Summary of Contents for Xtramus NuStreams-700
- Page 1 NuStreams-700 User’s Manual USM Ver 1.2...
-
Page 2: Foreword
Copyright Copyright © 2021 Xtramus Technologies, all rights reserved. The information contained in this document is the property of Xtramus Technologies. No part of this publication shall be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, without the prior written permission of Xtramus Technologies. -
Page 3: Revision History
Revision History Date Version History 2016/08/23 First draft version Add XM-RM882 description 2020/02/19 Remove 2 software description Modify the description about module LED 2021/01/04 Remove software descriptions that are no longer maintained... -
Page 4: Table Of Contents
G. XM-RM781 ........................22 H. XM-RM881 ........................23 I. XM-RM882 ......................... 24 5. Example of suitable software for NuStreams-700 ..............25 5.1. NuWIN-RM ........................25 5.2. NuApps-2544-RM ......................26 5.3. NuApps-MultiUnits-RM ....................28 6. Appendix – Other Utility Softwares for NuStreams-700 ............29... -
Page 5: Nustreams-700 Overview
X-TAG, a feature for verifying the integrity of the embedded memory of a switch controller by checking an unique tag attached to each packet sent from NuStreams-700 is supported by all test modules. Intelligence chassis with enhanced fan development makes NuStreams-700 even more stable and reliable. -
Page 6: Key Features Of Nustreams-700
Performing synchronized tests between module cards Multi-user function for module cards that can provide greater hardware-efficiency Utility software provided by Xtramus Technologies which can analyze the test results and DUT performance with intuitive GUI interface. Module cards that work as management interfaces of NuStreams-700 are available and support different Ethernet transferring rate. -
Page 7: Nustreams-700 Functions And Structure Overview
2. NuStreams-700 Functions and Structure Overview 2.1. Structure Overview NuStreams-700’s outer case is dedicatedly designed in its Front Panel, Top Panel and Bottom Panel. The figure above shows the outer case of NuStreams-700. NuStreams-700 Outer Case Overview NuStreams-700 has 7 slots for installation of module cards, where each module card provides streams generating platforms for different types of media. -
Page 8: Replaceable Fans
2.2. Replaceable Fans The fans for cooling the chassis attached to the Top & Bottom Panel are easily to replace. The steps to replace the fans are: 1. Unscrew the screws on the Top/Bottom Panel 2. Open the Top/Bottom Panel 3. -
Page 9: Nustreams-700 Installation
As cited above, NuStreams-700 is a chassis with 7 slots for installation of module cards. Installing NuStreams-700 is very easy and simple: all you have to do is to plug the proper fiber/UTP cables into NuStreams-700 ports. Selecting the proper physical media and applications in your network environment is crucial when installing NuStreams-700. -
Page 10: 10Gbase-R (Optical Fiber)
3.1.2. 10GBASE-R (Optical Fiber) 10GBASE-R is 10Gbps Ethernet connection that based on IEEE802.3ae. It uses fiber as transmission media with different specification of fiber, connector and transceiver. MCS-2160 uses two standards, 10GBASE-LR and 10GBASE-SR. 10GBASE-SR 10GBASE-SR ("Short Range") uses 64B/66B encoding and 850 nm wavelength lasers. It is designed to support short distances over deployed multi-mode fiber cabling, it has a range of between 26 meters (85 ft) and 82 meters (270 ft) depending on cable type. - Page 11 Optical Fiber As mentioned above, there are Single-mode and Multi-mode optical fiber. Both of them can be used for NuStreams module’s fiber port. Fiber Connector Optical fiber connector contains two ends of fibers and can attach to SFP+ transceivers. There are two ports for one SFP+ transceiver: one fiber is for receiving and one fiber is for transmitting.
