F8L10ST
LoRaWAN
Terminal User Manual
F8L10ST LoRaWAN Terminal
Model
F8L10ST-A-L
F8L10ST-A-H
F8L10ST-B-L
F8L10ST-B-H
Document Version
Product Name： F8L10ST
User Manual
Disposable lithium battery
Frequency：410-510 MHz
Disposable lithium battery
Frequency：863-928 MHz
Rechargeable lithium battery
Frequency：410-510 MHz
Rechargeable lithium battery
Frequency：863-928 MHz
The user manual is suitable for the following model:
Address：Xiamen Four-Faith Communication Technology Co., Ltd.
V1.0.0
Product
hotline：400-8838 -199
Tel：+86-592-6300320
Fax：+86-592-5912735
Website：en.four-faith.com
Page
Total: 14
Advertisement
Table of Contents
Related Manuals for Four-Faith F8L10ST
Summary of Contents for Four-Faith F8L10ST
- Page 1 Frequency：410-510 MHz F8L10ST-A-H Disposable lithium battery Frequency：863-928 MHz F8L10ST-B-L Rechargeable lithium battery Frequency：410-510 MHz F8L10ST-B-H Rechargeable lithium battery Frequency：863-928 MHz The user manual is suitable for the following model: hotline：400-8838 -199 Tel：+86-592-6300320 Fax：+86-592-5912735 Website：en.four-faith.com Address：Xiamen Four-Faith Communication Technology Co., Ltd.
- Page 2 F8L10ST LoRaWAN terminal user manual File Revised Record Date Version Remark Author 2019-07-15 V1.0.0 Initial version 2/13 Add： Floor 11,Area A06, No 370, chengyi street, Jimei, Xiamen.China http://en.four-faith.com Tel： +86 592-5907276 Fax：+86 592-5912735...
- Page 3 All contents in the files are protected by copyright law, and all copyrights are reserved by Xiamen Four-Faith Communication Technology Co., Ltd. Without written permission, all commercial use of the files from Four-Faith are forbidden, such as copy, distribute,reproduce the files, etc., but non-commercial purpose, downloaded or printed by individual (all files shall be not revised, and the copyright and other proprietorship notice shall be reserved) are welcome.
- Page 4 F8L10ST LoRaWAN terminal user manual Note:There may be difference between models of accessories and interfaces,actual products shall prevail 4/13 Add： Floor 11,Area A06, No 370, chengyi street, Jimei, Xiamen.China http://en.four-faith.com Tel： +86 592-5907276 Fax：+86 592-5912735...
-
Page 5: Table Of Contents
F8L10ST LoRaWAN terminal user manual Contents Chapter 1 Brief Introduction of Product..................5 1.1 Working principle and diagram..................6 1.2 Indicator Lights Introduction.....................7 1.3 Button/key Introduction.....................7 Chapter 2 Configuration Introduction....................8 2.1 Physical Connection......................8 2.2 Introduction of parameter configuration.................8 2.3 Detailed Parameters....................... 10 2.3.1 Network ........................10... -
Page 6: Working Principle And Diagram
F8L10ST LoRaWAN terminal user manual Chapter1 Brief Introduction F8L10T LoRa data transmission terminal is a wireless data transmission terminal based on LoRa spread spectrum technology，support connecting to all kinds of sensors with different interfaces This product adopts industrial grade Lora scheme with high performance, based on... -
Page 7: Indicator Lights Introduction
F8L10ST LoRaWAN terminal user manual 1.2 Indicator Lights Introduction LoRa terminal provides 1 indicator light,status are as follows: Indicator light Status description Power off/sleep Working normally blinking Joining network 1.3Button/Key introduction LoRa terminal provides 2 key/button: button description ON/OFF Power on/off Reset button Note：power on and off if you are holding the button more than 3 seconds... -
Page 8: Chapter 2 Configuration Introduction
2.2 Introduction of parameters configuration Two ways to config the parameters of F8L10ST： 1、Four-Faith Configuration software tool ”LoRaConfig”: All the settings are configured through the shipped software tool. It’s necessary to have one PC to run this tool. 2 、 Extended AT command: All the settings are configured through AT command, so any device with serial port can configure it. - Page 9 After the serial port is open,select “load the parameters”. The current configuration parameters will automatically load into the device. The parameters are displayed on the left side area. You can start to configure all the parameters in the F8L10ST, as shown in Figure 2-2. 9/13 Add：...
-
Page 10: Detailed Parameters
Device Class: support Class A and Class C for now Response Type：it decides whether the server will respond after terminal send data Device EUI、AppKey、AppEUI：ask Four-Faith enginners for these parameters for device network join Adaptive Rate ： LoRaWAN's ADR speed control mechanism is applicable to non-mobile ... -
Page 11: System
2.3.3 Serial Port Frame interval is fixed as 20ms,when users change the parameters,press”write params”and “reboot device”to take effect.Refer to <<F8L10ST AT Command User manual V1.0.0>>or above version for further information Serial port 1：Configure the parameters of RS232 in F8L10ST ... -
Page 12: Di、D2 Function
F8L10ST LoRaWAN terminal user manual Serial port 2 ： Configure the RS485 parameters of F8L10ST,can be used to connect sensors;the baudrate need to be set according to the real sensor Default value: baudrate use 115200,Attribute is 8N1 2.3.4 DI、D2 Function IO mode: DI and D2 can be configured as disabled,Input,Output mode(high level or low ... -
Page 13: Ai、A2 Function
F8L10ST LoRaWAN terminal user manual 2.3.5 AI、A2 Function A1、A2 （ port 10,11）can be configed as analog inputs,(A1 collect analog input voltage 0-5V,A2 collect current 0-20mA) Calculate Formula are as follows: Voltage：（collected value）*3.3*20.3/（4095*12.1）V Current：（collected value）*3.3*1000/（4095*150）（mA） IO mode：disabled or analog input Report interval：periodically report data,defualt is 0 which means it doesn’t report Take A1,A2 as example,A1 is disabled,A2 collect and report ADC value every 3 minites 2.3.6 voltage output（3.3V、12V）... -
Page 14: Chapter 3 Testing Duidance
F8L10ST LoRaWAN terminal user manual commands in order with a period.if all the command boxes are blank,serial port will send the default command(fixed in the firmware) Example： Config the first command as 0x11 0x11 0x11 0x11 0x11 0x11,time interval is 5 minutes,Then...
