F8L10T LoRa
Terminal User
Manual
F8L10T LoRa Terminal
Document Version
V1.1.2
Product Name：F8L10T
User Manual
Xiamen Four-Faith Communication Technology Co., Ltd.
Add：11th Floor, A-06 Area, No.370, Chengyi Street, Jimei,
Xiamen, Fujian, China.
Tel：+86 592-5907276
Fax:+86 592-5912735
Web:en.four-faith.com
Page
Total:18
Advertisement
Table of Contents
Related Manuals for Four-Faith F8L10T
Summary of Contents for Four-Faith F8L10T
- Page 1 F8L10T LoRa Document Version Page Terminal User V1.1.2 Manual Product Name：F8L10T Total:18 F8L10T LoRa Terminal User Manual Xiamen Four-Faith Communication Technology Co., Ltd. Add：11th Floor, A-06 Area, No.370, Chengyi Street, Jimei, Xiamen, Fujian, China. Tel：+86 592-5907276 Fax:+86 592-5912735 Web:en.four-faith.com...
- Page 2 F8L10T LoRa Terminal User Manual Files Revised Record Date Version Remark Author 2016-12-19 V1.0.0 Initial version According to the product line , modify the radio frequency description. 2017-02-20 V1.1.0 Adjust the parameter configuration section with multiple details. Add Formulas to calculate collected 2017-08-17 V1.1.1...
- Page 3 All contents in the files are protected by copyright law, and all copyrights are reserved by Xiamen Four-Faith Communication Technology Co., Ltd.Without written permission, all commercial use of the files from Four-Faith are forbidden, such as copy, distribute, reproduce the files, etc., but non-commercial purpose, downloaded or printed by individual (all files shall be not revised, and the copyright and other proprietorship notice shall be reserved) are welcome.
- Page 4 F8L10T LoRa Terminal User Manual Page 4 of 18 Xiamen Four-Faith Communication Technology Co.,Ltd. Add： 11th Floor, A-06 Area, No.370, Chengyi Street, Jimei, Xiamen, Fujian, China. http://en.four-faith.com Tel： +86 592-5907276 Fax：+86 592-5912735...
- Page 5 F8L10T LoRa Terminal User Manual FCC WARNING Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the...
-
Page 6: Table Of Contents
F8L10T LoRa Terminal User Manual Chapter 1 Brief Introduction of Product ..................7 1.1 General ..........................7 1.2 Features and Benefits ....................... 7 1.4 Specifications ........................8 Chapter 2 Installation Introduction ..................... 10 2.1 General ........................... 10 2.2 Encasement List ......................10 2.3 Installation and Cable Connection ................. -
Page 7: Chapter 1 Brief Introduction Of Product
F8L10T LoRa Terminal User Manual Chapter 1 Brief Introduction of Product 1.1 General F8L10T LoRa data transmission terminal is a wireless data transmission terminal based on LoRa spread spectrum technology. At the same time using Lora wireless transmission technology for short distance data transmission. -
Page 8: Specifications
F8L10T LoRa Terminal User Manual Support several work modes Convenient configuration and maintenance interface High-performance Support Lora wireless short-range data transmission capabilities, with self-organizing network capabilities Relay routing and terminal device functionality Network capacity: 65000 nodes (typical number of 300) ... - Page 9 F8L10T LoRa Terminal User Manual Baud rate: 300、600、1200、2400、4800、9600、19200、38400、57600、115200bps Indicator “Power”, “ACT”, "Online” Antenna LoRa : Standard SMA female interface, 50 ohm, lighting protection(optional) Power Terminal block interface, reverse-voltage and overvoltage protection Power supply Item Content Standard Power DC 12V/0.5A Power range...
-
Page 10: Chapter 2 Installation Introduction
F8L10T LoRa Terminal User Manual Chapter 2 Installation Introduction 2.1 General The LoRa Terminal must be installed correctly by professional Installer to make it work properly. Warning: 1.Forbid to install the MODEM when powered! 2.This device will not be sold to the general public,it will be sold to dealers only. - Page 11 F8L10T LoRa Terminal User Manual Ф3 Ф5 Installation of antenna: Screw the SMA male pin of the LoRa antenna to the female SMA interface of the Device with sign “LoRa”. Warning: The cellular antenna and the LoRa antenna can not be connected wrongly.
- Page 12 F8L10T LoRa Terminal User Manual antenna mode Figure 2-2 Installation User Interface Signal Definition Pin Number Signal Name Default Function Extensible Function Power input anode Power Ground Power Ground RS232 RX RS232 TX RS485 anode RS485 cathode GPIO sleep control...
- Page 13 F8L10T LoRa Terminal User Manual function (voltage acquisition 0 ~ 5 V) ADC, analog input GPIO function (current collection 0 ~ 20 mA) ADC, analog input GPIO function (current collection 0 ~ 20 mA) Formulas to calculate collected value of ADC Voltage: (collected value)*3.3*20.16/(4095*12.1) V...
-
Page 14: Power
F8L10T LoRa Terminal User Manual Power adapter and communication cable connection chart as following: Connect via RS232 Connect via RS485 + Anode + Anode - Cathode - Cathode User Device F8L10T User Device F8L10T (DB9M) 2.4 Power The power range of the LoRa Terminal is DC 5~36V. -
Page 15: Chapter 3 Configuration
F8L10T, windows of the super terminal, Linux minicom, putty, or directly by the user's SCM system to node configuration. In the use of extended at command to configure F8L10T to bring F8L10T into the configuration state. -
Page 16: Detailed Parameters
The serial port parameter settings column if the right button is displayed as "closed serial". That serial port has been opened, otherwise please open the serial port. The equipment again after power, configuration software f8l10t into the configuration state, and automatically load the current configuration parameters of equipment, in the area on the right side of the display parameters, thus can start all configuration parameters in the configuration F8L10T, as shown in Figure 3-2. -
Page 17: Serial Port Work Mode
F8L10T LoRa Terminal User Manual 3.3.2 serial port work mode Module serial data work can be divided into "TRNS","AT" and "API". "TRNS": data transmission, when the need to pass through the address configuration, namely the destination address. "AT": protocol format reference "Lora AT commands manual",usually used for parameter configuration and manual testing. -
Page 18: Debug Level
F8L10T LoRa Terminal User Manual In regular sleep, keep the device dormant time, unit MS, when the device sleep over this time will wake up, in a normal working state. 3.3.7 Debug level Debug level control module log display, can be divided into three debugging levels, which:...
