Recessed adjustable trim suitable
for wall wash and wall accent
applications.
Ultra low profile trim flange for
minimum ceiling architecture
interference. Provides a sleek,
architectural look.
Trim has a durable powder coat
finish.
Inside of trim and lamp holder fin-
ished with flat black powder coat
for reduced lamp glare.
Trim is retained in housing with
heavy duty torsion spring clip.
All ComboMini™ fixtures can
accept up to two (2) optical
accessories per lamp.
Housing Construction:
Plaster frame and housing are 18
gauge CRS with durable powder
coat finish.
Integral electronic transformer
with 14 gauge CRS galvanized J-
Box assembly. External thermal
protection. UL listed for through
branch wiring for 8 #12, 90ºC sup-
ply conductors or 60ºC supply
conductors for end of run.
Type:
Combo Mini Recessed Wall Accent
o
Two (2) Light 60
Adjustable
New Construction Housing - 7.13" Height
12V Bi-Pin Base MR16 Lamp 75 Watts Max.
7.125"
4.75"
5.5"
1.625"
Provided with two (2) 14 gauge steel butter-
fly type brackets for black iron installations.
Vent holes in housing (1/2" diameter) pro-
vide cooler operation.
Item #
Description
CM2W
Combo Mini Recessed Wall Accent
CM2B
Two Light 60º Adjustable
CM2S
©2002 RSA Lighting LLC All Rights Reserved • Specifications subject to change without notice.
Project:
18.125"
7.125"
60º Locking Adjustability
4.535"
Lamps adjust 60º for variable beam placement.
Housing adjusts in plaster frame to accommo-
date various ceiling thicknesses.
Finish
White
Black
Silver
RSA LIGHTING LLC 9660 - 9700 TOPANGA CANYON BLVD. CHATSWORTH CA. 91311
TOLL FREE: 800-356-3030 • 818-349-3030 • FAX: 818-349-3031 • www.rsalighting.com
CM2W
6.75"
7.688"
2.95" x 2.445"
Regular Aperture
Voltage / Wattage
12V / 75W Max.
CM2B
CM2S
4.25"
CM3