-
Page 12: Hardware Installation
Please follow the steps shown below for a better understanding on how to install hardware in NuStreams-700. 3.2.1. Bracket installation Steps for installing a Bracket in NuStreams-700 First of all, you must have an Empty Slot for the Installation of a Bracket. -
Page 13: Module Cards Installation
3.2.2. Module Cards Installation Steps for installing a XM-RM Module Card in NuStreams-700 Aim the border side of a XM-RM Module Card with the NuStreams-700 internal slide road, and push this Module Card into the NuStreams-700. Please, make sure if the XM-RM... -
Page 14: Nustreams-700'S Module Cards
Measuring Module sending/receiving. These Measuring Module XM-RM751 Cards cards can be installed in NuStreams-700 support XM-RM761 hot-swap. XM-RM781 XM-RM881 XM-RM882 Please see the sections down below for more detail information regarding to NuStreams-700 Module Cards. -
Page 15: System Module Cards
Green ON. The system is in single-user mode when Green ON. The system is in multi-user mode when Green ON. *Note: Please do not draw the XM-3S3GS module card from NuStreams-700 chassis when the system is power... -
Page 16: Xm-70Pw
XM-70PW is booting and preparing for test, or is power on but not Yellow ON Fault operating properly Yellow OFF XM-70PW is OFF or is operating *Note: Please do not draw the XM-70PW module card from NuStreams-700 chassis when the system is power on. -
Page 17: Measuring Module Cards
4.2. Measuring Module Cards A. XM-RM661 XM-RM661 Front Panel Specification Port 1 Port 2 Interface Port 3 Port 4 Data Transfer Rate 100 Mbps LED Status Green ON The module card is operating Yellow ON The module card is updating the Firmware (Blinking) Yellow/Green The module card is booting and preparing for... -
Page 18: Xm-Rm671
B. XM-RM671 XM-RM671 Front Panel Specification Port 1 Port 2 Interface Port 3 Port 4 Data Transfer Rate 100 Mbps LED Status Green ON The module card is operating Yellow ON The module card is updating the Firmware (Blinking) Yellow/Green The module card is booting and preparing for ON (Blinking) test... -
Page 19: Xm-Rm681
C. XM-RM681 XM-RM681 Front Panel Specification Port 1 RJ45 Port 2 RJ45 Interface Port 3 RJ45 Port 4 RJ45 Data Transfer Rate 100 Mbps LED Status Green ON The module card is operating Yellow ON The module card is updating the Firmware (Blinking) Yellow/Green The module card is booting and preparing for... -
Page 20: Xm-Rm731
D. XM-RM731 XM-RM731 Front Panel Specification Port 1 RJ45 + SFP Interface Port 2 RJ45 + SFP Data Transfer Rate 1000 Mbps LED Status Green ON The module card is operating Yellow ON The module card is updating the Firmware (Blinking) Yellow/Green The module card is booting and preparing for... -
Page 21: Xm-Rm751
E. XM-RM751 XM-RM751 Front Panel Specification Port 1 RJ45 Port 2 RJ45 Interface Port 3 Port 4 Data Transfer Rate 1000 Mbps LED Status Green ON The module card is operating Yellow ON The module card is updating the Firmware (Blinking) Yellow/Green The module card is booting and preparing for... -
Page 22: Xm-Rm761
F. XM-RM761 XM-RM761 Front Panel Specification Port 1 Port 2 Interface Port 3 Port 4 Data Transfer Rate 1000 Mbps LED Status Green ON The module card is operating Yellow ON The module card is updating the Firmware (Blinking) Yellow/Green The module card is booting and preparing for ON (Blinking) test... -
Page 23: Xm-Rm781
G. XM-RM781 XM-RM-781 Front Panel Specification Port 1 RJ45 Port 2 RJ45 Interface Port 3 RJ45 Port 4 RJ45 Data Transfer Rate 1000 Mbps LED Status Green ON The module card is operating Yellow ON The module card is updating the Firmware (Blinking) Yellow/Green The module card is booting and preparing for... -
Page 24: Xm-Rm881
H. XM-RM881 XM-RM881 Front Panel Specification Port 1 Port 2 Interface Port 3 Port 4 Data Transfer Rate 10 Gbps LED Status Green ON The module card is operating Yellow ON The module card is updating the Firmware (Blinking) Yellow/Green The module card is booting and preparing for ON (Blinking) test... -
Page 25: Xm-Rm882
I. XM-RM882 XM-RM882 Front Panel Specification Port 1 Port 2 Interface Port 3 Port 4 Data Transfer Rate 10 Gbps LED Status Green ON The module card is operating Yellow ON The module card is updating the Firmware (Blinking) Yellow/Green The module card is booting and preparing for ON (Blinking) test... -
Page 26: Example Of Suitable Software For Nustreams-700
5. Example of suitable software for NuStreams-700 Some software suitable for NuStreams-700 are showed below, please note that the software showed below don’t include all software suitable for NuStreams-700, for more information regarding the others software, please contact our account managers. -
Page 27: Nuapps-2544-Rm
5.2. NuApps-2544-RM Designed for Xtramus Technologies XM-RM series module cards, NuApps-2544-RM is an application designed based on RFC 2544 for analyzing Ethernet switches, bridges, and routers, NuApps-2544-RM’s load-generating capabilities provide an effective way to evaluate DUT Throughput, Latency, Packet Loss, and Back to Back under different modes such as One-to-One, One-to-Many, and Many-to-One. - Page 28 Latency The time interval for store and forward devices. Back to Back Fixed length frames presented at a rate such that there is the minimum legal separation for a given medium between frames over a short to medium period of time, starting from an idle state. With its real-time display of the results and various customizable report formats that allow users to view the test data and organize them into an appropriate form for debug, report, and record.
-
Page 29: Nuapps-Multiunits-Rm
5.3. NuApps-MultiUnits-RM NuApps-MultiUnits-RM is a utility software that displays up to 8 independent windows in 1 user interface, where each window can run different settings with an independent DUT (Device Under Test). The NuApps-MultiUnits-RM supports all XM-RM module cards and can reserve the XM-RM module card’s ports on each testing window, where the testing result of each window can be showed separately on a log file. -
Page 30: Appendix - Other Utility Softwares For Nustreams-700
6. Appendix – Other Utility Softwares for NuStreams-700 There are several other optional utility softwares for NuStreams-700 for different kinds of test requirements. The following section contains brief descriptions of these utility softwares. NuApps-2889-RM: RFC 2889 Benchmark Test Utility Designed for Xtramus Technologies XM-RM series module cards, NuApps-2889-RM is an application that’s designed base on RFC 2889 for analyzing Ethernet switches, bridges, and routers.
