXING MANTAGE BLE01 Mixing Bowl Holder Omk.YPC01.BLE01.001 BLE01 Sensor Tube Waterproof Cover Omk.YPC01.BLE01.003 BLE01 Main Body Top (Black) Omk.YPC01.BLE01.005 BLE01 Main Body Top (White) Omk.YPC01.BLE01.006 BLE01 Main Body Top (Red) Omk.YPC01.BLE01.007 BLE01 Main Body Top (Blue) Omk.YPC01.BLE01.008 BLE01 Main Body Top (Yellow)
H – ELECTRICAL CIRCUIT DIAGRAM WITH LID SENSOR OVERLOAD PROTECTION THERMAL 15A ENGINE 2200 W 220-240V 50-60 HZ BOTTOM SENSOR OF THE PITCHER COVER SENSOR OF THE PITCHER...
Page 39
H – ELECTRICAL CIRCUIT DIAGRAM WITHOUT LID SENSOR OVERLOAD PROTECTION THERMAL 15A ENGINE 2200 W 220-240V 50-60 HZ BOTTOM SENSOR OF THE PITCHER...
